TU 980

OWNER’S MANUAL

ENGLISH

2 TABLE OF CONTENTS

3 Introduction

4 Front Panel Controls

5 Rear Panel Connections

6 Remote Control Functions

7 Installation and Connections

8 Operation

8 Basic Operation

8 Station List

9 Preset Setting

9 Function Control

9 Station Order

9 Signal Error Rate

10 Preset Tune

11 RDS Operation

12 Troubleshooting Guide

13 Technical Specifications

Table of Contents

Typographical Conventions

In order to help you use this manual with the remote control, front-panel controls and rear-panel

connections, certain conventions have been used.

EXAMPLE

– (bold type) indicates a specific remote control or front-panel button, or rear-panel

connection jack

EXAMPLE

– (OCR type) indicates a message that is visible on the front-panel information

display



– (number in a square) indicates a specific front-panel control



– (number in a circle) indicates a rear-panel connection

– (number in an oval) indicates a button or indicator on the remote

Declaration of Conformity

We, Harman Consumer Group, Inc.

2, Route de Tours

72500 Château-du-Loir,

FRANCE

declare in own responsibility, that the product described

in this owner’s manual is in compliance with technical

standards:

EN55013(2001) & + A2(2006)

EN55020(2002) & + A2(2005)

EN60065:2002

EN61000-3-2(2000)+A2(2005)

EN61000-3-3 (1995)+A1(2001)+A2(2005)

EN61000-4-2(1995) & + A1(1998) & + A2(2001)

EN61000-4-3(2002) & + A1(2002)

EN61000-4-4(2004)

Jurjen Amsterdam

Harman Consumer Group, inc.

12/07

Congratulations! With the purchase of the

Harman Kardon TU 980 you are about to begin

many years of listening enjoyment.

While sophisticated systems are hard at work

within the TU 980 to make all of this happen,

hookup and operation are simple.

To obtain maximum enjoyment from your new

tuner, we urge you to take a few minutes to read

through this manual. This will ensure that

connections are made properly. In addition, a

few minutes spent learning the functions of the

various controls will enable you to take

advantage of all the power the TU 980 is able to

deliver.

If you have any questions about this product, its

installation or operation, please contact your

dealer. He is your best local source of information.

Description and Features

The TU 980 is equipped with a Dual Band DAB

(Digital Audio Broadcast) tuner and RDS (Radio

Data System), bringing a wide range of informa-

tion to radio listeners.

Until now, analogue radio signals such as FM

or AM have been subject to numerous kinds of

interference on their way from the transmitter to

your radio. These problems were caused by

mountains, high-rise buildings and weather

conditions.

With DAB, you can now receive CD-like quality

radio programs without any annoying interference

and signal distortion.

Now in use in many countries, RDS is a system

for transmitting station identification, a descrip-

tion of the station’s program type, indication of

national, regional or local programs and the

correct time. RDS also allows you to search for

favorite program types. A DOT-matrix display

brings all this information to you with high

visibility. As more FM stations become equipped

with RDS capabilities, the TU 980 will serve as

an easy to use center for both information and

entertainment.

READ THIS BEFORE OPERATING

YOUR UNIT.

Install this tuner in a well ventilated, cool, dry,

clean place with at least 10 cm on the top,

10 cm on the left and right, and 10 cm at the

back – away from direct sunlight, heat sources,

vibration, dust, moisture, and/or cold.

Avoid installing this unit where foreign object

may fall onto this unit and/or this unit may be

exposed to liquid dripping or splashing. On the

top of this unit, do not place:

– Burning objects (i.e. candles), as they may

cause fire, damage to this unit, and/or

personal injury.

– Containers with liquid in them, as they may

fall and liquid may cause electrical shock to

the user and/or damage to this unit.

Do not cover this unit with a newspaper, table-

cloth, curtain, etc. in order not to obstruct heat

radiation. If the temperature inside this unit

rises, it may cause fire, damage to this unit,

and/or personal injury.

Install this unit near the AC outlet and where the

AC power plug can be reached easily.

This unit is not disconnected from the AC power

source as long as it is connected to the wall out-

let, even if this unit itself is turned off. This state

is called the standby mode. In this state, this unit

is designed to consume a very small quantity of

power.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC

SHOCK, DO NOT EXPOSE THIS APPLIANCE

TO RAIN OR MOISTURE.

ENGLISH

INTRODUCTION 3

Introduction

Produkspesifikasjoner

Merke:	Harman Kardon
Kategori:	Hi-fi system
Modell:	TU 980
Vekt:	3400 g
Bredde:	442 mm
Dybde:	334 mm
Høyde:	63 mm
FM-bånd:	87.5 - 108 MHz
Strømforbruk (standby):	3 W
Produktfarge:	Sort
Strømforbruk (vanlig bruk):	11 W
Fjernkontroll medfølger:	Ja
inngangsimpedans:	50 Ω
Signal-til-støy-forhold (SNR):	65 dB
Krav til strømforsyning:	220 - 230V AC, 50/60Hz
Støttede radiobånd:	AM, DAB, FM
RDS-mottaker inkludert:	Ja
AM båndbredde:	522 - 1620 kHz
Digital koaksialutgang for lyd:	1
Optisk digital lydutgang:	1
Fjernkontrollinngang:	1
DAB-tuner:	Ja
DAB III båndområde:	174 MHz
DAB L båndområde:	1452 MHz
