BDS 776
Variety is the spice of life. The BDS 776 offers you all the
features of the BDS 770 wrapped in a glossy white finish.
Enjoy your favourite 3-D films and digital music, thanks to
the 3-D Blu-ray Disc
™
receiver and a complete 5.1-channel
speaker package – all with a cool, clean look befitting a
system of such distinction.
Highlights
Complete, integrated home theatre audio system
The performance of separate components with the
ease of use of a single, integrated system
Compact, stylish design with gloss white finish
Plays 3-D sources
BD-Live
™
interactivity
Integrated Blu-ray Disc player, DVD/CD player and FM
tuner
HDMI
®
v.1.4a inputs with 3-D support and Deep Colour
HDMI output with Audio Return Channel
Front-panel USB port for audio, video and image
playback
Dolby
®
TrueHD and DTS-HD Master Audio
™
decoding
The Bridge IIIP-compatible with iPod and iPhone
EzSet/EQ
™
auto calibration
Energy-saving subwoofer trigger output
Component video input
Convenient learning remote control
Intuitive on-screen menu
Dolby
®
Virtual Speaker technology
Full-colour and multi-language on-screen menus
5.1-channel integrated home theatre system featuring a 3-D Blu-ray Disc
™
receiver
with Dolby
®
TrueHD, DTS-HD Master Audio
™
surround-sound decoding and HDMI
®
inputs
BDS 776
Specifications
HARMAN Consumer, Inc.
8500 Balboa Boulevard, Northridge, CA 91329 USA www.harmankardon.com
© 2011 HARMAN International Industries, Incorporated. All rights reserved.
Harman Kardon is a trademark of HARMAN International Industries, Incorporated, registered in the United States and/or other countries. EzSet/EQ is a trademark of HARMAN International Industries,
Incorporated. Blu-ray 3D, Blu-ray Disc and BD-Live are trademarks of the Blu-ray Disc Association. DivX
®
, DivX Certified
®
and associated logos are trademarks of Rovi Corporation or its subsidiaries
and are used under license. Dolby is a registered trademark of Dolby Laboratories. DTS is a registered trademark of DTS, Inc. DTS-HD and DTS-HD Master Audio are trademarks of DTS, Inc. HDMI is a
registered trademark of HDMI Licensing LLC. iPhone and iPod are trademarks of Apple Inc., registered in the U.S. and other countries. iPhone/iPod not included.
Features, specifications and appearance are subject to change without notice.
5.1-channel integrated home theatre system featuring a 3-D Blu-ray Disc
™
receiver
with Dolby
®
TrueHD, DTS-HD Master Audio
™
surround-sound decoding and HDMI
®
inputs
BDS 776
Key Features
■
HDMI
®
v.1.4a with 3-D and Audio Return Channel: Delivers digital
video and audio at the highest quality level (up to 1080p)
■
Digital amplifier technology: Delivers high power from a small
package that uses less energy and generates less heat
■
Four identical dual-midrange two-way satellite speakers: Maintain
consistent sound from speaker to speaker, making moving sounds
clearer and more realistic, even at higher volumes
■
Dedicated, two-way midrange centre speaker: Voice-matched to the
satellite speakers for clear dialogue even at higher volumes
■
Compact powered subwoofer: Downward-firing to extend and
enhance the bass response
■
Extensive connectivity: Three HDMI v.1.4a inputs, three digital
audio inputs and two analogue inputs make it easy to connect
other audio/video components to your BDS system; there’s even a
component video connection ideal for game consoles
■
The Bridge IIIP-compatible with iPod/iPhone: System connects to iPod
and iPhone via Harman Kardon The Bridge IIIP dock (not included).
■
EzSet/EQ auto calibration: Automatically tailors individual speaker volume
levels to specific room conditions
■
Heavy-duty, gold-plated binding posts: Benefit from ultra-secure
speaker connections and compatibility with a variety of speaker wire
■
BD-Live
™
connection: Connect to your home network, and
experience next-generation interactive content through BD-Live
™
technology
■
DivX Certified
®
to play DivX
®
video up to HD 1080p, including
premium content
■
Playlist function: Automatically recalls your favourite files stored on
USB or CD-R discs, with minimal button pushing
■
Dot-matrix information display: Delivers status messages and
allows you to listen to music on the BDS system – without having to
turn on the TV
■
Cover-art display function: See album cover and artist info while
playing audio files with ID3 tags played from USB devices
■
Subwoofer trigger: When user turns system on or off, the subwoofer
automatically turns on or off
■
Screen-saver function: Prevents image burn-in on CRT and plasma
displays
■
Detachable IEC power cord: Simplify installation by running the
power cord to the installation site before installing the unit
■
Upgradable firmware: Get system upgrades via the on-screen
display to keep your receiver up to date
■
Headphone jack: Enables private listening when you connect stereo
headphones directly to the BDS system
■
Speaker wall-mount hardware and all cables included
Specications
BDS 570WQ Receiver
Audio Section
■
Continuous average power, stereo mode: 65 watts per channel,
20Hz – 20kHz, @ <0.1% THD, both channels driven into 6 ohms
■
Multichannel power: 65 watts per channel, 20Hz–20kHz,
@ <0.1% THD, all channels driven into 6 ohms
■
Input sensitivity/impedance (line inputs): 250mV/46k ohms
■
Signal-to-noise ratio (IHF-A): –90dB
■
Frequency response @ 1W (±0.5dB): 20Hz – 20kHz
FM Tuner Section
■
Frequency range: 87.5MHz – 108.0MHz (U.S. and EU)
■
Usable sensitivity IHF: >14dBf
■
Signal-to-noise ratio (mono/stereo): –60dB/–55dB
Disc Player Section
■
Supported disc formats: 127mm (5-inch) or 76mm (3-inch) BD-Video
(single-layer or double-layer), DVD-Video, DVD+R/+RW, DVD-R/-RW,
CDDA (CD digital audio), CD-R/RW, AVCHD discs
■
Region code (BD/DVD): B/2 (EU)
■
Audio formats: Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS
®
Digital, DTS-HD
™
High Resolution Audio, DTS-HD Master Audio,
™
PCM, WMA (DRM-free version only): WMA9, CBR @192kbps,
VBR @ 355kbps, MP3: 32kbps – 320kbps bitrates, including
variable-bitrate encoding
■
Still-image format: JPEG
■
Video signal system: PAL (EU)
■
Frequency response: 20Hz – 20kHz ±0.5dB
■
Signal-to-noise ratio: –90dB (A-weighted)
■
Dynamic range: 90dB (16-bit)
■
THD/1kHz: DVD/CD: 0.1%
■
Wow & flutter: Below measurable limits
Video Section
■
Television format: PAL (selectable)
■
HDMI version: v.1.4a, with 3-D and 30/36-bit Deep Colour
General
■
Power requirement: 110 – 240V AC, 50/60Hz
■
Power consumption: 110W maximum; <1W standby
■
Dimensions (H x W x D): 102mm x 401mm x 260mm
■
Weight: 6.5kg
■
Finish: Gloss white
HKTS 16WQ Speaker System
■
Frequency response: 45Hz – 20kHz (–6dB)
SAT-TS11 Satellites
■
Midrange transducer: 75mm (3") cone, video-shielded
■
High-frequency transducer: 13mm (½") dome, video-shielded
■
Nominal impedance: 8 ohms
■
Recommended power: 10-120 watts
■
Sensitivity (2.83V/1m): 86dB @ 1 watt/1 meter
■
Dimensions (H x W x D): 243mm x 100mm x 92mm
■
Weight: 1.0kg
■
Finish: Gloss white
CEN-TS11 Center
■
Midrange transducer: Two 75mm (3") cone, video-shielded
■
High-frequency transducer: 19mm (3/4") dome, video-shielded
■
Nominal impedance: 8 ohms
■
Recommended power: 10-120 watts
■
Sensitivity (2.83V/1m): 86dB @ 1 watt/1 meter
■
Dimensions (H x W x D): 102mm x 241mm x 92mm
■
Weight: 1.0kg
■
Finish: Gloss white
HKTS 210SUB Powered Subwoofer
■
Low-frequency transducer: 200mm (8") cone
■
Amplifier power: 200 watts RMS
■
Enclosure type: Sealed
■
Power requirement: 220V – 240V AC, 50Hz/60Hz (EU)
■
Dimensions (H x W x D): 353mm x 267mm x 267mm;
height measurement includes feet
■
Weight: 9kg
■
Finish: Gloss white
