MIC750~3300TL-X
MIC750~3300TL-X
· Maximum efficiency of 97.6%
· Compact design
· Touch key& OLED display
· Flexible interface
· AFCI optional
www.ginverter.com
GROWATT NEW ENERGY TECHNOLOGY Co.,LTD
A: No.28 Guangming Road, Longteng Community, Shiyan, Baoan District, Shenzhen, P.R.China.
T: + 86 755 2747 1900 F: + 86 755 2749 1460
E: info@ginverter.com
MIC750TL-X MIC1000TL-XMIC1500TL-X
MIC2000TL-X
MIC2500TL-X
MIC3000TL-X
Datasheet
Max. recommended PV power
(for module STC)
1050W1400W2100W2800W3500W4200W
Max. DC voltage
500V500V500V500V550V550V
Start voltage
50V
50V50V50V80V80V
Nominal voltage
120V180V250V360V360V360V
MPP voltage range
50V-500V65V-550V65V-550V
AC nominal power
750W1000W1500W3000W2000W2500W
Max. AC apparent power
750VA1000VA1500VA2500VA3000VA2000VA
AC grid frequencyrange*
Max. output current
3.6A
THDi
97.4%97.4%97.4%97.4%
Max.efficiency
97.6%97.6%
96.5%96.5%97.0%97.0%
European efficiency
97.0%97.1%
Weight
6kg
Operating temperature range
Nighttime power consumption
* The AC voltage and frequency range may vary depending on specific country grid standard.
All specifications are subject to change without notice.
6kg6kg6kg6.2kg6.2kg
MIC3300TL-X
4290W
550V
80V
360V
65V-550V
3300W
3300VA
97.6%
97.1%
6.2kg
50/60 Hz (45-55Hz/55-65 Hz)
< 0.5W
25°C ... +60°C
50V-500V 50V-500V 50V-500V
No. of MPP trackers
1
No. of PV strings per MPP tracker
1
Max. input current per MPP tracker
Max. short-circuit current
per MPP tracker
13A
16A
Nominal AC voltagerange*)
230V (180-280V)
4.8A7.1A9.5A11.9A14.3A14.3A
Adjustable power factor
0.8leading…0.8lagging
Single phase
AC grid connection type
MPPT efficiency
99.9%
yes
DC reverse polarity protection
yes
DC switch
AC/DC surge protection
Type III / Type III
Insulation resistance monitoring
yes
Ground fault monitoring
yes
Grid monitoring
yes
Anti-islanding protection
yes
Residual-current monitoring unit
AFCI protection
yes
AC short-circuit protection
yes
Optional
Dimensions (W / H / D)
274/254/138mm
Noise emission (typical)
25 dB(A)
Topology
Transformerless
Cooling
Natural convection
Protection degree
IP65
Relative humidity
0-100%
Altitude
4000m
DC connection
H4/MC4(Optional)
AC connection
Connector
Display
Interfaces: RS485 / USB/Wi-Fi/
GPRS/ RF/LAN
OLED+LED/WIFI+APP
Yes/Yes/Optional/Optional/Optional /Optional
Warranty: 5 years / 10 years
Yes /Optional
CE,AS4777, AS/NZS 3100, CEI 0-21, VDE-AR-N 4105, VDE 0126-1-1, UTE C 15-712-1, EN50549, IEC 60068, IEC 61683,
IEC 62116, IEC 61727, INMETRO, G98, C10/C11, UNE217001, UNE206007, PO12.2
<3%
Input data (DC)
Output data (AC)
Efficiency
Protection devices
General data
