PN 4954885 October 2018 Rev. 1, 2/19
©2018-2019 Fluke Corporation. All rights reserved.
Specifications are subject to change without notification.
All product names are trademarks of their respective companies.
Fluke Corporation
P.O. Box 9090
Everett, WA 98206-9090
U.S.A.
Fluke Europe B.V.
P.O. Box 1186
5602 BD Eindhoven
The Netherlands
ООО «Флюк СИАЙЭС»
125167, г. Москва,
Ленинградский проспект дом 37,
корпус 9, подъезд 4, 1 этаж
PQ400
PQ Window
Voltage/Current Measurement Feed-Through
Device for Electrical Enclosures
Instructions
PQ Window (the Product) is an accessory that mounts to the
flat surface of a Type 12 electrical enclosure (derate to Type 1
during measurements). When the Product is installed and signal
feeds connected, you can safely perform voltage and current
measurements from outside the enclosure.
Standard 4 mm safety sockets on the front provides access
to the three phases (A/L1, B/L2, C/L3), Neutral N, and Earth/
Ground for voltage measurements. The voltage outputs
support instruments that are powered from the measurement
line with a maximum power of 100 VA.
The Product supports current measurement with Fluke
intelligent current sensors (iFlex1500-12, iFlex 3000-24,
i40S-EL and i400S-EL). Go to www.fluke.com
for a full list of
compatible accessories.
The 354x FC, 173x Power, and 174x Power Quality Loggers
automatically read the sensor information, such as, the type,
serial number, scale factor, and phase angle compensation.
Use the optional adapter kit to connect instruments and
current sensors that have BNC connectors.
To contact Fluke, call one of the following telephone numbers:
• Technical Support USA: 1-800-44-FLUKE
(1-800-443-5853)
• Calibration/Repair USA:
• 1-888-99-FLUKE (1-888-993-5853)
• Canada: 1-800-36-FLUKE (1-800-363-5853)
• Europe: +31 402-675-200
• Japan: +81-3-6714-3114
• Singapore: +65-6799-5566
• China: +86-400-921-0835
• Brazil: +55-11-3530-8901
• Anywhere in the world: +1-425-446-5500
Or, visit Fluke's website at www.fluke.com
.
To register your product, visit http://register.fluke.com
.
To view, print, or download the latest manual supplement,
visit http://us.fluke.com/usen/support/manuals
.
A Warning identifies conditions and procedures that are
dangerous to the user.
XW Warning
To prevent possible electrical shock, fire, or
personal injury:
• Read all safety information before you use
the Product.
• Carefully read all instructions.
• Do not alter the Product and use only as
specified, or the protection supplied by the
Product can be compromised.
• Do not touch voltages >30 V ac rms,
42 V ac peak, or 60 V dc.
• Do not use the Product around explosive
gas, vapor, or in damp or wet
environments.
• Only install the Product to the specified
measurement category, voltage, or
amperage ratings.
• Do not exceed the Measurement Category
(CAT) rating of the lowest rated individual
component of a Product, probe, or
accessory.
• Do not use the Product if it is damaged.
• De-energize the voltage inputs before you
open the feed-through box.
• Comply with local and national safety codes.
Use personal protective equipment
(approved rubber gloves, face protection,
and flame-resistant clothes) to prevent
shock and arc blast injury where hazardous
live conductors are exposed.
• Use a circuit breaker rated for the wire gauge
used on the voltage inputs to the Product.
• Make sure that the sealing areas are clean
before you close the cover.
• Use only the replacement fuses specified by
the manual.
• Only for installation on bonded metal
enclosures that provide a protective earth
connection.
