DIGITAL LOGIC 7

VID 1

DVD

FMAM

TAPE

6 8 CH

VID 2

VID 3

PRO LOGIC

3 STEREO DSP

5 CH. STEREO

SURR. OFF

AVR 135

AUDIO/VIDEO RECEIVER

OWNER’S MANUAL

Power for the Digital Revolution

®



AVR 135 OM 12/3/04 12:11 PM Page 1

AVR 135 AUDIO/VIDEO RECEIVER

3 Introduction

4 Important Safety Infor

mation

4 Unpacking

5 Front-Panel Controls

7 Rear-Panel Connections

9 Remote Control Functions

12 Installation and Connections

14 System Configuration

14 Speaker Selection and Placement

14 System Setup

16 Input Setup

16 Surround Setup

17 Speaker Setup

19 Delay Settings

20 Output Level

Adjustment

22 Operation

22 Basic Operation

22 Source Selection

22 6-Channel/8-Channel Direct Input

22 Volume Control

22 Surround Mode Selection

23 Digital Audio Playback

24 Surround Mode Chart

26 Tuner Operation

27 Recording

27 Output Level Trim Adjustment

28 Advanced Features

28 Front-Panel-Display Fade

28 Display Brightness

28 Turn-On Volume Level

29 Semi-OSD Settings

29 Full-OSD Time-Out Adjustment

30 Programming the Remote

30 Programming Device Codes

30 Direct Code Entry

30 Auto Search Method

30 Code Readout

30 Macro Programming

31 Programmed Device Functions

32 V

olume Punch-Through

32 Channel Control Punch-Through

32 Transport Control Punch-Through

32 Resetting the Remote Memory

33 Function List

35 Setup Code Tables

45 Troubleshooting Guide

45 Processor Reset

46 Technical Specifications

46 Trademark Acknowledgements

47 Index

2 TABLE OF CONTENTS

Typographical Conventions

In order to help you use this manual with the remote control, front-panel controls and rear-panel connections,

certain conventions have been used.

EXAMPLE – (bold type) indicates a specific remote control or front-panel button, or rear-panel

connection jack

EXAMPLE – (OCR type) indicates a message that is visible on-screen or on the front-panel

information display

1 – (number in a square) indicates a specific front-panel control

¡ – (number in a circle) indicates a rear-panel connection

a – (number in an oval) indicates a button or indicator on the remote

AVR 135 OM 12/3/04 12:11 PM Page 2

INTRODUCTION

Thank you for choosing Harman Kardon

! With

the purchase of a Harman Kardon AVR 135, you are

about to begin many years of listening enjoyment.

Designed to provide all the excitement and detail of

movie soundtracks and

ever

y nuance of musical selec-

tions, the AVR 135

accomplishes its mission by har-

nessing advanced technologies usually found only in

higher-priced receivers.

The AVR 135 has been engineered so that it is easy

to take advantage of all the power of its digital tech-

nology. However, to obtain the maximum enjoyment

from your new receiver, we urge you to read this

manual. A few minutes spent learning the functions of

the various controls will enable you to take advantage

of all the power the AVR 135 is able to deliver.

If you have any questions about this product,

its instal-

lation or its operation, please contact your retailer or

custom installer. They are your best local sources of

information.

Description and Features

The AVR 135 is versatile and multifeatured, incorpo-

rating a wide range of listening options. In addition to

Dolby

* Digital and DTS

decoding for digital sources,

a broad choice of Matrix surround-encoded or Stereo

surround modes are available for use with sources

such as CD, VCR, TV broadcasts and the AVR 135’s

own FM/AM tuner. Along with Dolby Digital EX, Dolby

Pro Logic

* II, DTS Neo:6

, Dolby 3 Stereo, and Hall

and Theater modes, the AVR 135 offers Harman

International’s exclusive Logic 7

processing in both

5.1 and 7.1 versions to create a wider, more enveloping

field environment and more defined fly-overs and pans.

Another exclusive is VMAx

, which uses proprietary

processing to create an open,

spacious sound field

even when only two front speakers are available.

In addition to providing a wide range of listening

options, the AVR 135 is easy to configure so that it

provides the best results with your speakers and spe

cific listening-room environment. On-screen menus

make it simple to enter settings for speaker configura-

tions and bass management.

For the ultimate in flexibility, the AVR 135 features

connections for four video devices, all with both com-

posite and S-video inputs. Two additional audio inputs

are available

, and six digital inputs make the AVR 135

capable of handling all the latest digital audio sources

For compatibility with the latest HDTV video sources

and progressive scan DVD players, the AVR 135 also

features two-input, wide-bandwidth, low-crosstalk

component video switching

The front panel offers coax and optical digital inputs

for direct connection to digital recorders. A video

recording output, preamp-out and a color-coded

eight-channel input, with complete digital bass man-

agement,

make the AVR 135 virtually future-proof, with

everything needed to accommodate tomorrow’s new

formats right onboard.

The AVR 135’s powerful amplifier uses traditional

Harman Kardon high-current design technologies

to meet the wide dynamic range of any program

selection.

Harman Kardon invented the high-fidelity receiver

more than fifty years ago. With

state-of-the-art circuitry

and time-honored circuit designs, the AVR 135 is the

perfect combina

tion of the latest in digital audio tech-

nology, a

quiet yet powerful analog amplifier in an

ele-

gant, easy-to-use package.

For Canadian model

Modèle pour les Canadien

n A wide range of digital and matrix surround

modes, including Dolby

Digital, Dolby Digital EX

Dolby Pro Logic

II, DTS

, DTS-ES

Discrete and

trix, and DTS Neo:6

n Six channels of high-current amplification

Harman Kardon’s exclusive Logic 7

processing

vailable for the first time with both 7.1 and

5.1 processing in a variety of modes, and two

modes of VMAx

n High-bandwidth, HDTV-compatible component

video s

witching

n Discrete front-panel coaxial and optical digital

inputs for easy connection to portable digital

devices and video game consoles

n Extensive bass management options, includ-

ing three separate crossover groupings

n On-screen menu and display system

Cet appareil numérique de la classe B est conforme

à la norme NMB-003 du Canada.

Sur les modèles dont la fiche est polarisee:

ATTENTION: Pour éviter les chocs électriques, introduire

la lame la plus large de la fiche dans la borne

correspondante de la prise et pousser jusqu’au fond.

This class B digital apparatus complies with Canadian

ICES-003.

For models having a power cord with a polarized plug:

CAUTION: To prevent electric shock, match wide blade

of plug to wide slot, fully insert.

INTRODUCTION 3

AVR 135 OM 12/3/04 12:11 PM Page 3
