Side 1/34

OWNER’S

MANUAL

SURROUND

IMPORTANT SAFETY

INSTRUCTIONS

Verify Line Voltage Before Use

The HK Surround wireless home theater system has been

designed for use with 100-240 volt, 50/60 Hz AC current.

Connection to a line voltage other than that for which your

product is intended can create a safety and re hazard and may

damage the unit. If you have any questions about the voltage

requirements for your specic model or about the line voltage

in your area, contact your selling dealer before plugging the

unit in to a wall outlet.

Do Not Use Extension Cords

To avoid safety hazards, use only the power cord supplied

with your unit. We do not recommend that extension cords be

used with this product. As with all electrical devices, do not run

power cords under rugs or carpets, or place heavy objects on

them. Damaged power cords should be replaced immediately

by an authorized service center with a cord that meets factory

specications.

Handle the AC Power Cord Gently

When disconnecting the power cord from an AC outlet, always

pull the plug; never pull the cord.

If you do not intend to use your speaker for any considerable

length of time, disconnect the plug

from the AC outlet.

Do Not Open the Cabinet

There are no user-serviceable components inside this product.

Opening the cabinet may present a shock hazard, and any

modication to the product will void your warranty. If water

accidentally falls inside the unit, disconnect it from the AC

power source immediately, and consult an authorized service

center.

TABLE OF CONTENTS

/ IMPORTANT SAFETY INSTRUCTIONS ...............................................1

/ INTRODUCTIO N ........................................................................................ 3

/ WHAT’S IN THE BOX ............................................................................... 4

/ PRODUCT OVERVIEW ............................................................................ 6

/ INSTALLATION ........................................................................................... 11

/ CONNECTING TO TV .............................................................................14

/ CONNECTING TO OTHER DEVICES ...............................................16

/ POWER O N .................................................................................................18

/ CONNECTING TO INTERNET ........................................................... 20

/ USING YOUR SYSTEM ......................................................................... 22

/ SOUND SETTIN GS ................................................................................. 24

/ SET TI N GS...................................................................................................25

/ SPECIFIC ATIONS .....................................................................................27

/ TROUBLESHOOTIN G ........................................................................... 29

/ OPEN SOURCE LICENSE NOTICE ....................................................31

/ LI C EN SE ......................................................................................................32

Produkspesifikasjoner

Merke:	Harman Kardon
Kategori:	hjemmekinoanlegg
Modell:	Surround
Bluetooth:	Ja
Wi-Fi:	Ja
Bluetooth-versjon:	4.2
Pakkevekt:	25000 g
Audio Return Channel (ARC):	Ja
HDMI inn:	1
Antall HDMI-utganger:	4
Antall satellitter:	4
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 / 60 Hz
Produktfarge:	Sort
Pakkedybde:	504 mm
Pakkehøyde:	456 mm
Pakkebredde:	562 mm
Kabler inkludert:	AC, HDMI
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Fjernkontroll medfølger:	Ja
AUX-inngang:	Ja
Signal-til-støy-forhold (SNR):	80 dB
Satelitthøyttalerens dimensjoner (BxDxH):	86 x 105 x 274 mm
Lyd-utgang kanaler:	- kanaler
RMS-rangert strøm/utgangseffekt:	- W
Satelitthøyttalere RMS-strøm:	50 W
Dimensjoner på hovedenhet (BxDxH):	155 x 305 x 60 mm
Digital optisk lydinngang:	1
Senterhøyttaler, strøm:	50 W
Subwooferens dimensjoner (BxDxH):	121.7 x 496 x 396.8 mm
Senterhøyttalerens dimensjoner (BxDxH):	106 x 365 x 73 mm
Sovemodus:	Ja
Diskanthøyttalerens diameter:	7 "
Lydplankens RMS-effekt:	120 W
Diameter på satelitthøyttalerens diskantenhet:	1.25 "
Diameter (imperisk) på satelitthøyttalerens bassenhet:	3 "
Diameter på senterhøyttalerens diskantenhet:	1.25 "
