Audio/video receiver
AVR 1710S, AVR 171S, AVR 171S/230C
AVR 1610S, AVR 161S, AVR 161S/230C
Owner’s Manual
ENGLISH
AVR
Table of Contents
2
INTRODUCTION 3
SUPPLIED ACCESSORIES 3
IMPORTANT SAFETY INFORMATION 3
PLACE THE AVR 3
FRONT-PANEL CONTROLS 4
REAR-PANEL CONNECTORS 6
SYSTEM REMOTE CONTROL FUNCTIONS 8
INTRODUCTION TO HOME THEATER 10
TYPICAL HOME THEATER SYSTEM 10
MULTICHANNEL AUDIO 10
SURROUND MODES 10
PLACE YOUR SPEAKERS 11
PLACING THE LEFT, CENTER AND RIGHT SPEAKERS 11
PLACING THE SURROUND SPEAKERS IN A 5.1-CHANNEL
SYSTEM 11
AVR 1710S/AVR 171S ONLY: PLACING THE SURROUND
SPEAKERS IN A 7.1-CHANNEL SYSTEM 11
AVR 1710S/AVR 171S ONLY: PLACING FRONT HEIGHT
SPEAKERS IN A 7.1-CHANNEL SYSTEM 11
PLACING THE SUBWOOFER 11
TYPES OF HOME THEATER SYSTEM CONNECTIONS 12
SPEAKER CONNECTIONS 12
SUBWOOFER CONNECTIONS 12
SOURCE DEVICE CONNECTIONS 12
VIDEO CONNECTIONS 13
RADIO CONNECTIONS 13
NETWORK CONNECTOR 14
USB PORT 14
MAKING CONNECTIONS 14
CONNECT YOUR SPEAKERS 14
CONNECT YOUR SUBWOOFER 15
CONNECT YOUR TV OR VIDEO DISPLAY 15
CONNECT YOUR AUDIO AND VIDEO SOURCE DEVICES 16
USB AND IOS DEVICES 18
CONNECT TO YOUR HOME NETWORK 18
CONNECT THE RADIO ANTENNAS 18
INSTALL A MULTIZONE SYSTEM 19
CONNECT IR EQUIPMENT 20
CONNECT THE TRIGGER OUTPUT 20
CONNECT TO AC POWER 20
SET UP THE REMOTE CONTROL 21
INSTALL THE BATTERIES IN THE REMOTE CONTROL 21
PROGRAM THE REMOTE TO CONTROL YOUR SOURCE
DEVICES AND TV 21
SET UP THE AVR 22
TURN ON THE AVR 22
USING THE ON-SCREEN MENU SYSTEM 22
CONFIGURE THE AVR FOR YOUR SPEAKERS 22
SET UP YOUR SOURCES 23
SET UP THE NETWORK 24
OPERATING YOUR AVR 25
HARMAN REMOTE APP 25
CONTROLLING THE VOLUME 25
MUTING THE SOUND 25
LISTENING THROUGH HEADPHONES 25
SELECTING A SOURCE 25
SELECTING A SURROUND MODE 25
LISTENING TO FM AND AM RADIO 26
LISTENING TO MEDIA ON A USB DEVICE 26
LISTENING TO AN IPOD/IPHONE/IPA D DEVICE 27
LISTENING TO VTUNER (INTERNET RADIO) 28
LISTENING TO MEDIA VIA YOUR HOME NETWORK 28
PLAYI NG MEDIA FROM A ROKU STREAMING STICK 29
LISTENING TO MEDIA VIA SPOTIFY CONNECT 29
USING THIS DEVICE WITH SPOTIFY CONNECT 29
ADVANCED FUNCTIONS 29
AUDIO PROCESSING AND SURROUND SOUND 29
MANUAL SPEAKER SETUP 30
LISTENING IN ZONE 2 33
SYSTEM SETTINGS 34
SLEEP TIMER 34
PROCESSOR RESET 34
TROUBLESHOOTING 35
SPECIFICATIONS 36
APPENDIX 37
AVR
ENGLISH
Introduction, Supplied Accessories,
Important Safety Information and Place the AVR
3
Introduction
Thank you for choosing this Harman Kardon product!
For more than fifty years, the Harman Kardon mission has been to share a passion for music
and entertainment, using leading-edge technology to achieve premium performance.
Sidney Harman and Bernard Kardon invented the receiver, a single component designed
to simplify home entertainment without compromising performance. Over the years,
Harman Kardon products have become easier to use, while offering more features and
sounding better than ever.
The AVR 1710S/AVR 171S 7.2-channel and AVR 1610S/AVR 161S 5.1-channel digital
audio/ video receivers (AVRs) continue this tradition with some of the most advanced
audio and video processing capabilities yet, and a wealth of listening and viewing options.
To obtain the maximum enjoyment from your new AVR, please read this manual and
refer back to it as you become more familiar with its features and their operation.
If you have any questions about this product, its installation or its operation, please
contact your Harman Kardon retailer or custom installer, or visit the Web site at
www.harmankardon.com.
Supplied Accessories
The following accessory items are supplied with your AVR. If any of these items are
missing, please contact your Harman Kardon dealer or Harman Kardon customer service
at www.harmankardon.com.
• System remote control
• EzSet/EQ™ microphone
• AM loop antenna
• FM wire antenna
• Two AAA batteries
• AC power cord (AVR 171S/AVR 161S only)
IMPORTANT SAFETY INFORMATION
Verify Line Voltage Before Use
The AVR 1710S and AVR 1610S have been designed for use with 120-volt alternating
current (AC). The AVR 171S and AVR 161S have been designed for use with 220 – 240-volt
AC. Connection to a line voltage other than that for which your receiver is intended can
create a safety and fire hazard and may damage the unit. If you have any questions
about the voltage requirements for your specific model, or about the line voltage in your
area, contact your selling dealer before plugging the unit into a wall outlet.
Do Not Use Extension Cords
To avoid safety hazards, use only the power cord supplied with your unit. We do not
recommend that extension cords be used with this product. As with all electrical devices,
do not run power cords under rugs or carpets, or place heavy objects on them. Damaged
power cords should be replaced immediately by an authorized service center with a cord
meeting factory specifications.
Handle the AC Power Cord Gently
When disconnecting the power cord from an AC outlet, always pull the plug; never
pull the cord. If you do not intend to use your AVR for any considerable length of time,
disconnect the plug from the AC outlet.
Do Not Open the Cabinet
There are no user-serviceable components inside this product. Opening the cabinet may
present a shock hazard, and any modification to the product will void your warranty.
If water or any metal object such as a paper clip, wire or staple accidentally falls inside
the unit, disconnect it from the AC power source immediately, and consult an authorized
service center.
CATV or Antenna Grounding (AVR 1710S/AVR 1610S)
If an outside antenna or cable system is connected to this product, be certain that it is
grounded so as to provide some protection against voltage surges and static charges.
Section 810 of the United States National Electrical Code, ANSI/NFPA No. 70-1984,
provides information with respect to proper grounding of the mast and supporting
structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding
conductors, location of antenna discharge unit, connection to grounding electrodes and
requirements of the grounding electrode.
NOTE TO CATV SYSTEM INSTALLER: This reminder is provided to call the CATV (cable TV)
system installer’s attention to article 820-40 of the NEC, which provides guidelines for
proper grounding and, in particular, specifies that the cable ground shall be connected
to the grounding system of the building, as close to the point of cable entry as possible.
Place the AVR
• Place the AVR on a firm and level surface. Be certain that the surface and any
mounting hardware can support the AVR’s weight.
• Provide proper space above and below the AVR for ventilation. Recommended
clearance distances are 30cm above the unit, 30cm behind the unit and 30cm on
each side of the unit.
• If you install the AVR in a cabinet or other enclosed area, provide cooling air within
the cabinet. Under some circumstances, a fan may be required.
• Do not obstruct the ventilation slots on the top of the AVR or place objects directly
over them.
• Do not place the AVR directly on a carpeted surface.
• Do not place the AVR in moist or humid locations, in extremely hot or cold locations,
in areas near heaters or heat registers, or in direct sunlight.
