PN 667345 December 1998, Rev.1, 12/99

All product names are trademarks of their respective companies.

Model 705

Loop Calibrator

Calibration Information

W Warning

To avoid electrical shock, remove test leads and any input signals from the

Model 705 Loop Calibrator before opening the case.

Caution

The Model 705 Loop Calibrator contains parts that can be damaged by static

discharge. Follow the standard practices for handling static sensitive

devices.

Introduction

The Calibration Information for the Model 705 Loop

Calibrator (hereafter referred to as the Loop

Calibrator) provides the information necessary to

calibrate and verify the performance of the Loop

Calibrator.

This document includes the following:

• Contacting Fluke for service

• Specifications

• Cleaning

• Replacing the battery

• Disassembly and reassembly

• Recommended test equipment

• Performance verification procedures

• Calibration adjustments

• User-replaceable parts

Complete operating instructions and the warranty

statement for the Model 705 Loop Calibrator are

provided in the Instruction Sheet that came with it.

Contacting Fluke for Service

This Fluke product will be free from defects in

material and workmanship for three years from the

date of purchase.

The complete warranty statement is in the Model 705

Loop Calibrator Instruction Sheet.

To locate an authorized service center, visit us on the

World Wide Web: www.fluke.com or call Fluke using

the phone numbers listed below:

• 1-888-99FLUKE (1-800-993-5853) in USA

• 1-800-36-FLUKE (1-800-363-5853) in Canada

• +31 402-678-200 in Europe

• +81-3-3434-0181 in Japan

• +65-738-5655 in Singapore

• +1-425-356-5500 from other countries

Fluke 705

Calibration Information

Specifications

Product specifications are provided Tables 1 and 2. These specifications are based on a 1-year calibration cycle and

apply from 18 ºC to 28 ºC (64 ºF to 82 ºF) unless stated otherwise. Accuracy specifications are given as follows:

± ( [ % of reading ] + [ number of least significant digits ] ).

Table 1. General Specifications

Maximum voltage between any

terminal and earth ground or

between any two terminals

30 V

Display: 0 to 28 V with 0.001 V resolution, 0 to 24 mA with 0.001 mA resolution

Operating Temperature: -10 °C to 55 °C

Storage Temperature: -40 °C to 60 °C

Temperature Coefficient: ± 0.005 % of range per °C for -0 °C to 18 °C and 28 °C to 55 °C

Relative Humidity: 95 % to 30 °C,

75 % to 40 °C,

45 % up to 50 °C,

35 % up to 55 °C

Operationing Altitude: 3000 meters maximum

Power Requirements: Single 9 V battery (ANSI/NEDA 1604A or IEC 6LR61)

Battery Life (Typical): Source Mode: 18 hours; 12 mA into 500 Ω

Measure / Simulate Mode: 50 hours

Shock, Vibration: 1 meter drop test

Random vibration 2 g @ 5 to 500 Hz

Size (H x W x L): 32 mm x 87 mm x 187 mm (1.25 in x 3.41 in x 7.35 in)

Weight: 349 g (12.3 oz). With Holster and flex-stand: 601 g (21.2 oz)

Safety Certified as compliant to CAN/CSA C22.2 No. 1010.1:1992.

Complies with ANSI/ISA S82.01-1994

Certification P and

)

Table 2. Accurcy Specifications

Function Range Resolution Accuracy

DC Volts Input + 28 V 0.001 V ± (0.025 % + 1)

DC mA Input 24 mA 0.001 mA ±( 0.02 % + 2)

DC mA Output 0 mA to 24 mA 0.001 mA ± (0.02 % + 2)

E 0 % -100 % - 0 % 40 second smooth ramp

O 0 % -100 % - 0 % 15 second smooth ramp

N 0 % -100 % - 0 % Stair-step ramp in 25 % steps, pausing 5 seconds at each step

Source mode: Compliance: ≥ 1000 Ω at 20 mA

Simulate mode: External loop voltage requirements: 24 V nominal, 30 V maximum, 12 V minimum

Loop Power ≥ 24 V

Percent display - 25 % to 125 %

Input/Output protection Input/Output protection on mA range: resettable, nonreplaceable 0.1 A fuse.

Produkspesifikasjoner

Merke:	Fluke
Kategori:	Multimeter
Modell:	705
Vekt:	340 g
Bredde:	70 mm
Dybde:	41 mm
Høyde:	152 mm
Bruksanvisning:	Ja
Kontrolltype:	Knapper
Batterispenning:	9 V
Driftstemperatur (T-T):	-10 - 55 °C
Oppbevaringstemperaturomåde (Celsius):	-40 - 60 °C
Relativ luftfuktighet under drift (H-H):	0 - 90
Hylstermateriale:	Ja
Krokodille klype:	Ja
Loop-spenning:	30 V
Spenning målingsoppløsning:	0.001 V
Periodesjekk:	Ja
Auto-trinn:	Ja
Spenning målingsnøyaktighet:	0.25
