Side 1/9

Fluke IRR1-SOL

Irradiance Meter

Users Manual

5237649, September 2020

Specications are subject to change without notice.

All product names are trademarks of their respective companies.

Fluke Corporation Fluke Europe B.V.

P.O. Box 9090 P.O. Box 1186

Everett, WA 98206

-9090

5602 BD Eindhoven

U.S.A. The Netherlands

Introduction

The Fluke IRR1-SOL Irradiance Meter (the Meter) provides digital read-outs

related to photovoltaic (PV) panels. Measures and reads:

• Solar irradiation (W/m

) on the surface of a photovoltaic (PV) panel

• Temperature (°F or °C) on the surface of a photovoltaic (PV) panel

• Inclination (degrees) of a photovoltaic (PV) panel

• Cardinal degrees with the compass function

The read-outs provided by the Meter help determine optimum positioning of the

photovoltaic (PV) panel for best performance.

Contact Fluke

Fluke Corporation operates worldwide. For local contact information, go to

our website: www.uke.com

To register your product, view, print, or download the latest manual or manual

supplement, go to our website.

Fluke Corporation

P.O. Box 9090

Everett, WA 98206-9090

+1-425-446-5500

uke-info@uke.com

Kit Components

The product contains the following items:

1 FLK-IRR1-SOL/001 Solar Irradiance Meter

1 FLK-80PR-IRR External Temperature Probe with Suction Cup

1 C250 Carrying Case with Shoulder Strap

4 AA Alkaline Batteries

1 User Manual

English

Symbols

Symbol Description



WARNING. RISK OF DANGER.

Consult user documentation.

Battery or battery compartment.

Conforms to relevant South Korean EMC Standards.

Conforms to relevant Australian standards.



Conforms to European Union directives.



This product complies with the WEEE Directive marking

requirements. The a󰀩xed label indicates that you must

not discard this electrical/electronic product in domestic

household waste. Product Category: With reference to

the equipment types in the WEEE Directive Annex I, this

product is classed as category 9 “Monitoring and Control

Instrumentation” product. Do not dispose of this product as

unsorted municipal waste.

Safety Information

A Warning identies hazardous conditions and procedures that are

dangerous to the user. A Caution identies conditions and procedures that

can cause damage to the Product or the equipment under test.



Warning

To prevent personal injury and damage to the Product:

• Read the entire users manual before using the Meter.

• Use the Meter only as described in the Users Manual otherwise

the protection provided by the equipment may be impaired.

• Inspect the Meter before use. Do not use it if it appears damaged.

• Do not use the Meter around explosive gas, vapor, and/or in damp

or wet environments that exceeds IP40.

• The Meter contains no user-serviceable parts. Do not open

the instrument.

• Use only AA batteries, properly installed in the Meter case, to

power the Meter (see Battery Replacement).

• To avoid false readings, replace the batteries as soon as the low

battery indicator appears.

• Remove the batteries if the Meter is not used for an extended

period of time, or if stored in temperatures above 140 °F (60 °C).

If the batteries are not removed, battery leakage can damage the

Meter.

• Have the Meter serviced only by qualied service personnel.

Product Overview

1617

ON/OFF Button

Battery Level Indicator

Angle Reset Button

* Use function to measure

angle di󰀨erence between solar

panel and surface

Compass Function Indicator

Function key for Irradiance,

Temperature, Compass and

Angle measurements

Irradiance Units and

Function Indicator

Integrated Temperature

Sensor for panel's surface

measurement

Angle Function Indicator

External Temperature

Probe Socket

Temperature Units Indicator

(Celsius / Fahrenheit)

Photovoltaic Irradiance Sensor

Angle Reset Indicator

Hold Button to hold

measurement on the display

*Push button for 2 seconds

to enable Temperature Units

Change mode

External Temperature

Probe Indicator

Temperature Units Switch

Button (Celsius / Fahrenheit)

Integrated Temperature

Sensor Indicator

Hold Indicator

Produkspesifikasjoner

Merke:	Fluke
Kategori:	Lysmåler
Modell:	FLK-IRR1-SOL
Vekt:	231 g
Bredde:	80 mm
Dybde:	35 mm
Høyde:	150 mm
Strømkildetype:	Batteri
Batteriteknologi:	Alkalinsk
Batteritype:	AA
Produktfarge:	Black, Yellow
Antall støttede batterier:	4
Oppbevaringstemperaturomåde (Celsius):	-30 - 60 °C
