AVR 645
AVR 645 Audio/ Video Receiver
OWNER’S MANUAL
29851_AVR645_ENG 30/10/06 9:46 Side 1
2 TABLE OF CONTENTS
3 Introduction
4 Safety Information
4 Unpacking
5 Front Panel Controls
7 Rear Panel Connections
10 Main Remote Control Functions
14 Zone II Remote Control Functions
16 Installation and Connections
16 Audio Connections
16 Video Connections
17 HDMI Connections
18 SCART A/V Connections
20 System and Power Connections
21 Speaker Selection
21 Speaker Placement
23 System Configuration
23 First Turn On
23 Using the On-Screen Display
23 System Setup
24 In/Out Input Setup
26 Video Monitor Settings
27 Audio Setup
27 Surround Setup
29 Night Mode Settings
29 Using EzSet/EQ
32 Manual Setup
33 Speaker Setup
35 Delay Settings
36 Output Level Adjustment
37 Additional Input Adjustments
38 Operation
38 Surround Mode Chart
40 Basic Operation
40 Source Selection
40 6/8-Channel Direct Input
41 Controls and Use of Headphones
41 Surround Mode Selection
42 Digital Audio Playback
42 Dolby Digital
42 DTS
42 PCM Audio Playback
43 Selecting a Digital Source
43 Digital Bitstream Indicators
43 USB Playback
44 Speaker/Channel Indicators
44 Night Mode
45 Using The Bridge™
45 Tape Recording
45 Front Panel Input/Output Connections
46 Output Level Adjustment with Source
46 EzSet/EQ Operation on/off Signals
46 Dim Function
46 Memory backup
47 Advanced Features
47 Front Panel Display Fade
47 Display Brightness
47 Turn-On Volume Level
48 Semi-OSD Settings
48 Full-OSD Time Out Adjustment
48 DMP The Bridge Auto Power
49 Multiroom Operation
50 Infrared Output Selection
51 Tuner Operation
51 Basic Tuner Operation
51 Station Selection
51 Preset Tuning
Table of Contents
Typographical Conventions
In order to help you use this manual with the remote control, front-panel controls and rear-panel
connections, certain conventions have been used.
EXAMPLE – (bold type) indicates a specific remote control or front-panel button, or rear-panel
connection jack
EXAMPLE – (OCR type) indicates a message that is visible on the front-panel information display
EXAMPLE – (Synchro type) indicates a message that is displayed on the remote control’s LCD screen
1
– (number in a square) indicates a specific front-panel control
– (number in a circle) indicates a rear-panel connection
0
– (number in an oval) indicates a button or indicator on the remote
A – (letter in an oval) indicates a button on the Zone II remote
51 RDS Operation
51 RDS Tuning
51 RDS Display Options
52 Program Search
53 Programming the Remote
53 Configuring the Remote
53 Preprogrammed Code Entry
54 Automatic Code Entry
54 Learning Commands
55 Learning Codes for an Input Selector
55 Device Priority
56 Macro Programming
58 Punch-Through Configuration
59 Renaming
61 Resetting the Remote
61 Backlight Options
63 Troubleshooting Guide
63 Processor Reset
64 Appendix
67 Technical Specifications
Declaration of Conformity
We, Harman Consumer Group, Inc.
2, route de Tours
72500 Château-du-Loir,
FRANCE
declare in own responsibility, that the product described in
this owner’s manual is in compliance with technical
standards:
EN 55013:2001+A1:2003
EN 55020:2002+A1:2003
EN 61000-3-2:2000
EN 61000-3-3.1995+A1:2001
EN 60065:2002
Jurjen Amsterdam
Harman Consumer Group, Inc.
07/06
The appearance of the text or cursor for your receiver’s on-screen menus may vary slightly from the
illustrations in this manual. Whether the text appears in all uppercase or upper- and lowercase
characters, performance and operation remain the same.
29851_AVR645_ENG 30/10/06 9:46 Side 2
INTRODUCTION 3
ENGLISH
Introduction
Thank you for choosing Harman Kardon!
With the purchase of a Harman Kardon AVR 645
you are about to begin many years of listening
enjoyment.
The AVR 645 has the most extensive range of
audio and video processing, control and connec-
tivity options ever offered by Harman Kardon,
enabling it to provide the best possible audio
and video reproduction with any type of source
material. Teaming advanced processing circuitry
with proprietary technologies such as EzSet/EQ,
the AVR 645 seamlessly integrates every compo-
nent in your entertainment system to deliver the
best possible sound and images.
Some of the leading-edge features that are
available with the AVR 645, such as HDMI
™
connectivity, are new to even the most experi-
enced home theater enthusiast.
To obtain the maximum enjoyment from your
new receiver, we urge you to read this manual.
A few minutes spent learning the functions of
the various controls will enable you to take
advantage of all the power the AVR is able to
deliver.
If you have any questions about this product, its
installation or its operation, please contact your
retailer or custom installer. They are your best
local sources of information.
Description and Features
The AVR 645 serves as the hub of your home
entertainment system, providing a wide range of
listening possibilities for almost any audio or
video program source, whether it is the broad-
cast of a movie or sporting event in HDTV or a
vintage mono or stereo recording. When playing
digital audio sources from either the convention-
al optical and coaxial inputs, or through the
HDMI 1.1 compliant connections, the AVR 645
decodes Dolby Digital, Dolby Digital EX, DTS and
DTS-ES data streams. Two-channel stereo and
matrix surround sources benefit from all current
Dolby Pro Logic IIx modes and DTS Neo:6. The
latest version of our proprietary Logic 7
®
process
is on-board to create a wider, more enveloping
sound field and more defined surround channel
positioning, regardless of the type of source
material. Additional audio playback and
processing options include a direct connection to
compatible computer-based sources through a
direct USB connection.
The AVR 645 takes the “video” part of its name
seriously. Along with two HDMI inputs and three
100MHz analog component video inputs, the
AVR 645 converts incoming analog signals to an
HDMI output or converts composite and S-video
to component for single wire connections. Tying
audio and video together, the AVR 645 provides
A/V sync delay so that the lip sync errors – com-
monly seen when digital video processing is used
in a source, program or video display – are
eliminated.
Coax and optical digital outputs are available for
direct connection to digital recorders, and both
the front panel analog audio/video and coaxial
digital jacks may be switched to outputs for use
with portable recorders – a Harman Kardon
exclusive. Two video recording outputs, preamp-
out and a color-coded eight-channel input make
the AVR virtually future-proof, with everything
needed to accommodate tomorrow’s new for-
mats right on board.
The AVR 645’s flexibility and power extend
beyond your main home theater or listening
room. The AVR includes a sophisticated multi-
zone control system that allows you to select
one source for use in the main room and a
different one (Audio) in a second room.
Complete control over volume is possible with a
separate infrared control link. To make it easy to
operate the AVR from a remote room, a separate
“ZR 10” remote is included.
Additional multiroom options include the option
to assign two of the AVR’s output channels to the
multiroom system and the ability to link the AVR
to innovative A-BUS
®
keypads for multiroom oper-
ation without the need for external amplifiers.
The AVR 645’s powerful amplifier uses traditional
Harman Kardon high-current design technologies
to meet the wide dynamic range of any program
selection.
Harman Kardon invented the high-fidelity
receiver more than fifty years ago. With
state-of-
the-art circuitry and time-honored circuit designs,
the AVR is the perfect combina
tion of the latest in
digital audio technology, a
quiet yet powerful
analog amplifier in an
elegant, easy-to-use
package.
■ Dolby* Digital, Dolby Digital EX and
Dolby Pro Logic* IIx Decoding, and the
full suite of DTS
®
modes, including
DTS-ES
®
6.1 Discrete & Matrix and
Neo:6
®
and DTS 96/24
■ Seven channels of high-current amplifi-
cation with two channels assignable to
either surround back or multiroom
applications
■ Harman Kardon’s exclusive Logic 7
®
processing, along with a choice of
Dolby Virtual Speaker processing for
use when only two speakers are
available
■ Dolby Headphone to create spacious,
open sound fields when using head-
phones
■ USB connectivity for audio playback
with compatible computers and quick
system upgrades
■ Two HDMI
™
1.1 and three assignable
high-bandwidth analog component
inputs for compatibility with the latest
high-definition video sources
■ Harman Kardon’s advanced EzSet/EQ
automatically configures speaker
settings and sets room equalization for
quick, easy and accurate system setup
■ High-bandwidth, HDTV-compatible
component video switching
■ Front panel analog A/V inputs,
switchable to outputs
■ Front panel digital inputs with coax
digital output capability for easy
connection to portable digital devices
and the latest video game consoles
■ Multiple digital inputs and outputs
■ On-screen menu and display system
■ Extensive multiroom options, including
a standard Zone II remote, assignable
amplifier channels and A-BUS/
READY
®
capability for listening to a separate
source in a remote zone
■ 6-Channel/8-Channel Direct Input and
Preamp Outputs for Easy Expansion and
Use with Future Audio Formats
■ Extensive bass management options,
including Quadruple Crossover
■ A/V Sync delay adjustable for each
input delivers perfect lip sync with
digital programs or video displays
29851_AVR645_ENG 30/10/06 9:46 Side 3

Produkspesifikasjoner

Merke: Harman Kardon
Kategori: Mottaker
Modell: AVR 645

Trenger du hjelp?

Hvis du trenger hjelp med Harman Kardon AVR 645 still et spørsmål nedenfor, og andre brukere vil svare deg


Mottaker Harman Kardon Manualer

Harman Kardon

Harman Kardon AVI200 Bruksanvisning

10 September 2025
Harman Kardon

Harman Kardon AVR 700 Bruksanvisning

9 September 2025
Harman Kardon

Harman Kardon CA215 Bruksanvisning

9 September 2025
Harman Kardon

Harman Kardon AVR 110 Bruksanvisning

9 September 2025
Harman Kardon

Harman Kardon CA70 Bruksanvisning

9 September 2025
Harman Kardon

Harman Kardon AVR 2650 Bruksanvisning

9 September 2025
Harman Kardon

Harman Kardon AVR 138 Bruksanvisning

9 September 2025
Harman Kardon

Harman Kardon AVR 320 Bruksanvisning

8 September 2025
Harman Kardon

Harman Kardon AVR 370 Bruksanvisning

8 September 2025
Harman Kardon

Harman Kardon CA240 Bruksanvisning

8 September 2025

Mottaker Manualer

Nyeste Mottaker Manualer

Hughes & Kettner

Hughes & Kettner 15 DFX Bruksanvisning

22 September 2025
InLine

InLine 99204I Bruksanvisning

22 September 2025
Cambridge

Cambridge Edge M Bruksanvisning

22 September 2025
Cambridge

Cambridge 351R Bruksanvisning

22 September 2025
Cambridge

Cambridge Evo 150 Bruksanvisning

21 September 2025
Cambridge

Cambridge Azur 540P Bruksanvisning

21 September 2025
Cambridge

Cambridge Azur 851E/W Bruksanvisning

21 September 2025
Rocketfish

Rocketfish RF-RBREC Bruksanvisning

21 September 2025
Cambridge

Cambridge CXA81 Bruksanvisning

21 September 2025
Cambridge

Cambridge CXR200 Bruksanvisning

21 September 2025
