Side 1/15

ENGLISH

HKTS 3

Home Theater & Music Speaker System

OWNER’S MANUAL

00XXCSK - HK HKTS3 OM, ENGv3,DEUv2,FRAv1,NLDv1,ITAv1,SWEv2.indd 1 23/02/09 10:00:04

EN 61000-6-3:2001

EN 61000-6-1:2001

EN 55013:2001

EN 55020:2002

EN 61000-3-2:2000

EN 61000-3-3:1995+A1:2001

EN 60065:2002

Jurjen Amsterdam

Harman Consumer Group International

02/09

Important Safety Instructions

TABLE OF CONTENTS

Table of Contents

3 Introduction

4 Rear Panel Connections

6 Speaker Placement

7 Mounting Options

8 Speaker Connections

12 Operation

12 Volume

12 Additional Bass Adjustments

13 Troubleshooting

14 Specifications

We, Harman Consumer Group International

2, route de Tours

F-72500 Château-du-Loir

France

declare in own responsibility, that the

product described in this owners manual is

in compliance with technical standards:

DECLARATION OF CONFORMITY

Read these instructions.1.

Keep these instructions.2.

Heed all warnings.3.

Follow all instructions.4.

Do not use this apparatus near water.5.

Clean only with a dry cloth.6.

Do not block any ventilation openings. Install in 7.

accordance with the manufacturer’s instructions.

Do not install near any heat sources such as 8.

radiators, heat registers, stoves or other apparatus

(including amplifiers) that produce heat.

Do not defeat the safety purpose of the polarized 9.

or grounding-type plug. A polarized plug has

two blades with one wider than the other. A

grounding-type plug has two blades and a third

grounding prong. The wide blade or the third

prong is provided for your safety. If the provided

plug does not fit into your outlet, consult an elec-

trician for replacement of the obsolete outlet.

Protect the power cord from being walked on 10.

or pinched, particularly at plugs, convenience

receptacles and the point where they exit from

the apparatus.

Only use attachments/accessories specified by the 11.

manufacturer.

12. Use only with the cart, stand, tripod, bracket or

table specified by the manufacturer or

sold with the apparatus. When a cart is

used, use caution when moving the

cart/apparatus combination to avoid

injury from tip-over.

Unplug this apparatus during lightning storms or 13.

when unused for long periods of time.

Refer all servicing to qualified service personnel. 14.

Servicing is required when the apparatus has

been damaged in any way, such as power supply

cord or plug is damaged, liquid has been spilled

or objects have fallen into the apparatus, the

apparatus has been exposed to rain or moisture,

does not operate normally, or has been dropped.

Do not expose this apparatus to dripping or 15.

splashing and ensure that no objects filled

with liquids, such as vases, are placed on the

apparatus.

To completely disconnect this apparatus from the 16.

AC Mains, disconnect the power supply cord plug

from the AC receptacle.

The mains plug of the power supply cord shall 17.

remain readily operable.

Do not expose batteries to excessive heat such as 18.

sunshine, fire or the like.

The lightning flash with arrowhead

symbol, within an equilateral triangle, is

intended to alert the user to the presence

of uninsulated “dangerous voltage” within the prod-

uct’s enclosure that may be of sufficient magnitude to

constitute a risk of electric shock to persons.

The exclamation point within an equilat-

eral triangle is intended to alert the user

to the presence of important operating

and maintenance (servicing) instructions in the litera-

ture accompanying the product.

WARNING: To reduce the risk of fire or electric shock,

do not expose this apparatus to rain or moisture.

Typographical Conventions

In order to help you use this manual, certain conventions have been used.

Example – (bold type) indicates a specific control or rear-panel connection on the subwoofer

ExamplE

– (OCR type) indicates a control or switch position on the subwoofer

– (number in a circle) indicates a rear-panel control or connection on the subwoofer

00XXCSK - HK HKTS3 OM, ENGv3,DEUv2,FRAv1,NLDv1,ITAv1,SWEv2.indd 2 23/02/09 10:00:05

ENGLISH

Introduction

INTRODUCTION

Thank you for purchasing the Harman Kardon HKTS 3,

with which you’re about to begin many years of

listening enjoyment. The HKTS 3 has been custom-

designed to provide all the excitement and power of

the music and cinema experience in your own living

room.

While sophisticated electronics and state-of-the-art

speaker components are hard at work within the

HKTS 3, hookup and operation are simple. Color-keyed

cables and connections, and simple controls make the

HKTS 3 easy to use.

To obtain maximum enjoyment from your new music

and home theater speaker system, we urge you to take

a few minutes to read through this manual. This will

ensure that connections to your receiver or preamp/

processor and amplifier or other external devices

are made properly. In addition, a few minutes spent

learning the functions of the various controls will

enable you to take advantage of all the power and

refinement the HKTS 3 is able to deliver.

If you have any questions about this product, its

installation or operation, please contact your dealer,

the best local source of information.

Description and Features

The HKTS 3 is a three-piece home theater speaker

system that includes a 10-inch, 100-watt, bass-reflex

powered subwoofer; two identical, 2-way dual-driver

satellite speakers for use in the left and right front

speaker positions; shelf stands and wall-mount

brackets for the two satellites; and all of the speaker

cables you need to connect your speakers to your

receiver or preamp/processor and amplifier. The

speaker cables and speakers all use a color-coding

system to conform to the CEA standard. The color-

coding system minimizes confusion, especially when

the HKTS 3 system is used with a Harman Kardon

receiver.

The HKTS 3 subwoofer is easy to connect to your

system, since it’s equipped with a special subwoofer

input for use with equipment that has a dedicated

subwoofer connection that carries a low-frequency

output. It also includes stereo speaker-level inputs

and outputs for connection to older receivers and

processors that do not have a line-level subwoofer

output. Other conveniences include a level control,

high-cut (low-pass) filter switch and phase switch

for fine-tuning bass response to suit your listening

environment and taste, and an efficient Trigger

switching system that automatically switches the unit

from Standby mode to Active mode.

Shelf stands and wall-mount brackets are included for

the satellite speakers, and optional HTFS 2 floor stands

are available separately from your Harman Kardon

dealer.

Harman Kardon invented the high-fidelity receiver

fifty years ago. With state-of-the-art features and

time-honored circuit designs, the HKTS 3 is a perfect

complement to a Harman Kardon receiver or any home

theater system.

Complete 2.1 home theater and music ■

speaker system

Speakers are magnetically shielded for ■

placement near video monitors

Fully color-coded cables and connections ■

simplify setup

Both line- and speaker-level inputs for use ■

with most audio components

Subwoofer input offers superior-quality ■

bass reproduction when used with any

digital audio system that incorporates bass

management or programmable crossovers

Included

One powered

subwoofer

Two satellites for left,

right and surrounds, with

color-key stickers (shown

with included shelf stands

attached)

Two wall-mount

brackets

One RCA cable for connection to subwoofer (purple)

Two 6-meter speaker cables for connection to front

satellites (red and white)

00XXCSK - HK HKTS3 OM, ENGv3,DEUv2,FRAv1,NLDv1,ITAv1,SWEv2.indd 3 23/02/09 10:00:06
