Gigabyte AORUS Liquid Cooler 280 Bruksanvisning

Gigabyte CPU kjøler AORUS Liquid Cooler 280

Les nedenfor 📖 manual på norsk for Gigabyte AORUS Liquid Cooler 280 (2 sider) i kategorien CPU kjøler. Denne guiden var nyttig for 4 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/2

AORUS LIQUID COOLER Quick Installation Guide

Installing the AORUS LIQUID COOLER

For Intel motherboard:

12QM-LIQ248-2NR

1 x AORUS LIQUID COOLER 360

1 x AORUS LIQUID COOLER 280

1 x AORUS LIQUID COOLER 240

Package contents:

1 x Intel Backplate 1 x Intel Mounting Bracket 1 x AMD Mounting Bracket

4 x LGA 115X/1200/1366

Standoff Screws

4 x LGA 2011/2011-3/2066

Standoff Screws

8 or 12 x UNC 6-32x30mm

Fan Screws

4 x Thumbscrew caps

4 x AM4 Standoff Screws

16 or 24 UNC 6-32x8mm

Randiator Screws

8 or 16 x Washers

For LGA 20XX socket

For LGA 1366

socket

For LGA 115X/1200

socket

For LGA 115X/1200/1366 socket

AORUS LIQUID COOLER 360:

3 x 12cm fans

AORUS LIQUID COOLER 280:

2 x 14cm fans

AORUS LIQUID COOLER 240:

2 x 12cm fans

8 or 12 x Metal gaskets

for fan

Installing the AORUS LIQUID COOLER

Cable Connection

GIGA-BYTE TECHNOLOGY CO., LTD.

Address: No.6, Baoqiang Rd., Xindian Dist., New Taipei City 231, Taiwan

TEL: +886-2-8912-4000, FAX: +886-2-8912-4005

Tech. and Non-Tech. Support (Sales/Marketing) : https://esupport.gigabyte.com

WEB address (English): https://www.gigabyte.com

WEB address (Chinese): https://www.gigabyte.com/tw

The trademarks mentioned in this manual are legally registered to their respective owners.

Disclaimer

Information in this manual is protected by copyright laws and is the property of GIGABYTE.

Changes to the specications and features in this manual may be made by GIGABYTE without prior notice.

No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or by any means without GIGABYTE's prior written permission.

For product-related information, check on our website at: https://www.gigabyte.com

For AMD motherboard:

USB 2.0 Cable

LED Headers

Fan Headers

SATA Power

Produkspesifikasjoner

Merke:	Gigabyte
Kategori:	CPU kjøler
Modell:	AORUS Liquid Cooler 280
Antall per pakke:	1 stykker
Maksimal luftstrøm:	100.16 cfm
Egnet plassering:	Prosessor
Maksimalt lufttrykk:	5.16 mmH2O
Viftehastighet (maks.):	2300 RPM
Vannblokkmateriale:	Kopper
Radiatormateriale:	Aluminium
Radiatorhøyde:	30 mm
Viftelagerteknologi:	Dobbelt kulelager
Pumpebredde:	80 mm
Produktfarge:	Sort
Harmonisert system (HS)-kode:	84733080
Modell/Type:	Alt-i-ett væskekjøler
Viftestøynivå (maks.):	44.5 dB
Belysningsfarge:	Multi
Viftediameter:	140 mm
Antall vifter:	2 vifter
Belysningsdiode:	Ja
Støttede prosessorkontakter:	LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1366 (Socket B), LGA 2011-v3 (Socket R), LGA 2066, Socket AM4, Socket TR4
Viftens forventede levetid (MTTF):	70000 timer
Radiatordybde:	143 mm
Radiatorbredde:	315 mm
Pulsbreddemodulerings- støtte (PWM):	Nei
Viftekontroller:	Ja
Viftestøynivå (min.):	22.3 dB
Pumpedybde:	80 mm
Pumpehøyde:	60 mm
