Side 1/16

ENGLISH

HD 980 CD Player

OWNER’S MANUAL

2 TABLE OF CONTENS

Table of Contents

2 Typographic Conventions

3 Introduction

4 Information

4 Unpacking

5 Front Panel Controls

6 Rear Panel Connections

7 Remote Control Functions

9 Installation

10 Operation

10 Loading and Unloading Discs

10 Normal Play

11 Display Dim

11 Time Display

11 Disc Info

12 Search

12 Skip

12 Folder

12 +10/-10

13 Programmed Play Operation

13 Programmed Play

13 Checking Program Contents

13 Clearing Programs

14 Repeat Play

15 Troubleshooting Guide

16 Technical Specifications

Typographic Conventions

In order to help you use this manual with the remote control, front panel controls and rear panel

connections, certain conventions have been used.

EXAMPLE – (bold type) indicates a specific remote control or front panel button, or rear panel

connection jack.

EXAMPLE – (bold type) indicates a message in the front panel information display.

1 – (number in a square) indicates a specific front panel control.

a – (number in an oval) indicates a button or indicator on the remote.

¡ – (number in a circle) indicates a rear panel connection.

Declaration of Conformity

We, Harman Consumer Group, Inc.

2, route de Tours

72500 Château-du-Loir,

FRANCE

declare in own responsibility, that the product described

in this owner’s manual is in compliance with technical

standards:

EN 55013:2001+A1:2003

EN 55020:2002+A1:2003

EN 61000-3-2:2000

EN 61000-3-3.1995+A1:2001

EN 60065:2002

Jurjen Amsterdam

Harman Consumer Group, Inc.

12/07

INTRODUCTION 3

Introduction

ENGLISH

Thank you for choosing Harman Kardon

HD 980 CD player.

The HD 980 is an exceptionally well-engineered

product that offers high performance and ease

of use.

Along with conventional CD audio discs, the

HD 980 is also compatible with MP3 data from

CDs and most recordable CD formats.

Harman Kardon's analog processing legacy has

been expressed to its optimal level in the output

stage of the HD 980 with High Definition, Wide

Bandwidth and Low Feedback circuitry in a pure

Class A configuration, using only high grade

components.

We ask that you take a few minutes to read

through this Owner’s Manual to familiarize your-

self with the controls and functions. This brief

investment of time will yield dividends in the

form of years of listening pleasure.

If you have any questions about this product, its

installation or operation, please contact your

dealer, as they are your best source of local

information.

n Digital Processing for Highest Possible

Jitter Rejection based on a 32bit DSP

n CD Playback with CD Text Functionality,

MP3 Playback with ID3 Tag Information

n Digital Output for Direct Connection to

Outboard Digital-to-Analog Converters

n Sophisticated Programming Features to

Automatically Play Tracks in

Preprogrammed or Random Order

n Full compatibility with CD-R and CD-RW

format to play (finalized) recordable

and erasable discs without problems.

Important Note: The player will only output

2-channel PCM signals. Neither multi-channel

Dolby Digital or DTS nor their 2-channel down-

mix signals will be output.

CLASS 1

LASER

Produkspesifikasjoner

Merke:	Harman Kardon
Kategori:	CD-spiller
Modell:	HD 980
Vekt:	3800 g
Bruksanvisning:	Ja
Innebygde høyttalere:	Nei
Innebygd mikrofon:	Nei
Lydutgang:	3
Klokkefunksjon:	Nei
Kompatible produkter:	HRS
ID3 Tag-skjerm:	Ja
Antall kanaler:	2 kanaler
Dimensjoner (B x D x H):	440 x 332 x 63 mm
Batteritype:	AA
Diskantjustering:	Nei
CD-tekst:	Ja
Strømforbruk (standby):	2 W
Ekstra tilbehør:	Ja
Støttede lydformater:	CD-A, MP3
Produktfarge:	Sort
Antall støttede batterier:	2
Minnekortenhet:	Støttes ikke
MP3-avspilling:	Ja
Batterispenning:	1.5 V
Strømforbruk (vanlig bruk):	20 W
Fjernkontroll medfølger:	Ja
Fjernkontrolltype:	IR
AUX-inngang:	Nei
Signal-til-støy-forhold (SNR):	110 dB
CD-RW-avspilling:	Ja
CD-R-avspilling:	Ja
Enhetstype:	HiFi CD-spiller
I/O-porter:	RCA, TOS opt/coax., IEC
Line-in:	Nei
Lydsystem:	2.0
Strømkabel inkludert:	Ja
Total Harmonic Distortion (THD):	0.0009
Krav til strømforsyning:	AC 220-230 V, 50/60 Hz
Kassettbunke:	Nei
Bit-rate:	24
Utjevner/frekvenskorrigerer:	Nei
RDS-mottaker inkludert:	Nei
Skjermsifre:	12 sifre
Skjerm med bakgrunnsbelysning:	Ja
Line-out:	Nei
Frekvensrekkevidde:	12 - 39500 Hz
Subwoofer RMS-styrke:	0 W
Bassjustering:	Nei
Innlastingstype plate:	Brett
Lyd D/A-konverterer (DAC):	Wolfson WM8740
Utgangsstrømbeskrivelse:	2.0 V
Medietyper som støttes:	CD-DA, CD-R/RW, MP3
Digital mottaker:	Nei
Innebygd antenne:	Nei
Optisk diskinnspilling:	Nei
Programmerbare spor:	99
