AVR 520 Audio/VideoReceiver

OWNER’S MANUAL

Power for the Digital Revolution.

2 TABLE OF CONTENTS

3 Introduction

4 Safety Information

4 Unpacking

5 Front Panel Controls

8 Front Panel Information Display

10 Rear Panel Connections

12 Main Remote Control Functions

15 Zone II Remote Control Functions

16 Installation and Connections

18 System Configuration

18 Speaker Placement

19 System Setup

20 Input Setup

20 Surround Setup

22 Speaker Setup

23 Delay Settings

24 Output Level Adjustment

25 Manual Output Level Adjustment

26 Operation

26 Surround Mode Chart

28 Basic Operation

28 Source Selection

28 Surround Mode Selection

29 Digital Audio Playback

31 Tuner Operation

32 Tape Recording

32 Front Panel Input/Output

Connections

32 Output Level Trim Adjustment

33 6/8-Channel Direct Input

34 Advanced Features

34 Display Brightness

34 Turn-On Volume Level

34 Semi-OSD Settings

36 Multiroom Operation

37 Programming the Remote

37 Direct Code Entry

37 Auto Search Method

37 Code Readout

37 Learning Codes

38 Erasing Learned Codes

38 Macro Programming

39 Programmed Device Functions

40 Volume Punch-Through

40 Channel Control Punch-Through

41 Reassigning Device Control

Selectors

42 Function List

44 Setup Code Tables

54 Troubleshooting Guide

54 Processor Reset

55 Technical Specifications

AVR 520 Audio/Video Receiver

Typographical Conventions

In order to help you use this manual with the remote control, front panel controls and rear panel

connections, certain conventions have been used.

EXAMPLE – (bold type) indicates a specific remote control or front panel button, or rear panel

connection jack

EXAMPLE – (OCR type) indicates a message that is visible on-screen or on the front panel

information display

1 – (number in a square) indicates a specific front panel control

¡ – (number in a circle) indicates a rear panel connection

a – (number in an oval) indicates a button or indicator on the remote

A – (letter in a square) indicates an indicator in the front panel display

– (letter in an oval) indicates a button on the Zone II remote

3 INTRODUCTION

Introduction

Thank you for choosing Harman Kardon!

With the purchase of a Harman Kardon

AVR 520 you are about to begin many years of

listening enjoyment. Designed to provide all the

excitement and detail of movie soundtracks and

every nuance of musical selections, the AVR 520

is truly a multichannel receiver for the new mil-

lenium.

The AVR 520 has been engineered so that it is

easy to take advantage of all the power of its

digital technology. On-screen menus, fully color

coded connection jacks and terminals and our

exclusive EzSet

™

remote make installation fast

and simple. However, to obtain the maximum

enjoyment from your new receiver, we urge you

to read this manual. A few minutes spent

learning the functions of the various controls

will enable you to take advantage of all the

power the AVR 520 is able to deliver.

If you have any questions about this product,

its installation or its operation, please contact

your retailer or custom installer. They are your

best local sources of information.

Description and Features

The AVR 520 is among the most versatile and

multifeatured A/V receivers available, incorpo-

rating a wide range of listening options. In

addition to Dolby Digital and DTS decoding for

digital sources, a broad choice of Matrix sur-

round-encoded or Stereo surround modes are

available for use with sources such as CD, VCR,

TV broadcasts and the AVR 520’s own FM/AM

tuner. Along with Dolby Pro Logic II, DTS Neo:6,

Dolby 3 Stereo, and Hall and Theater modes,

the AVR 520 offers Harman International’s

exclusive Logic 7 process in both 5.1 and 7.1

versions to create a wider, more enveloping

field environment and more defined fly-overs

and pans. Another Harman Kardon exclusive is

VMAx, which uses proprietary processing to

create an open, spacious sound field even

when only two front speakers are available.

Finally, the AVR 520 is among the very few A/V

receivers that offer decoding of MP3 data, so

that you may listen to the latest music selec-

tions directly from compatible computers or

playback devices with the power and fidelity

you expect from Harman Kardon.

In addition to providing a wide range of listen-

ing options, the AVR 520 is easy to configure so

that it provides the best results with your

speakers and specific listening-room environ-

ment. On-screen menus make it simple to enter

settings for speaker configurations and bass

management, and the EzSet remote measures

a system’s sound levels and automatically cali-

brates them for perfectly balanced sound field

presentation.

For the ultimate in flexibility, the AVR 520 fea-

tures connections for six video devices, all with

both composite and S-Video inputs. Two addi-

tional audio inputs are available, and a total of

six digital inputs make the AVR 520 capable of

handling all the latest digital audio sources.

For compatibility with the latest HDTV video

sources and progressive scan DVD players, the

AVR 520 also features wide-bandwidth, low-

crosstalk component video switching.

Coax and optical digital outputs are available

for direct connection to digital recorders, and

both the front panel analog audio/video and

coaxial digital jacks may be switched to

outputs for use with portable recorders – a

Harman Kardon exclusive. Two video recording

outputs, preamp-out and main amp-in jacks,

and a color-coded eight-channel input make the

AVR 520 virtually future-proof, with everything

needed to accommodate tomorrow’s new for-

mats right on board.

The AVR 520’s flexibility and power extend

beyond your main home theater or listening

room. The AVR 520 includes a sophisticated

multizone control system that allows you to

select one source for use in the main room and

a different one in a second room. Complete

control over volume is possible with a separate

infrared control link. To make it easy to operate

the AVR 520 from a remote room, a separate

“Zone II” remote is included.

The AVR 520’s powerful amplifier uses

traditional Harman Kardon high-current design

technologies to meet the wide dynamic range

of any program selection.

Harman Kardon invented the high-fidelity

receiver more than forty-seven years ago. With

state-of-the-art circuitry and time-honored circuit

designs, the AVR 520 is the perfect combina

tion

of the latest in digital audio technology, a

quiet

yet powerful analog amplifier in an

elegant,

easy-to-use package.

■ Dolby* Digital and Dolby Pro Logic* II

Decoding, and the full suite of DTS

modes, including DTS-ES

6.1 Discrete

& Matrix and Neo:6

using the latest

24-bit, twin-core Crystal

DSP engine

■ Harman Kardon’s exclusive Logic 7

processing, available for the first time

with both 7.1 and 5.1 processing in

a variety of modes and two modes

of VMAx

■ MP3 decoding for use with computers

and digital audio players

■ remote automatically sets

output levels for optimum performance

■ High-bandwidth, HDTV-compatible

component video switching

■ Front panel digital inputs and coax

digital output capability for easy con-

nection to portable digital devices and

the latest video game consoles

■ Multiple digital inputs and outputs

■ Front panel analog A/V and coax digi-

tal jacks switchable to outputs for

easy connection to portable digital

devices and video game consoles

■ On-screen menu and display system

■ Complete multizone system with sepa-

rate “Zone II” remote included

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: To prevent electric shock,

do not use this (polarized)

plug with an extension cord,

receptacle or other outlet

unless the blades can

be fully inserted to

prevent blade exposure.

The lightning flash with arrowhead symbol,

within an equilateral triangle, is intended to

alert the user to the presence of uninsulated

“dangerous voltage” within the product’s

enclosure that may be of sufficient magnitude to constitute a

risk of electric shock to persons.

The exclamation point within an equilateral

triangle is intended to alert the user to the

presence of important operating and

maintenance (servicing) instructions in the

literature accompanying the appliance.
