Side 1/14

Active speaker soundbar

SB 16

Owner’s Manual

SB 16

Table of Contents

INTRODUCTION 3

DESCRIPTION AND FEATURES 3

INCLUDED ITEMS 3

SOUNDBAR TOP-PANEL CONTROLS 4

SOUNDBAR REAR-PANEL CONTROLS AND CONNECTIONS 4

SUBWOOFER REAR-PANEL CONTROLS 5

SPEAKER PLACEMENT 6

PLACING THE SOUNDBAR ON A TABLE 6

WALL-MOUNTING THE SOUNDBAR 6

PLACING THE SUBWOOFER 6

CONNECTIONS 7

SOURCE CONNECTIONS 7

POWER CONNECTIONS 8

OPERATION 9

TURNING THE SOUNDBAR ON AND OFF 9

TURNING THE SUBWOOFER ON AND OFF 9

ADJUSTING THE SYSTEM’S VOLUME 9

MUTING THE SYSTEM 9

SOUNDBAR SURROUND MODE BUTTON 9

SOUNDBAR SRC (SOURCE) BUTTON 9

SUBWOOFER VOLUME KNOB 10

SOUNDBAR TRIM SWITCH 10

WIRELESS CODE SWITCHES 10

SUBWOOFER CROSSOVER KNOB 10

SUBWOOFER PHASE SWITCH 10

PROGRAMMING THE SOUNDBAR TO RESPOND TO YOUR TV REMOTE 11

TROUBLESHOOTING 12

SPECIFICATIONS 13

Introduction, Description and Features, Included Items

SB 16

Introduction

Please register your product on our Web site at

www.harmankardon.com.

Note: You’ll need the product’s serial number.

At the same time, you can choose to be

notiﬁed about our new products and/or special

promotions.

Thank you for purchasing the harman kardon

SB 16 speaker system, with which you’re

about to begin many years of listening enjoyment. The SB 16 has been custom-designed

to provide the excitement and power of the cinema experience in your own living room.

While sophisticated electronics and state-of-the-art speaker components are hard at

work within the SB 16, hookup and operation are simple.

To obtain maximum enjoyment from your new soundbar speaker system, we urge

you to take a few minutes to read through this manual. This will help ensure that the

connections you make are correct. In addition, a few minutes spent learning the functions

of the various controls will enable you to take advantage of all the power and reﬁnement

the SB 16 is able to deliver.

If you have any questions about this product, its installation or its operation, please

contact your retailer or custom installer, or visit our Web site at www.harmankardon.com.

Description and Features

The SB 16 is a complete home theater speaker system that includes:

s!VIDEOSHIELDEDSTEREOSOUNDBARSPEAKERTHE3"#42WITHTWOWAYDUAL

driver left and right speakers and built-in 25-watt x 2 stereo ampliﬁer

s!INCHMMWATTWIRELESSPOWEREDSUBWOOFERTHE3"35"

s7ALLMOUNTBRACKETSFORTHESOUNDBAR

s!FOOTMSTEREOAUDIOCABLEFORCONNECTINGTHESYSTEMDIRECTLYTOYOUR46S

audio output.

The SB 16CTR soundbar contains the system’s left and right speakers and stereo

ampliﬁers, and features digital signal processing with virtual 3D surround circuitry that

creates a complete surround-sound experience without any extra speakers or wires. You

can set the soundbar on a table in front of your TV; also, the system includes hardware

that makes it easy to mount the soundbar on the wall along with your ﬂat-panel TV. You

can program the soundbar to respond to your TV remote’s volume, power and source

commands.

The SB 16 SUB subwoofer receives its signal from the SB 16CTR soundbar via wireless

technology, so you can place it anywhere in your room without having to run any wires.

Its 10-inch (250mm) woofer and built-in 100-watt ampliﬁer deliver a movie’s impact and

excitement. Other conveniences include a volume control, a phase switch for ﬁne-tuning

bass performance to suit your listening environment, and an efﬁcient switching system

that senses the presence of an audio signal and automatically switches the subwoofer on.

harman kardon invented the high-ﬁdelity receiver more than 50 years ago. With state-

of-the-art features and time-honored circuit designs, the SB 16 system will turn your

ﬂat-screen TV into a fun and exciting home theater.

Included Items

One SB 16 CTR soundbar speaker

One SB 16 SUB 10-inch (250mm) 100-watt wireless subwoofer

Two sets of wall-mount brackets for the soundbar – one shallow and one extended (for

when the optical digital audio input is being used)

Two rubber feet One 24V DC power supply and one AC power

cord for the SB 16CTR speaker

One 1.5m (5-ft) optical digital audio cable

One 2m (6.5-ft) stereo audio cable

Important:

If anything is missing, or if any part of your SB 16 system fails to operate

properly, contact your dealer immediately.

Produkspesifikasjoner

Merke:	Harman Kardon
Kategori:	lydrekke
Modell:	SB 16
Tilkoblingsteknologi:	Ledning & Trådløs
FM-radio:	Nei
Impedans:	8 Ω
AC-inngangsspenning:	230 V
AC-inngangsfrekvens:	50 - 60 Hz
Produktfarge:	Sort
Strømforbruk (vanlig bruk):	100 W
Total Harmonic Distortion (THD):	0.07
Subwoofer inkludert:	Ja
Subwoofer-vekt:	15400 g
Lyd-utgang kanaler:	2.1 kanaler
RMS-rangert strøm/utgangseffekt:	- W
Mottaker medfølger:	Nei
Frekvensrekkevidde:	45 - 20000 Hz
Subwoofer RMS-styrke:	100 W
Apple docking-kompabilitet:	Støttes ikke
Subwooferens dimensjoner (BxDxH):	380 x 380 x 480 mm
Diskanthøyttalerens diameter:	0.75 "
Diameter på mellomtone-driver (imperisk):	3 "
Overgangsfrekvens:	2200 Hz
Antall drivere til diskant:	1
Frekvensomgang subwoofer:	45 - 200 Hz
Subwoofer-tilkoblingsevne:	Trådløs
Lydplankevekt:	3670 g
Antall mellomtonedrivere:	2
Dokkingtilkoblingstype:	Støttes ikke
Lydplankens dimensjoner (BxDxH):	920 x 89 x 110 mm
