TL2X4W-TWZ
2x4-Wire Ohms Tweezers Test Leads
Instruction Sheet
Introduction
The Fluke TL2X4W-TWZ 2X4-Wire Tweezers Test Leads are
designed for use with the 8808A, 8845A, and 8846A multimeters.
The split contacts of the test lead’s banana plugs are aligned to
mate with the split contacts of the 8808A, 8845A, and 8846A HI
and LO input connectors.
The split contact design of the meters and the test leads bring
both the input and sense terminals of the meters to any 4-wire
resistance measurement with only two, instead of four test leads.
PN 3255292
April 2008
©2008 Fluke Corporation. All rights reserved. Printed in U.S.A.
All product names are trademarks of their respective companies.
Safety Information
XW Warning
To avoid possible electric shock or personal injury:
• Do not use the test leads to measure voltages
above 33 V rms, 46.7 V peak or 70 V dc.
Voltages above these levels will cause electric
shock.
• Do not use the test leads for measurements
within Measurement Categories II, III, and IV.
• Use the test leads only as specified by Fluke or
the protection provided may be impaired.
• Do not use the test leads if they are cracked or
have exposed metal.
• Do not exceed the test lead’s voltage and
current rating.
• Make sure test leads are fully mated to the
instrument and accessories.
• Keep fingers behind the finger guards
• Adhere to local and national safety codes.
• Individual protective equipment must be used
to prevent shock and injury.
International Symbols
Symbol Meaning
J
Earth ground
X
Hazardous voltage
W
Risk of danger. Important information. See
instruction sheet.
P
Conforms to European Union directives
T
Double Insulated
Cleaning
Cleaning the leads with a soft cloth, mild soap, and water. To
avoid damage, do not use abrasives or solvents to clean the
leads.
Specifications
Maximum Voltage between test lead and ground: 33 V rms,
46.7 V peak or 70 V dc
Maximum Current: 1 A.
Temperature
Operating: 0 to 55 ºC < 90% relative humidity
Storage: -40 to +70 ºC
Altitude: 2000 m
Safety: Complies with EN/IEC 61010-031.
