Harman Kardon AVR 132 Bruksanvisning
Harman Kardon
Mottaker
AVR 132
Les nedenfor 📖 manual på norsk for Harman Kardon AVR 132 (36 sider) i kategorien Mottaker. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/36
2 TABLE OF CONTENTS
3 Introduction
4 Safety Information
4 Unpacking
5 Front Panel Controls
7 Rear Panel Connections
9 Remote Control Functions
12 Installation and Connections
12 Audio Equipment Connections
13 Video Equipment Connections
14 SCART A/V Connections
14 AC Power Connections
15 Speaker Selection and Placement
16 System Configuration
16 First Turn On
16 Settings to be Made
With Each Input Used
16 Input Setup
16 Speaker Setup
17 Triple Crossover Setting
18 Surround Setup
18 Configuring the Surround Off
(Stereo) Modes
18 Stereo-Direct (Bypass) Mode
19 Stereo Digital Mode
19 Delay Settings
19 Night Mode Settings
19 Output Level Adjustment
21 Operation
21 Basic Operation
21 Source Selection
21 Controls and Use of Headphones
21 Surround Mode Selection
22 Surround Mode Chart
24 Digital Audio Playback
25 Selecting a Digital Source
25 Digital Status Indicators
25 Surround Mode Types
26 Night Mode
26 Tape Recording
26 Output Level Trim Adjustment
27 6-Channel Direct Input
27 Display Brigthness
27 Memory Backup
27 Tuner Operation
28 RDS Operation
29 Programming the Remote
29 Programming the Remote with Codes
29 Code Readout
30 Programmed Device Functions
30 Macro Programming
31 Volume Punch-Through
31
Channel Control Punch-Through
31 Transport Control Punch-Through
31 Resetting the Remote Memory
32 Function List
34 Troubleshooting Guide
34 Processor Reset
35 Technical Specifications
Table of Contents
Typographical Conventions
In order to help you use this manual with the remote control, front-panel controls and rear-panel
connections, certain conventions have been used.
EXAMPLE – (bold type) indicates a specific remote control or front-panel button, or rear-panel
connection jack
EXAMPLE – – (OCR type) indicates a message that is visible on the front-panel information display
– (number in a square) indicates a specific front-panel control
0
– (number in a circle) indicates a rear-panel connection
0
– (number in an oval) indicates a button or indicator on the remote.
Declaration of Conformity
We, Harman Consumer Group International
2, route de Tours
72500 Château-du-Loir,
FRANCE
declare in own responsibility, that the product described in
this owner’s manual is in compliance with technical
standards:
EN 55013:2001 + A1:2003
EN 55020:2002 + A1:2003
EN 61000-3-2:2000
EN 61000-3-3:1995 + A1:2001
EN 60065:2002
Jurjen Amsterdam
Harman Consumer Group International
07/06
29782_AVR132_ENG 29/11/06 12:07 Side 2
Downloaded from www.Manualslib.com manuals search engine
ENGLISH
INTRODUCTION 3
Introduction
Thank you for choosing Harman Kardon!
With the purchase of a Harman Kardon
AVR 132 you are about to begin many years of
listening enjoyment. The AVR 132 has been
custom designed to provide all the excitement
and detail of movie sound tracks and every
nuance of musical selections. With onboard
Dolby* Digital and DTS
†
decoding, the AVR 132
delivers six discrete channels of audio that take
advantage of the digital sound tracks from the
latest DVD and LD releases and Digital Television
broadcasts.
While complex digital systems are hard at work
within the AVR 132 to make all of this happen,
hookup and operation are simple. Color-keyed
connections and a programmable remote con-
trol make the AVR easy to use. To obtain the
maximum enjoyment from your new receiver,
we urge you to take the time to read through
this manual. This will ensure that connections to
speakers, source playback units and other exter-
nal devices are made properly. In addition, a
few minutes spent learning the functions of the
various controls will enable you to take
advantage of all the power the AVR 132 is able
to deliver.
If you have any questions about this product,
its installation or its operation, please contact
your dealer. He is your best local source of
information.
Description and Features
The AVR 132 is among the most versatile and
multi-featured A/V receivers available,
incorporating a wide range of listening options.
In addition to Dolby Digital and DTS decoding
for digital sources, a broad choice of analog
surround modes are available for use with
sources such as CD, VCR, TV broadcasts and the
AVR’s own FM/AM tuner. Along with the latest
Dolby ProLogicII
®
decoding technology, Dolby 3
Stereo, 5 Ch Stereo and custom Hall and Theater
modes, only Harman Kardon receivers offer Logic
7
®
to create a wider, more enveloping field
environment and more defined fly-overs and
pans.
In addition to providing a wide range of listening
options, the AVR 132 is easy to configure so that
it provides the best results with your speakers
and specific listening-room environment.
A Stereo-Direct mode bypasses the digital
processor to preserve all of the subtleties of
older analog, two-channel materials, while bass
management, available in the surround and
Stereo-Digital modes,improves your ability to
tailor the sound to suit your room acoustics or
taste.
For the ultimate in flexibility, the AVR 132
features connections for four video devices, all
with both composite and S-Video inputs,
including the front-panel inputs. Two additional
audio inputs are available, and a total of six
digital inputs make the AVR 132 capable of
handling all the latest digital audio sources.
A video recording output and a six-channel
input make the AVR 132 virtually future-proof,
with everything needed to accommodate
tomorrow’s new formats right on board.
The AVR 132’s powerful amplifier uses
traditional Harman Kardon high-current design
technologies to meet the wide dynamic range of
any program selection.
Harman Kardon invented the high-fidelity
receiver fifty years ago. With state-of-the-art cir-
cuitry and time-honored circuit designs, the
AVR 132 is one of the finest receivers ever
offered by Harman Kardon within its price range.
■ Onboard Dolby Digital and DTS
Decoding Using Crystal
®
Chip
Technology
■ Harman Kardon’s exclusive Logic 7
®
processing, along with a choice of
Dolby Virtual Speaker processing for
use when only two speakers are
available
■ Dolby Headphone to create spacious,
open sound fields when using head-
phones
■ Dolby Laboratory's latest ProLogic II
decoding technology.
■ Stereo-Direct Mode for Two-Channel
Sources Bypasses DSP Processing to
Preserve the Integrity of Analog
Materials
■ Stereo-Digital Mode for Programmable
Bass Management of Low Frequencies
Between Main Speakers and
Subwoofer
■ Front panel digital inputs for easy
connection to portable digital devices
and the latest video game consoles
■ Multiple Digital Inputs
■ 6-Channel Direct Input for Use With
DVD-Audio or SACD Players and Other
Products With Internal Surround
Decoders
■ Color-Coded Input,Output and Speaker
Terminals Comply With CEA Standards
for Easy Installation
■ Remote with Internal Codes Capability
■ High-bandwidth, HDTV-compatible
component video switching
■ Input titling for all input sources
(except tuner)
29782_AVR132_ENG 29/11/06 12:07 Side 3
Downloaded from www.Manualslib.com manuals search engine
