Installation Instructions
QUASAR Contactless Bottle Filler
Models UV-C LED WATER TREATMENT:
• KEPWEBQ
• KEP*EBQ Family of Drinking
Fountains/Bottle Filler combo
The Contactless Bottle Filler mounts directly above Versacooler
® I and II
products.
If installed onto a refrigerated cooler, chilled water can be dispensed through
the Bottle Filler. Otherwise, room temperature water will be dispensed.
The Bottle Filler is shipped partially assembled.
On the combo units, the cooler is plumbed and ready to attach to the Bottle
Filler.
When completed, the finished assembly will look like this:
1
OR
1
07/25 | FRANKE 0365865-081 (B)
What’s Included:
Section 1: Getting Started
Rubber
Gasket
Installation
instructions
Quick connect tee
fitting
Snap bushings 7/8”
and 1½”
Top Cap
Optional
Versafilter III
38” of ¼ OD plastic
tubing with 38” of
sponge tubing
insulation
Quick connect
elbow fitting
Quasar Hands-Free
Bottle Filler
3/8” pilot drill and either a step drill bit up to 7/8” diameter that will drill
through SS top or 7/8” diameter punch die (retrofit version only)
Electric drill; wrench for punch die
Small tubing cutter for copper tube
1/4“ nut driver
# 2 Phillips screwdriver
#15 torx bit driver
Tools required:
2
07/25 | FRANKE 0365865-081 (B)
Section 2: IMPORTANT REQUIREMENT
CAUTION: ENSURE BOTTLE FILLER IS PROPERLY GROUNDED. IT IS REQUIRED
TO ATTACH THE LONG GREEN GROUND WIRE TO THE FRAME ASSEMBLY.
REFER TO THE STEPS DESCRIBED ON STEPS 6-8 ON PAGE 19.
Section 3A: QUASAR
®
UV-C LED OPERATION
1. QUASAR is a form of dispense point water treatment that utilizes
UV-C LEDs to inactivate pathogens.
2. Operation:
a. The QUASAR activation is automatic. The UV-C LEDs turn
ON when water is dispensed and OFF when the dispense
stops.
b. During non-use periods the QUASAR automatically cycles ON
for ten seconds every ten minutes. This keeps the dispense
point more sanitary between use.
c. When the QUASAR is ON, the LED light on the front of the
alcove near the top will turn BLUE.
d. If QUASAR is not working properly, then the LED light on the
front of the alcove near the top will be ORANGE. The light will
remain ORANGE and the system will not allow water to be
dispensed until the problem is resolved.
e. IMPORTANT: Never operate the QUASAR without water
connected to the system. Lack of water can cause the
QUASAR to overheat. If it is necessary to activate QUASAR
to purge the system of air, then the QUASAR will
automatically shut off if it overheats. The QUASAR will
resume operation once water begins to flow through it.
CAUTION: DO NOT ACTIVATE BOTTLE FILLER ELECTRIC EYE SENSOR
WITHOUT RUNNING WATER THROUGH THE UV-C MODULE. OPERATING THE
UV-C MODULE DRY MAY DAMAGE THE UV-C LEDS.
3
07/25 | FRANKE 0365865-081 (B)
