Side 1/82
User
Manual
Hamax ID:
10244 , Rev. 011, User manual Caress
User ManualImportant!
OK!
NOT OK!
BIKE FRAME TUBE
Ø = 28 - 40mm
NOT OK!
Hamax AS
Visiting address:
Vålerveien 159
N-1599 Moss
Norway
Tel.: +47 69 23 38 38
email: customerservice@hamax.no
www.hamax.com
EN EN
Congratulations on purchasing the Hamax bicycle child seat. You now have
a comfortable and safe child seat that can be adjusted to fit your child as
she/he grows.
Please read the instructions carefully before assembling or using the child
seat.
Keep these instructions in a safe place as they will be useful if you later
buy extra equipment for your child seat.
FR
DE
NO
CZ
DA
ES
FI
HU
IT
NL
Important!
Wichtig!
Viktig!
Důležité!
Vigtigt!
¡Importante!
TÄRKEÄÄ!
FONTOS!
IMPORTANTE!
BELANGRIJK!
INSTALLATION
• Can be mounted on bicycles with frame tube
diameters from 28-40 mm.
• Cannot be mounted on bicycles with oval or
square down tubes.
• Cannot be mounted where the luggage carrier
is wider than 160 mm.
(Note that the luggage carrier can be removed
before fitting the child seat.)
• Cannot be mounted on cycles fitted with shock
absorbers.
• Can be fitted to bikes with and without a
luggage carrier. If you are in any doubt that the
seat will fit, we recommend you seek
information from the bicycle’s supplier.
• The seat must only be mounted on a bicycle
which is suitable for this kind of load. Please
ask your bicycle supplier for detailed advice.
• Make sure the bracket screws are well
tightened and check them at regular intervals.
• The child seat is fitted on the frame tube of the
bike with the bracket (7). See picture E. The
screws must be tightened hard enough to fix
the seat securely and prevent it from sliding.
Make it a rule to check this before starting a
trip with the bike.
• For optimal comfort and safety of the child,
ensure that the seat does not slope forwards,
so that the child does not tend to slide out of it.
Hamax recommend that the backrest should
slope backwards slightly.
• Check that all parts of the bike function
correctly with the bicycle seat mounted.
USE
• To take a child on a bicycle, the rider must
normally be over 16 years. Check your national
laws and regulations.
• The child seat is approved for children from
about 9 months to 6 years or maximum 22 kg
weight. Ensure that you re-check from time to
time that the child’s weight and size do not
exceed the maximum capacity of the seat.
• Do not carry a child that is too young to sit
safely in the seat, please note the minimum age
of the child. Only carry a child that is able to sit
unaided for a longer period of time, at least as
long as the intended bicycle journey.
• Ensure that it is not possible for any part of
the child’s body or clothing to come into
contact with any moving part of the seat or
cycle and to re-check as the child grows, due to
the danger of entrapment of feet in the wheel
and of the finders in brake mechanisms and
sprung saddles. The child seat provides good
side and feet protection. However, you are
recommended to buy and fit a closed wheel
guard/chain guard. You can buy this at your
bicycle dealer.
• Check there are no sharp objects, such as split
wires, on the bicycle that can harm the child.
• Ensure that the restraint system is not loose or
able to become trapped in any moving parts
particularly the wheels, including when the
cycle is ridden without a child in the seat.
• Always use the safety belt/restraint system,
ensuring the child is restrained in the seat.
• A child sitting in a child seat should be dressed
more warmly than the rider.
• The child should be protected against rain with
suitable waterproof garments.
• Remember to put the child’s helmet on
before starting your bicycle trip.
• Remember that the child seat can get very hot
standing out in the sunshine, so check the child
seat before placing your child in it.
• When transporting the bicycle by car (outside
the car) remove the seat. Air turbulence might
damage the seat or loosen its fastenings to the
cycle, which can result in an accident.
WARNINGS
• Warning: Do not attach extra luggage or
equipment to the child seat, as this could lead
to the total load exceeding 22 kg. We
recommend that extra luggage is attached at
the front of the bicycle.
• Warning: Do not modify the child seat. This will
automatically invalidate the guarantee and the
manufacturer’s product liability will lapse.
• Warning: Be aware that the load of a child in
the child seat may alter the bicycle’s stability
and handling characteristics, particularly when
steering and braking.
• Warning: Never leave the bicycle parked with a
child in the seat unattended.
• Warning: Do not use the seat if any parts are
broken.
• Cover any exposed rear saddle spring.
MAINTENANCE
• When cleaning the seat, use only lukewarm
soapy water.
• If the child seat is involved in an accident or
are damaged, contact your dealer to check that
it can still be used. Damaged parts must
always be replaced. Contact your dealer if you
are not sure how to fit the new parts.
Tip! With an extra bracket you can easily move
one seat between two bicycles.
We wish you and your child many enjoyable
bicycle trips with your Hamax child seat!
Best regards from us at Hamax.
PL
PT
RO
RU
SE
SK
BG
TR
UA
LT
Ważne!
IMPORTANTE!
Importantă!
важно!
VIKTIGT!
Dôležité!
Важно!
Önemli!
Важливо!
Svarbu!
OK
NOT
OK
Caress C2
CARESS
FR
1. Siègeprincipal
2. Systèmedeharnais
3. Dossiercoulissant
4. Fermeturedeceinture
5.Supportsdepieds
6. Arcporteur
7.Étrierdefixationcomplet
a)Étrier
b)Sanglesmétalliques
c)Visdefixation
d)Indicateurdesécurité
e)Goupilledeverrouillage
f)Clé
8. Tigeexcentrique
9.Boutond’inclinaison
10.Protectiondepied
11.Bandepourexpositionenmagasin
DE
1. Sitz
2. Rückhaltesystem
3. VerschiebbareRückenlehne
4. Gurtverschluss
5. Fußstützen
6. Trägerbogen
7. KompletteBefestigungsklammer
a)Klammer
b)Metallstreifen
c)Befestigungsschrauben
d)Sperrenanzeige
e)Sperre
f)Schlüssel
8. Exzenterwelle
9. KnopffürZurücklehnen
10. Radkontaktschutz
11. Ausstellungsgurt
NO
1. Hovedsete
2. Sikkerhetssele
3. Justerbarryggstøtte
4.Beltelås
5.Fotstøtter
6.Bærebøyle
7.Festebeslagkomplett
a)Brakett
b)Metallbånd
c)Festeskruer
d)Låsindikator
e)Låsepinne
f)Nøkkel
8.Låsepinne
9. Justeringsrattforsoveposisjon
10.Ekstraeikebeskyttelse
11.Butikkutstillingsstropp
CZ
1. Sedačka
2.Zádržnýsystém
3. Posuvnéopěradlo
4.Bezpečnostnípřezka
5.Podporyproboty
6.Připevňovacírám
7.Kompletníupevňovacítřmen
a)třmen
b)kovovépásy
c)upevňovacíšrouby
d)indikátorzajištění
e)uzavíracípáčka
f)klíč
8. Excentrickýhřídel
9.Knoflíksklápění
10. Ochrana nohou
11.Reklamnípáska
DK
1. Sæde
2.Fastspændingssystem
3. Forskydeligtryglæn
4.Bæltelås
5.Fodstøtter
6.Bærebue
7.Kompletmonteringsbeslag
a)Beslag
b)Metalbånd
c)Fastgørelsesskruer
d)Sikkerhedslås
e)Låsebolt
f)Nøgle
8. Ekscenteraksel
9.Justeringsskrue
10.Fodbeskyttelse
11.Butiksudstillingsstrop
ES
1. Asientoprincipal
2.Sistemaderetención
3. Respaldoregulable
4.Cierredelcinturón
5.Reposapiés
6.Horquillasustentadora
7.Soportedesujecióncompleto
a)Soporte
b)Tirasmetálicas
c)Tornillosdefjiación
d)Indicadordeseguridad
e)Pasadordecierre
f)Llave
8. Ejeexcéntrico
9.Mandodereclinación
10.Protecciónparalospies
11.Correadepresentaciónentienda
FI
1. Istuin
2.Turvakiinnitysjärjestelmä
3. Liukuvaselkätuki
4.Vyönlukkosolki
5.Jalkatuet
6. Kantokaari
7.Kiinnityspidikekokonaisena
a)Pidike
b)Metalliliuskat
c) Kiinnitysruuvit
d)Turvamerkinnät
e)Lukitustappi
f)Avain
8. Epäkeskoakseli
9.Kallistusnuppi
10.Jalkasuoja
11.Kotelosuoja
HU
1. Gyermekülés
2.Biztonságiöv
3. Csúsztathatóháttámasz
4.Övrögzítő
5.Lábtartó
6.Tartórúd
7.Teljesrögzítőkonzol
a)Konzol
b)Fémlemez
c)Rögzítőcsavarok
d)Biztosításjelző
e)Lezárócsap
f)Kulcs
8. Excentrikustengely
9.Dőlésállítógomb
10.Lábvédő
11.Boltibemutatópánt
1
7
9
3
11
6
11
2
4
5
10
7d
7c
7b
7a
10
8
6
7
7e
7f
EN
1. Main seat
2. Restraint system
3. Sliding backrest
4. Belt lock
5. Foot rests
6. Carrier bow
7. Fastening bracket complete
a) Bracket
b) Metal strips
c) Fastening screws
d) Safety indicator
e) Locking pin
f) Key
8. Eccentric shaft
9. Reclining knob
10. Footguard
11. Shop display strap
IT
1. Seggiolino principale
2. Cinture di sicurezza
3. Schienale scorrevole
4. Fibbia
5. Poggiapiedi
6. Staffa di sostegno
7. Attacco completo
a) Attacco
b) Fascette metalliche
c) Viti di fissaggio
d) Indicatore di sicurezza
e) Perno di fermo
f) Chiave
8. Assale eccentrico
9. Manopola di reclinazione
10. Protezione per piedi
11. Fascia di esposizione vendita
NL
1. Hoofdzitje
2. Harnassysteem
3. Verschuifbare rugleuning
4. Riemsluiting
5. Voetsteunen
6. Draagboog
7. Beugelvergrendeling compleet
a) Beugel
b) Metalen strips
c) Bevestigingsschroeven
d) Veiligheidsindicatie
e) Vergrendelingspin
f) Sleutel
8. Excentrische stang
9. Kantelknop
10. Voetsteun
11. Riem voor winkeldisplay
PL
1. Siedzisko
2. System zabezpieczający
3. Oparcie przesuwane
4. Klamra pasów bezpieczeństwa
5. Podpórki na stopy
6. Pałąk mocujący
7. Uchwyt mocujący
a) Klamra
b) Tylna płyta uchwytu mocującego
c) Śruby mocujące
d) Wskaźnik blokady
e) Bolec blokujący
f) Kluczyk
8. Wałek mimośrodowy
9. Pokrętło do ustawiania fotelika w
pozycji leżącej
10. Osłona stóp
11. Uchwyt sklepowy
PT
1. Assento principal
2. Sistema de aperto
3. Encosto deslizante
4. Fivela do cinto
5. Descanso de pés
6. Arco de transporte
7. Componente de fixação completo
a) Suporte
b) Tiras de metal
c) Parafusos para fixar
d) Indicador de segurança
e) Pino de bloqueio
f) Chave
8. Eixo excêntrico
9. Botão de reclinação
10. Proteção de pés
11. Fita da exposição na loja
RO
1. Scaun principal
2. Sistem de fixare
3. Spătar glisant
4. Dispozitiv de blocare centură
5. Suport pentru picioare
6. Bară de sprijin
7. Suport de fixare complet
a) Suport
b) Benzi metalice
c) Şuruburi de fixare
d) Indicator de siguranţă
e) Ştift de blocare
f) Cheie
8. Bară cu excentric
9. Buton de rabatare
10. Protecţie pentru picioare
11. Centură de prezentare
RU
1. Сиденье
2. Система фиксации
3. Подвижная спинка
4. Фиксатор ремня
5. Упоры для ног
6. Дуга багажника
7. Крепежная скоба в комплекте
а.) Скоба
b) Металлические подкладки
с) Крепежные винты
d) Индикатор безопасности
e) Стопорный штифт
f) Ключ
8. Вал эксцентрика
9. Ручка наклона
10. Защитный щиток для ног
11. Лента для подвешивания в
магазине
SE
1. Huvudsäte
2. Fastspänningssystem
3. Glidande ryggstöd
4. Bälteslås
5. Fotstöd
6. Båge
7. Komplett fäste
a) Fäste
b) Metallsektioner
c) Fästskruvar
d) Säkerhetsindikator
e) Låssprint
f) Nyckel
8. Excenteraxel
9. Lutningsvred
10. Fotskydd
11. Rem för butiksvisning
SK
1. Hlavné sedadlo
2. Obmedzovací systém
3. Posuvná opierka chrbta
4. Zámka pásu
5. Opierky na nohy
6. Oblúk nosiča
7. Kompletná upínacia konzola
a) konzola
b) kovové pásy
c) upevňovacie skrutky
d) bezpečnostná kontrolka
e) blokovací kolík
f) drážka
8. Odstredivý hriadeľ
9. Sklápací gombík
10. Ochrana nôh
11. Uchopovací pásik
Produkspesifikasjoner
| Merke: | Hamax |
| Kategori: | Sykkelsete |
| Modell: | Caress C2 |
Trenger du hjelp?
Hvis du trenger hjelp med Hamax Caress C2 still et spørsmål nedenfor, og andre brukere vil svare deg
Sykkelsete Hamax Manualer
14 August 2025
14 August 2025
14 August 2025
13 August 2025
13 August 2025
13 August 2025
13 August 2025
13 August 2025
13 August 2025
Sykkelsete Manualer
Nyeste Sykkelsete Manualer
30 Desember 2025
6 Desember 2024
