Side 1/42

AVR 1650/AVR 165

Audio/video receiver

Owner’s Manual

ENGLISH

AVR 1650/AVR 165 Table of Contents

INTRODUCTION 3

SUPPLIED ACCESSORIES 3

IMPORTANT SAFETY INFORMATION 3

PLACE THE AVR 3

FRONT-PANEL CONTROLS 4

REAR-PANEL CONNECTORS 6

SYSTEM REMOTE CONTROL FUNCTIONS 8

INTRODUCTION TO HOME THEATER 10

TYPICAL HOME THEATER SYSTEM 10

MULTICHANNEL AUDIO 10

SURROUND MODES 10

PLACE YOUR SPEAKERS 10

PLACING THE LEFT, CENTER AND RIGHT SPEAKERS 10

PLACING THE SURROUND SPEAKERS 10

PLACING THE SUBWOOFER 10

TYPES OF HOME THEATER SYSTEM CONNECTIONS 11

SPEAKER CONNECTIONS 11

SUBWOOFER CONNECTIONS 11

SOURCE DEVICE CONNECTIONS 11

VIDEO CONNECTIONS 12

RADIO CONNECTIONS 12

USB PORT 12

MAKING CONNECTIONS 13

CONNECT YOUR SPEAKERS 13

CONNECT YOUR SUBWOOFER 13

CONNECT YOUR TV OR VIDEO DISPLAY 13

CONNECT YOUR SOURCE DEVICES 13

CONNECT THE BRIDGE IIIP 15

CONNECT THE RADIO ANTENNAS 15

CONNECT IR EQUIPMENT 15

CONNECT THE 12V TRIGGER OUTPUT 16

CONNECT TO AC POWER 16

SET UP THE REMOTE CONTROL 16

INSTALL THE BATTERIES IN THE REMOTE CONTROL 16

PROGRAM THE REMOTE TO CONTROL YOUR SOURCE

DEVICES AND TV 16

SET UP THE AVR 17

TURN ON THE AVR 17

USING THE ON-SCREEN MENU SYSTEM 17

CONFIGURE THE AVR FOR YOUR SPEAKERS 17

ASSIGN THE DIGITAL AUDIO CONNECTORS 18

ADDITIONAL INPUT SETUP MENU ITEMS 18

OPERATING YOUR AVR 19

CONTROLLING THE VOLUME 19

MUTING THE SOUND 19

LISTENING THROUGH HEADPHONES 19

SELECTING A SOURCE 19

LISTENING TO FM AND AM RADIO 19

LISTENING TO AN iPod/iPhone DEVICE 19

VIDEO TROUBLESHOOTING TIPS 19

SELECTING A SURROUND MODE 20

ADVANCED FUNCTIONS 20

AUDIO PROCESSING AND SURROUND SOUND 20

MANUAL SPEAKER SETUP 21

SYSTEM SETUP 23

ADVANCED REMOTE CONTROL PROGRAMMING 24

RECORDING 24

SLEEP TIMER 24

RESETTING THE REMOTE 24

PROCESSOR RESET 24

MEMORY 24

TROUBLESHOOTING 25

SPECIFICATIONS 26

APPENDIX 27

AVR 1650/AVR 165

ENGLISH

Introduction, Supplied Accessories,

Important Safety Information and Place the AVR

Introduction

Thank you for choosing this Harman Kardon product!

For more than ﬁfty years, the Harman Kardon mission has been to share a passion for music

and entertainment, using leading-edge technology to achieve premium performance.

Sidney Harman and Bernard Kardon invented the receiver, a single component designed

to simplify home entertainment without compromising performance. Over the years,

Harman Kardon products have become easier to use while offering more features and

sounding better than ever.

The AVR 1650 and AVR165 5.1-channel digital audio/video receivers (AVRs) continue

this tradition with some of the most advanced audio and video processing capabilities

yet and a wealth of listening and viewing options.

To obtain the maximum enjoyment from your new AVR, please read this manual and

refer back to it as you become more familiar with its features and their operation.

If you have any questions about this product, its installation or its operation, please

contact your Harman Kardon retailer or custom installer, or visit our Web site at www.

harmankardon.com.

Supplied Accessories

The following accessory items are supplied with your AVR. If any of these items are

missing, please contact your Harman Kardon dealer, or Harman Kardon customer service

at www.harmankardon.com.

System remote control •

EzSet/EQ •

™

microphone

AM loop antenna •

FM wire antenna •

Three • AAA batteries

AC power cord •

IMPORTANT SAFETY INFORMATION

Verify Line Voltage Before Use

The AVR 1650 has been designed for use with 120-volt alternating current (AC). The

AVR 165 has been designed for use with 220 – 240-volt AC. Connection to a line voltage

other than that for which your AVR is intended can create a safety and ﬁre hazard, and

may damage the unit. If you have any questions about the voltage requirements for your

speciﬁc model or about the line voltage in your area, contact your selling dealer before

plugging the unit into a wall outlet.

Do Not Use Extension Cords

To avoid safety hazards, use only the power cord supplied with your unit. We do not

recommend that extension cords be used with this product. As with all electrical devices,

do not run power cords under rugs or carpets, or place heavy objects on them. Damaged

power cords should be replaced immediately by an authorized service center with a cord

meeting factory speciﬁcations.

Handle the AC Power Cord Gently

When disconnecting the power cord from an AC outlet, always pull the plug; never

pull the cord. If you do not intend to use your AVR for any considerable length of time,

disconnect the plug from the AC outlet.

Do Not Open the Cabinet

There are no user-serviceable components inside this product. Opening the cabinet may

present a shock hazard, and any modiﬁcation to the product will void your warranty. If

water or any metal object such as a paper clip, wire or staple accidentally falls inside

the unit, disconnect it from the AC power source immediately, and consult an authorized

service center.

CATV or Antenna Grounding (AVR 1650)

If an outside antenna or cable system is connected to this product, be certain that it is

grounded so as to provide some protection against voltage surges and static charges.

Section 810 of the United States National Electrical Code, ANSI/NFPA No. 70-1984,

provides information with respect to proper grounding of the mast and supporting

structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding

conductors, location of antenna discharge unit, connection to grounding electrodes and

requirements of the grounding electrode.

NOTE TO CATV SYSTEM INSTALLER: This reminder is provided to call the CATV (cable

TV) system installer’s attention to article 820-40 of the NEC, which provides guidelines

for proper grounding and, in particular, speciﬁes that the cable ground shall be connected

to the grounding system of the building, as close to the point of cable entry as possible.

Place the AVR

Place the AVR on a ﬁrm and level surface. Be certain that the surface and any mounting •

hardware can support the AVR’s weight.

Provide proper space above and below the AVR for ventilation. If you install the AVR in •

a cabinet or other enclosed area, provide cooling air within the cabinet. Under some

circumstances, a fan may be required.

Do not obstruct the ventilation slots on the top of the AVR or place objects directly •

over them.

Do not place the AVR directly on a carpeted surface. •

Do not place the AVR in moist or humid locations, in extremely hot or cold locations, in •

areas near heaters or heat registers, or in direct sunlight.

Produkspesifikasjoner

Merke:	Harman Kardon
Kategori:	Mottaker
Modell:	AVR 165
Vekt:	9100 g
Bredde:	440 mm
Dybde:	385 mm
Høyde:	165 mm
Wi-Fi:	Nei
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
3D:	Ja
HDMI inn:	4
FM-bånd:	87.5 - 108 MHz
AC-inngangsspenning:	230 V
AC-inngangsfrekvens:	50 - 60 Hz
AirPlay:	Nei
Produktfarge:	Sort
Strømforbruk (vanlig bruk):	280 W
Komponentvideo (YPbPr/YCbCr) inn:	1
Innebygd kortleser:	Nei
Fjernkontroll medfølger:	Nei
Signal-til-støy-forhold (SNR):	100 dB
Optisk stasjon inkludert:	Nei
Total Harmonic Distortion (THD):	0.07
Ethernet/bredbåndsforbindelse:	Nei
Lyd-utgang kanaler:	5.1 kanaler
Komposittvideo inn/sammensatt video inn:	1
RMS-rangert strøm/utgangseffekt:	- W
Display:	LCD
Støttede radiobånd:	AM, FM
AM båndbredde:	520 - 1620 kHz
Innebygd lyddekoder:	Dolby Digital Plus, Dolby TrueHD, DTS, DTS-HD
Frekvensrekkevidde:	20 - 20000 Hz
Apple docking-kompabilitet:	Støttes ikke
Effekt pr. kanal (20-20KHz@8 Ohm):	95 W
Effekt pr. kanal (1KHz@8 Ohm):	95 W
