Operating Instructions
Convector Heater
With Fan and Timer
Model: GCV330
General Care and Safety Guide
Thank you for choosing a Goldair Convector Heater. This Goldair Heater
has been designed and manufactured to high standards of engineering
and with proper use and care, as described in this leaflet, will give you
years of useful service. Please read these instructions carefully.
TECHNICAL SPECIFICATION
Model No: GCV330
Supply: 230-240VAC 50Hz
Wattage: 1900-2000W
1. Use only the voltage specified on the rating
label of the appliance.
2. Keep all objects at least 1 metre from the front,
sides and rear of the appliance. Do not place
appliance close to radiant heat source.
3. Do not operate in areas where petrol, paint or
other flammable liquids are used or stored.
4. Do not insert or allow foreign objects to enter
any ventilation or exhaust opening, as this may
cause an electric shock, fire or damage to the
appliance. Do not sit on the appliance.
5. Do not operate this appliance with a damaged
cord, plug or after the appliance malfunctions or
has been dropped or damaged in any manner.
Return to a qualified electrical person for
examination, electrical service or repair.
6. This appliance is intended for household use
only and not for commercial or industrial use.
7. Use this appliance only as described in this
manual. Any other use is not recommended by
the manufacturer and may cause fire, electrical
shock or injury.
8. The common cause of overheating is deposits
of dust or fluff in the appliance. Ensure these
deposits are removed regularly by unplugging
the appliance and vacuum cleaning the air vents
and grills.
9. Do not use abrasive cleaning products on this
appliance. Clean with a damp cloth (not wet)
rinsed in hot soapy water only. Always remove
plug from the mains supply before cleaning.
10. Do not connect the appliance to mains supply
until completely assembled and adjusted.
11. Switch off and use handles provided when
moving.
12. Do not operate with cord set coiled up as a heat
build up is likely, which could be sufficient to
become a hazard.
13. It is recommended that this heater is plugged
directly into the wall socket. Power boards are
not rated to supply power to high wattage
appliances.
14. A correctly specified, undamaged extension
cord may be used with this heater provided it is
used in a safe manner.
15. Do not remove plug from power socket until the
appliance has been switched off.
16. Do not remove plug from power socket by
pulling cord; always grip plug.
17. Always unplug appliance when not in use.
18. Do not locate the heater directly below any
power socket during operation.
19. Do not twist, kink or wrap the cord around the
appliance, as this may cause the insulation to
weaken and split. Always ensure that all cord
has been removed from any cord storage area
and is unrolled before use.
20. This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge, unless they are
supervised or have been given instruction
concerning the use of the appliance by a person
responsible for their safety.
21. Do not use this appliance in the immediate
surrounds of a bath, a shower, or a swimming
pool or other liquids. The appliance must not be
immersed in any liquids.
22. When the appliance has been unpacked, check
if for transport damage and ensure all parts
have been delivered. If parts are missing or the
appliance has been damaged, contact the
Goldair Customer Services Team.
23. If your appliance does not work, or is not
working properly, contact the place of purchase
or the Goldair Customer Services Team. Repair
work on the appliance by unqualified persons
can cause serious risk to the user.
24. There are no user serviceable parts installed in
the unit.
25. Do not place the unit in wardrobes or other
enclosed spaces as this may cause fire
hazards.
26. This unit is not supposed to be used in or
around locations where foodstuffs, works of art
or delicate articles of science, etc are stored.
27. Indoor use only.
28. Children should be supervised to ensure that
they do not play with the appliance.
29. Ensure heater is on a flat, stable, heat-resistant
surface.
30. It is important that you do not cover this heater.
Operating your Convector Heater
HEAT CONTROL SWITCH
The control switch positions are:
I+ - Low Heat with fan
II+ - High Heat with fan
0 –Off
I - Low Heat
II - High Heat
Check that the heat control switch is set to Off
position before plugging the heater into the mains
supply. For greater economy, use the High Heat
setting initially and then switch to the Low Heat
setting.
THERMOSTAT
Turn the thermostat knob clockwise until you
reach the maximum temperature on the
graduated scale. When the desired room
temperature is reached, slowly turn the knob anti-
clockwise until the heater turns off (you will hear a
click). The heater will now cycle on and off to
maintain the set temperature.
SAFETY DEVICE
This appliance has two protection devices:
The first device automatically disconnects &
reconnects the appliance at a pre-set
temperature.
The second safety device disconnects the
appliance permanently in case of overheating, by
means of a thermal fuse (it is non resettable).
IMPORTANT! NEVER COVER THIS HEATER
Do not use this heater with a programmer,
remote-control system, separate timer or any
other device that switches the heater on
automatically.
Always choose a safe location for the heater, keeping in mind the safety
precautions outlined. Ensure all packaging has been removed from the
unit before use. This appliance requires no installation, it should be used
solely as a portable appliance.
WARNING Keep all objects at least 1 metre
from the front, sides and rear of the appliance.
PLEASE NOTE: As this product is fitted with a
Timer, the Timer has been set to the “ON”
position. Please refer to the Timer section for
setting instructions.
ASSEMBLING YOUR HEATER
Before using the heater the feet (supplied
separately in the carton), must be fitted to the
unit. These are to be attached to the base of the
heater by placing the lugs on the feet in the
bottom ends of the heater side mouldings. The
screw pack to attach the feet to your heater will
be taped to either one of the feet for your heater,
or taped to the plug head.
Goldair – New Zealand
Monday – Friday 8am-5pm
Phone +64 (0)9 917 4000
Phone 0800 232 633
info@cdb.co.nz
Goldair – Australia
Monday – Friday 8am-5pm
Phone +61 (0)3 9336 4423
Phone 1300 465 324
info@cdbgoldair.com.au
SUPPORT AND TECHNICAL ADVICE
