i3000s/i2000 Flex

AC Current Probe

Instruction Sheet

Introduction

The i3000s 24 Flex, i3000s 36 Flex, and i2000 Flex AC Current

Probes (the Probe) are used with oscilloscopes, digital

multimeters, recorders or data loggers. The i3000s probes can

be used to measure AC current up to 3000 A. The i2000 can be

used to measure AC current up to 2000 A. The flexible

measuring head allows current measurements on conductors

that are hard to reach or inaccessible using typical clamp-on

current probes.

The Probes provide a low-voltage (3 V AC for i3000s models,

and 2 V AC for i2000) output that is proportional to the current

being measured. The Probes provide full-scale direct readings

for 30 A, 300 A, and 3000 A when using the i3000s models, and

20 A, 200 A, and 2000 A when using the i2000.

Safety Instructions

A Warning identifies conditions and procedures that are

dangerous to the user. A Caution identifies conditions and

procedures that can cause damage to the Product or the

equipment under test.

 Warning

To prevent electric shock or personal injury:

• Use the Current Probe only as specified in the

operating instructions; otherwise the current

probe’s safety features may not protect you.

• Use the Probes only if qualified.

• Use caution during installation and use of the

Probe; high voltages and currents may be

present in circuit under test.

• Have maintenance performed by only qualified

service personnel.

PN 2560447

March 2006, Rev. 1, 4/17

Specifications are subject to change without notice.

All product names are trademarks of their respective companies.

Produkspesifikasjoner

Merke:	Fluke
Kategori:	Multimeter
Modell:	i3000s Flex
Produkttype:	Strømklemme
Vekt:	190 g
Tilkobling:	BNC
Sertifisering:	BS EN 61010-1: 2001\nBS EN 61010-2-032: 2002\nBS EN 61010-031: 2002
Materiale:	Polypropylene (PP), Thermoplastic elastomer (TPE)
Antall per pakke:	1 stykker
Lengde:	610 mm
Nominell spenning:	600 V
Kabellengde:	2 m
Produktfarge:	Black, Red, Yellow
Driftstemperatur (T-T):	-20 - 85 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 85 °C
Strøm (maks.):	3000 A
Maksimal driftshøyde:	2000 m
Målekategori som støttes:	CAT III
Dobbeltisolert:	Ja
