ENGLISH

AVR 155 Audio/ Video Receiver

OWNER’S MANUAL

2 TABLE OF CONTENTS

3 Introduction

4 Safety Information

4 Unpacking

5 Front Panel Controls

7 Rear Panel Connections

9 Main Remote Control Functions

13 Installation and Connections

13 Audio Connections

13 Video Connections

14 HDMI Connections

14 SCART A/V Connections

15 Power Connections

16 Speaker Selection

16 Speaker Placement

17 System Configuration

17 First Turn On

17 Using the On-Screen Display

17 System Setup

18 Input Setup

19 Surround Setup

19 Night Mode Settings

20 Configuring the Surround Off

(Stereo) Modes

21 Automated Speaker Setup Using EzSet/EQ

23 Manual Setup

23 Speaker Setup

26 Delay Settings

27 Output Level Adjustment

30 Operation

30 Surround Mode Chart

32 Basic Operation

32 Source Selection

32 6-Channel Direct Input

32 Controls and Use of Headphones

33 Surround Mode Selection

33 Digital Audio Playback

33 Dolby Digital

33 DTS

34 PCM Audio Playback

34 Selecting a Digital Source

34 Digital Bitstream Indicators

34 Surround mode Types

35 Surround Mode Post Processing

35 PCM Playback Indications

35 Speaker/Channel Indicators

36 Night Mode

37 Tape Recording

37 Output Level Adjustment

With Source Signals

38 Dim function

38 Memory backup

39 System Setup

39 Front Panel Display Fade

39 Turn-On Volume Level

39 Semi-OSD Settings

40 Full-OSD Time Out Adjustment

40 Default Surround Mode

40 Full-OSD Background Color

41 Tuner Operation

41 Basic Tuner Operation

41 Station Selection

41 Preset Tuning

42 RDS Operation

42 RDS Tuning

42 RDS Display Options

42 Program Search (PTY)

43 Programming the Remote

43 Programming the Remote with Codes

Table of Contents

Typographical Conventions

In order to help you use this manual with the remote control, front-panel controls and rear-panel

connections, certain conventions have been used.

EXAMPLE – (bold type) indicates a specific remote control or front-panel button, or rear-panel

connection jack

EXAMPLE – (OCR type) indicates a message that is visible on the front-panel information display

– (number in a square) indicates a specific front-panel control

– (number in a circle) indicates a rear-panel connection

– (number in an oval) indicates a button or indicator on the remote

The appearance of the text or cursor for your receiver’s on-screen menus may vary slightly from the

illustrations in this manual. Whether the text appears in all uppercase or upper- and lowercase

characters, performance and operation remain the same.

Declaration of Conformity

We, Harman Consumer Group, Inc.

2, route de Tours

72500 Château-du-Loir,

FRANCE

declare in own responsibility, that the product

described in this owner’s manual is in compliance

with technical standards:

EN 55013:2001 + A1:2003

EN 55020:2002 + A1:2003

EN 61000-3-2:2000

EN 61000-3-3:1995 + A1:2001

EN 60065:2002

Jurjen Amsterdam

Harman Consumer Group, Inc.

02/08

43 Direct Code Entry

43 Auto Search Method

43 Code Readout

44 Macro Programming

44 Programmed Device Functions

44 Volume Punch-Through

45 Channel Control Punch-Through

45 Transport Control Punch-Through

45 Resetting the Remote Memory

46 Function List

48 Troubleshooting Guide

48 Processor Reset

49 Technical Specifications

50 Appendix - Settings Worksheet

INTRODUCTION 3

ENGLISH

Introduction

Thank you for choosing Harman Kardon!

With the purchase of a Harman Kardon AVR 155

you are about to begin many years of listening

enjoyment. Designed to provide all the excitement

and detail of movie soundtracks and every nuance

of musical selections, the AVR is truly a multichan-

nel receiver for the new millennium. In addition to

the traditional 5.1 digital decoding modes such as

Dolby Digital and DTS, it offers the latest advance-

ments in surround technology such as Dolby Pro

Logic II, the full suite of DTS modes, DTS Neo:6

and the latest 5.1 channel versions of Harman's

own Logic 7 technology.

The AVR has been engineered so that it is easy

to take advantage of all the power of its digital

technology. On-screen menus, fully color coded

connection jacks and terminals make installation

fast and simple. However, to obtain the maxi-

mum enjoyment from your new receiver, we urge

you to read this manual. A few minutes spent

learning the functions of the various controls will

enable you to take advantage of all the power

the AVR is able to deliver.

If you have any questions about this product, its

installation or its operation, please contact your

retailer or custom installer. They are your best

local sources of information.

Description and Features

The AVR 155 is among the most versatile and

multifeatured A/V receivers available, incorpora-

ting a wide range of listening options. In addition

to Dolby Digital and DTS decoding for digital

sources, a broad choice of surround modes for

Matrix surround-encoded or Stereo recordings are

available for use with sources such as CD, VCR, TV

broadcasts and the AVR’s own FM/AM tuner.

Along with Dolby Digital, Dolby Pro Logic II, DTS

Neo:6, DTS 96/24, Dolby 3 Stereo, 5 Channel

Stereo and Hall and Theater modes, the AVR offers

Harman International’s exclusive Logic 7 process

in 5.1 versions to create a wider, more enveloping

field environment and more defined fly-overs and

pans.

Dolby Virtual Speaker is available to create

enveloping sound fields from front left and right

speakers, and the latest Dolby Headphone

circuitry creates an amazing sense of openness

with headphones.

In addition to providing a wide range of listening

options, the AVR is easy to configure so that it

provides the best results with your speakers and

specific listening-room environment.

A Stereo-Direct mode bypasses the digital proces-

sor to preserve all of the subtleties of older analog,

two-channel materials, while bass management,

available in the surround and Stereo-Digital

modes,improves your ability to tailor the sound to

suit your room acoustics or taste.

The AVR 155 takes the “video” part of its name

seriously. Along with three HDMI inputs and two

100MHz analog component video inputs, the

AVR 155 provides A/V sync delay so that the lip

sync errors – commonly seen when digital video

processing is used in a source, program or video

display – are eliminated. For the ultimate in flexi-

bility, the AVR features connections for three video

devices, all with both composite and S-Video

inputs. Two additional audio inputs are available,

and a total of four digital inputs and two outputs

make the AVR 155 capable of handling all the

latest digital audio sources.

For compatibility with the latest HDTV video

sources and progressive scan DVD players, the

AVR also features wide-bandwidth, low-crosstalk

component video switching.

Coax and optical digital outputs are available for

direct connection to digital recorders. A video

recording output and a color-coded six-channel

input make the AVR 155 virtually future-proof,

with everything needed to accommodate to -

morrow’s new formats right on board.

An important addition to the AVR 155’s impres-

sive list of features is EzSet/EQ

™

, which auto-

mates the configuration process to make it quick-

er, easier and more precise. Using the special

microphone supplied with the unit, EzSet/EQ

takes the guesswork out of entering speaker

“size” and crossover information, delay times for

all channels and output levels. In addition to the

configuration settings, EzSet/EQ also includes

room equalization so that the signals sent to

each speaker are tailored to provide accurate

sonic quality with your specific combination of

speaker type, room size and other factors that

influence room acoustics. With EzSet/EQ, your

system is custom-configured in a few minutes

with accuracy that previously required expensive

and hard-to-use test equipment.

In tandem with EzSet/EQ, the AVR 155 includes a

full set of manual configuration settings for those

who wish to custom-trim their system even fur-

ther. A Triple Crossover bass management system

makes it possible to enter different crossover set-

tings for each speaker group.

The AVR 155’s powerful amplifier uses traditi onal

Harman Kardon high-current design technologies

to meet the wide dynamic range of any program

selection.

Harman Kardon invented the high- fidelity receiver

more then fifty years ago. With state-of-the-art

circuitry and time-honored circuit designs, the

AVR 155 is the perfect combination of the latest

in digital audio technology, a quiet yet powerful

analog amplifier in an elegant, easy-to-use pack-

age.

n Dolby* Digital, Dolby Pro Logic* II

Decoding, and DTS

n Five channels of high-current

amplification

n Harman Kardon’s exclusive Logic 7

pro-

cessing, along with a choice of Dolby

Virtual Speaker processing for use when

only two speakers are available

n Dolby Headphone to create spacious,

open sound fields when using head-

phones

n Harman Kardon’s advanced EzSet/EQ

™

automatically configures speaker set-

tings and sets room equalization for

quick, easy and accurate system setup

n Three HDMI 1.3 and two assignable

high-bandwidth analog component

inputs for compatibility with the latest

high-definition video sources

n Stereo-Direct Mode for Two-Channel

Sources Bypasses DSP Processing to

Preserve the Integrity of Analog

Materials

n Stereo-Digital Mode for Programmable

Bass Management of Low Frequencies

Between Main Speakers and Subwoofer

n Front panel analog A/V inputs

n Front panel digital inputs for easy con-

nection to portable digital devices and

the latest video game consoles

n Input titling for all input sources (except

tuner)

n Multiple digital inputs and outputs

n On-screen menu and display system

with choice of blue or black background

screen

n A/V Sync delay adjustable for each input

delivers perfect lip sync with digital

programs or video displays

n 6-Channel Direct Input for Use with

Future Audio Formats

n Extensive bass management options,

including three separate crossover

groupings

n Main Remote with Internal Codes

Produkspesifikasjoner

Merke:	Harman Kardon
Kategori:	Mottaker
Modell:	AVR 155
Vekt:	11100 g
Bredde:	440 mm
Dybde:	382 mm
Høyde:	165 mm
Wi-Fi:	Nei
Hodetelefonutganger:	1
3D:	Nei
Impedans:	8 Ω
HDMI inn:	3
Antall HDMI-utganger:	1
AC-inngangsspenning:	230 V
AC-inngangsfrekvens:	50 Hz
AirPlay:	Nei
Produktfarge:	Sort, sølv
Komponentvideo (YPbPr/YCbCr) inn:	3
Innebygd kortleser:	Nei
Fjernkontroll medfølger:	Ja
Signal-til-støy-forhold (SNR):	100 dB
Antall S-Video-innganger:	1
Optisk stasjon inkludert:	Nei
Total Harmonic Distortion (THD):	0.07
Ethernet/bredbåndsforbindelse:	Nei
Lyd-utgang kanaler:	5.1 kanaler
Mottakertype:	Surround
Støttede radiobånd:	AM, FM
Utjevner/frekvenskorrigerer:	Ja
Antall forhåndsinnstallerte stasjoner:	30
Innebygd lyddekoder:	Dolby Digital, Dolby Pro Logic II, Dolby TrueHD, DTS
Digital koaksialutgang for lyd:	1
Apple docking-kompabilitet:	Støttes ikke
Lyd D/A-konverterer (DAC):	24-bit/192kHz
Digital optisk lydinngang:	3
Effekt pr. kanal (20-20KHz@8 Ohm):	40 W
Digital koaksialinngang for lyd:	3
