Side 1/12

HKTS 9/16

User Guide

English

Home Theater Speaker System

2 3

Harman Kardon® HKTS 9/16

Typographical Conventions

We have employed certain conventions to help you use this manual:



– (number in a circle) – Indicates a rear-panel control or connection on the illustration of the HKTS200SUB subwoofer

Example (bold type) – Indicates the name of a specific control or rear-panel connection on the HKTS200SUB subwoofer

EXAMPLE (OCR type) – Indicates a control or switch setting on the HKTS200SUB subwoofer

Important Safety Instructions

Please read the following precautions before use:

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s

instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves or other

apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized

plug has two blades with one wider than the other. A grounding-type plug has two blades

and a third grounding prong. The wide blade or the third prong is provided for your safety. If

the provided plug does not fit into your outlet, consult an electrician for replacement of the

obsolete outlet.

10. Protect the power cord from being walked on or pinched, particularly at plugs,

convenience receptacles and the point where they exit from the apparatus.

11. Only use attachments/accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket or table specified by

the manufacturer or sold with the apparatus. When a cart is used, use

caution when moving the cart/apparatus combination to avoid injury

from tip-over.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus

has been damaged in any way, such as power supply cord or plug is damaged, liquid has been

spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or

moisture, does not operate normally, or has been dropped.

15. Do not expose this apparatus to dripping or splashing and ensure that no objects filled

with liquids, such as vases, are placed on the apparatus.

16. To completely disconnect this apparatus from the AC Mains, disconnect the power supply

cord plug from the AC receptacle.

17. The mains plug of the power supply cord shall remain readily operable.

18. Do not expose batteries to excessive heat such as sunshine, fire or the like.

The lightning flash with arrowhead symbol, within an equilateral triangle,

is intended to alert the user to the presence of uninsulated “dangerous

voltage” within the product’s enclosure that may be of sufficient magnitude to

constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the

user to the presence of important operating and maintenance (servicing)

instructions in the literature accompanying the product.

WARNING:

To reduce the risk of fire or electric shock,

do not expose this apparatus to rain or moisture.

HKTS 9/16 Home-Theater System Owner’s Manual

Table of Contents

Introduction .....................................................3

Description and Features .........................................3

HKTS200SUB Subwoofer Rear-Panel Connections. . . . . . . . . . . . . . . . . . . 4

Speaker Placement ...............................................5

Mounting Options ................................................5

Speaker Connections .............................................6

Operation .......................................................10

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Specifications ...................................................11

2 3

ENGLISH

Introduction

Thank you for purchasing the Harman Kardon

HKTS 9/16 speaker system, with which

you’re about to begin many years of listening enjoyment. The HKTS 9/16 has been custom

designed to provide all the excitement and power of the cinema experience in your own

living room.

While sophisticated electronics and state-of-the-art speaker components are hard at

work within the HKTS 9/16, hookup and operation are simple. Color-keyed cables and

connections, and simple controls make the HKTS 9/16 easy to use.

To obtain maximum enjoyment from your new home theater speaker system, we urge

you to take a few minutes to read through this manual. This will help ensure that the

connections you make to your receiver (or preamp/processor), amplifier and other devices

are correct. In addition, a few minutes spent learning the functions of the various controls

will enable you to take advantage of all the power and refinement the HKTS 9/16 is able

to deliver.

If you have any questions about this product, its installation or its operation, please

contact your dealer, the best local source of information.

Description and Features

The HKTS 9/16 is a complete six-piece home theater speaker system that includes:

An 8-inch, 200-watt powered subwoofer

•

Four identical two-way video-shielded satellite speakers (the

•

HKTS 16 satellite

speakers feature dual drivers) for the left and right front, and left and right rear

(surround) speaker positions

A dedicated, voice-matched, video-shielded, dual-driver center speaker

•

Shelf stands and wall-mount brackets for the satellite speakers and a wall-mount

•

bracket for the center speaker.

All of the cables you need to connect all of the speakers to your receiver or preamp/

•

processor and amplifier.

The speaker cables all use a color-coding system to conform to the Consumer Electronics

Association (CEA®) standard. This color-coding system minimizes confusion when

connecting the speakers, especially when the HKTS 9/16 system is used with a Harman

Kardon receiver.

Shelf stands and wall-mount brackets are included for the satellite and center speakers,

and shelf stands are included for the satellite speakers. Optional HTFS 2 floor stands are

available separately from your Harman Kardon dealer.

Harman Kardon invented the high-fidelity receiver fifty years ago. With state-of-the-art

features and time-honored circuit designs, the HKTS 9/16 is a perfect complement to a

Harman Kardon receiver, or any home theater system.

One center-channel speaker

One powered subwoofer

Four wall-mount brackets for satellite speakers

One combination LFE (low-frequency effects)

and trigger cable for connection to the

subwoofer (LFE cable has purple connectors)

Three six-meter (19.7-foot) speaker cables for

connection to front satellites (red and white)

and to center speaker (green)

Two 12-meter (39.4-foot) speaker cables for

connection from receiver to rear surround-sound

satellites (gray and blue)

Harman Kardon®

HKTS 9/16

Included

Four satellite speakers: a left front speaker, a right front

speaker, and two rear surround-sound speakers, with

color-keyed stickers (shown with included shelf stands

attached). (HKTS9 satellites shown)

Produkspesifikasjoner

Merke:	Harman Kardon
Kategori:	Høyttaler
Modell:	HKTS 16WQ
Strømkilde:	AC
Anbefalt bruk:	Hjemmekino
Antall satellitter:	2
Akustisk forsterkning:	86 dB
Satelitthøyttalerens dimensjoner (BxDxH):	100 x 92 x 243 mm
Subwoofer-vekt:	9000 g
Lyd-utgang kanaler:	- kanaler
RMS-rangert strøm/utgangseffekt:	450 W
Satelitthøyttalere RMS-strøm:	120 W
Subwoofer RMS-styrke:	200 W
Frekvensomfang for satelitthøyttaler:	45 - 20000 Hz
Subwoofer-driverdiameter (imperisk):	8 "
Senterhøyttaler, strøm:	10 W
Senterhøyttaler vekt:	1000 g
Subwooferens dimensjoner (BxDxH):	267 x 267 x 353 mm
Senterhøyttalerens dimensjoner (BxDxH):	241 x 92 x 102 mm
Impedans for senterhøyttaler:	8 Ω
Forsterkerenhet medfølger:	Ja
Impedans for satellitthøyttaler:	8 Ω
Satelitthøyttalervekt:	1000 g
Diameter på satelitthøyttalerens diskantenhet:	0.5 "
Diameter på senterhøyttalerens diskantenhet:	0.75 "
Diameter på senterhøyttalerens mellomtonedriver:	3 "
Diameter på satelitthøyttalerens mellomtonedriver:	3 "
Veggmonterbare satelitthøyttalere:	Ja
