Side 1/52

October 2019 Rev. 1, 2/20

All product names are trademarks of their respective companies.

87V MAX

Digital Multimeter

Users Manual

Lifetime Limited Warranty

Each Fluke 20, 70, 80, 170, 180 and 280 Series DMM will be free from defects in material and workmanship for its lifetime. As used herein,

“lifetime” is defined as seven years after Fluke discontinues manufacturing the product, but the warranty period shall be at least ten years from

the date of purchase. This warranty does not cover fuses, disposable batteries, damage from neglect, misuse, contamination, alteration,

accident or abnormal conditions of operation or handling, including failures caused by use outside of the product’s specifications, or normal

wear and tear of mechanical components. This warranty covers the original purchaser only and is not transferable.

For ten years from the date of purchase, this warranty also covers the LCD. Thereafter, for the lifetime of the DMM, Fluke will replace the LCD

for a fee based on then current component acquisition costs.

To establish original ownership and prove date of purchase, please complete and return the registration card accompanying the product, or

register your product on http://www.fluke.com. Fluke will, at its option, repair at no charge, replace or refund the purchase price of a

defective product purchased through a Fluke authorized sales outlet and at the applicable international price. Fluke reserves the right to

charge for importation costs of repair/replacement parts if the product purchased in one country is sent for repair elsewhere.

If the product is defective, contact your nearest Fluke authorized service center to obtain return authorization information, then send the

product to that service center, with a description of the difficulty, postage and insurance prepaid (FOB Destination). Fluke assumes no risk

for damage in transit. Fluke will pay return transportation for product repaired or replaced in-warranty. Before making any non-warranty

repair, Fluke will estimate cost and obtain authorization, then invoice you for repair and return transportation.

THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER WARRANTIES, SUCH AS FITNESS FOR A PARTICULAR PURPOSE, ARE

EXPRESSED OR IMPLIED. FLUKE SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL

DAMAGES OR LOSSES, INCLUDING LOSS OF DATA, ARISING FROM ANY CAUSE OR THEORY. AUTHORIZED RESELLERS ARE

NOT AUTHORIZED TO EXTEND ANY DIFFERENT WARRANTY ON FLUKE’S BEHALF. Since some states do not allow the exclusion or

limitation of an implied warranty or of incidental or consequential damages, this limitation of liability may not apply to you. If any provision of

this warranty is held invalid or unenforceable by a court or other decision-maker of competent jurisdiction, such holding will not affect the

validity or enforceability of any other provision.

Fluke Corporation

P.O. Box 9090

Everett, WA 98206-9090

U.S.A.

Fluke Europe B.V.

P.O. Box 1186

5602 BD Eindhoven

The Netherlands

ООО «Флюк СИАЙЭС»

125167, г. Москва, Ленинградский

проспект дом 37,

корпус 9, подъезд 4, 1 этаж

5/07

Table of Contents

Title Page

Introduction .................................................................................................................... 1

How to Contact Fluke ..................................................................................................... 1

Safety Information .......................................................................................................... 1

Features ......................................................................................................................... 2

Automatic Power-Off ................................................................................................. 8

Input Alert™ Feature ................................................................................................. 8

Power-Up Options ..................................................................................................... 8

How to Make Measurements .......................................................................................... 10

AC and DC Voltage Measurements ........................................................................... 10

Zero Input Behavior of True-rms Meter ..................................................................... 11

Low-Pass Filter .......................................................................................................... 11

Temperature Measurements ..................................................................................... 12

Continuity Tests ......................................................................................................... 13

Resistance Measurements ........................................................................................ 15

Produkspesifikasjoner

Merke:	Fluke
Kategori:	Multimeter
Modell:	87V MAX
Produkttype:	Digitalt
Vekt:	698.5 g
Bredde:	600 mm
Dybde:	215 mm
Høyde:	101 mm
Strømkilde:	Batteri
Vanntett:	Ja
Batterilevetid:	800 timer
Frekvensområde:	0.5 - 199.99 kHz
Batteritype:	AA
Kapasitansområde:	0.1 - 9999 nF
Oppløsning (AC-spenning):	0.1 mV
Oppløsning (frekvens):	0.01 Hz
Produktfarge:	Gult
Antall støttede batterier:	3
Internasjonal beskyttelses (IP)-kode:	IP67
DC-spenningsområde:	0.1 - 1000 V
AC-spenningsområde:	0.1 - 1000 V
Display:	Analog
Støttede plasseringer/plasseringer som kan benyttes:	Håndholdt multimeter
Dust-resistant:	Ja
Intervall for temperaturmåling:	-200 - 1090 °C
Målekaterogi:	CAT III 1000V
Oppløsning (DC-spenning):	0.1 mV
Resistansområde:	0.1 - 50 Ω
Resistansoppløsning:	0.1 Ω
Oppløsning (AC-strøm):	0.1 µA
Oppløsning (DC-strøm):	0.1 µA
