Side 1/10

Onyx

Wireless Speaker System with Rechargeable Battery

Owner’s Manual

Table of Contents

Onyx

INTRODUCTION 3

DESCRIPTION AND FEATURES 3

DESIGN AND PERFORMANCE 3

WIRELESS CONNECTION 3

INCLUDED ITEMS 3

CONTROLS AND CONNECTIONS 3

ONYX TOP PANEL CONTROLS 3

ONYX REAR PANEL CONNE CTIONS AND CONTROLS 4

SPEAKER PLACEMENT 4

CONNECTIONS 4

POWER CONNECTIONS 4

SOURCE OPTIONS 4

WI-FI CONNECTION 4

BLUETOOTH CONNECTION 4

WPS CONNECTION 5

IOS WIRELESS WI-FI SHARING 5

IOS WI-FI SHARING WITH CABLE 5

AD-HOC MODE 6

OPERATION 6

SWITCHING ON AND OFF 6

ADJUSTING VOLUME 6

PLAYING MUSIC THROUGH BLUETOOTH 6

PLAYING MUSIC THROUGH WI-FI 7

PLAYING MUSIC THROUGH AIRPLAY® 7

PLAYING MUSIC THROUGH AN AUXILIARY DEVICE 7

CONNECTING THROUGH DLNA 7

H/K REMOTE 7

LED INDICATIONS 7

TROUBLESHOOTING 8

SPECIFICATIONS 9

Introduction

Ony x

Introduction

Thank you for purchasing the Harman Kardon Onyx. HK Onyx is a premium wireless

speaker with an iconic design and comes with a rechargeable inbuilt battery that allows

you to stream music from any smart phone, tablet or other wireless devices through

Bluetooth®, AUX, Wi-Fi, AirPlay® and DLNA®.

HK Onyx is a 4-speaker, advanced acoustic platform and its dual passive radiators

deliver a truly fantastic sound experience with a balanced soundstage and powerful

bass response. The Harman Kardon Remote app simplifies the setup and lets you stream

all your audio content. With its simple setup, quality sound, and easy portability, the HK

Onyx is an essential audio component for every house.

browse www.harmankardon.com for complete details.

Description and Features

Design and Performance

• HK Onyx is designed with steel and leather.

• Dual passive radiators provide deep bass.

• The built-in rechargeable battery offers up to 6 continuous hours of

playtime.

• HK Onyx is compatible with Harman Kardon Remote app.

Wireless Connection

Wireless connectivity allows you to place the speaker in any part of the room without

having to worry over friends and family tripping over cables. The HK Onyx supports

almost every popular wireless device via Bluetooth or Wi-Fi connections.

Included Items

HK Onyx speaker system complete accessories consist of:

• HK Onyx speaker

• One AC power adaptor

• Regional power cable

• Quick Start Guide

IMPORTANT: If any included accessory is missing, or if any part of your HK

Onyx system fails to operate properly, contact your dealer immediately.

Controls and Connections

This section will help you identify the controls and connections that are provided on the

Onyx top and rear panels.

Onyx Top Panel Controls

The following control buttons are available on the top panel of the HK Onyx:

• Power button

• Volume Controls

• Bluetooth

• Wi-Fi

• Battery level indicator

Power Button

This button when pressed turns the HK Onyx ON or OFF and has an LED to indicate the

power mode. The three power modes are:

• Operational mode

• Sleep mode

• OFF mode

When the system is in OFF mode (Power LED is not lit), touch the power button for more

than 2 seconds to switch on the system. The power LED turns white when the system

is turned on.

While the unit is powered on, touch the power button for at least one second to check

the battery status. The 5 volume LEDs will light up to show the battery status.

One LED lit indicates 20% battery life; two LEDs indicate 40% battery life, and so on.

When all 5 LEDs are lit, the internal battery is fully charged.

To turn the speaker off, touch the Power button for more than 2 seconds.

The speaker will go into power saving mode automatically after 10 minutes if no music

stream is detected. The power LED will turn amber and all other LEDs will be turned off.

To turn the speaker on, press the power button for more than 2 seconds.

Produkspesifikasjoner

Merke:	Harman Kardon
Kategori:	Høyttaler
Modell:	Onyx
Bredde:	164 mm
Dybde:	300 mm
Høyde:	275 mm
Batterikapasitet:	2500 mAh
AC-adapter inngangsspenning:	100 - 240 V
Bluetooth:	Ja
Bluetooth-versjon:	3.0+HS
Tilkoblingsteknologi:	Trådløs
Strømkildetype:	AC, Battery
Impedans:	- Ω
Diskanthøyttaler:	Ja
Strømforbruk (standby):	0.5 W
Produktfarge:	Sort
Kabler inkludert:	AC
Batterispenning:	11.1 V
Strømforbruk (vanlig bruk):	120 W
Fjernkontroll medfølger:	Ja
Hurtigstartsguide:	Ja
Signal-til-støy-forhold (SNR):	90 dB
Batteristrøm:	3 A
Lyd-utgang kanaler:	- kanaler
RMS-rangert strøm/utgangseffekt:	- W
Fjerndrevet:	Ja
Antall drivere:	4
Frekvensrekkevidde:	60 - 20000 Hz
Basshøyttalerens diameter:	76.2 mm
Diskant diameter:	19.05 mm
AC-adapter frekvens:	50 - 60 Hz
