Heinner HVC-MLED700BL Bruksanvisning

Heinner Støvsuger HVC-MLED700BL

Les nedenfor 📖 manual på norsk for Heinner HVC-MLED700BL (20 sider) i kategorien Støvsuger. Denne guiden var nyttig for 24 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF
Side 1/20
• LED display
• Power: 700W
• Capacity: 3.5 L
VACUUM CLEANER
Model: LumaClean
HVC-MLED700BL
www.heinner.com
1
1. INTRODUCTION
Please read the instructions carefully and keep the manual for future information.
This manual is designed to give all necessary instructions concerning installation, use and maintenance of the
unit. In order to operate the unit correctly and safely, please read this instruction manual carefully before
installation and use.
2. CONTENT OF YOUR PACKAGE
➔ Vacuum cleaner
➔ User manual
➔ Certificate of warranty
➔ Declaration of conformity
3. SAFETY MEASURES
Keep the manual in a safe place for future reference, along with the completed warranty card, purchase
receipt and carton. If applicable, pass these instructions on to the next owner of the appliance.
Always follow basic safety precautions and accident prevention measures when using an electrical
appliance, including the following:
1. Read all instructions carefully before using the appliance and keep them for future reference.
2. Make sure the dust bag is properly installed before use.
3. Check that the voltage marked on the rating label matches your main voltage.
4. Never vacuum up water or any other liquids. Never vacuum up flammable substances and do not vacuum
up ashes until they are cold.
5. Unplug the appliance from the mains socket when it is not in use and before replacing the filter.
6. Store and use the appliance well away from heat sources such as radiators or gas/electric powered heaters.
7. Do not continue to operate the appliance if you are in any doubt about it working normally (e.g. abnormal
noise, smell, smoke), or if it is damaged in any way- switch off, withdraw the main plug and consult your
dealer.
8. If the main cable is damaged, it must be replaced by the manufacturer, its service agent, or similarly
qualified persons in order to avoid a hazard.
9. This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
10. Children should be supervised to ensure that they do not play with the appliance.
11. The plug must be removed from the power socket before any maintenance or replacement.
www.heinner.com
2
4. USING THE PRODUCT
Assembly
Operation methods
A set of hose accessories are included: one extendible tube, one floor brush, one integrated brush & a nozzle.
1. Connecting the hose: insert the hose end into the hose connection opening at the front cover and then
lock it (Fig. 1).
2. Removing the hose: press the adaptors at both sides of the hose end and then pull the hose (Fig. 2).
3. Connect the metal telescopic tube to the curved end of the hose (Fig 3).
4. Connect different nozzles tools to the tube for different cleaning purposes: floor brush (adjusts to the type
of ground, for carpet or floor) (Fig. 4, 5).
5. Turn on the unit: insert the plug of the cable into the power socket which conforms to the voltage marked
on the rating label and press the ON/OFF button. The unit will start working (Fig. 6).
6. Cable rewinding: hold the plug and pull out the table, press the cable rewind button and the power cable
will be drawn in (Fig. 7).
1. Handle
2. Hose connection opening
3. Front cover
4. Speed control button
5. Cable rewind button
6. Back cover
7. ON/OFF button
8. Big wheel
9. Brush holder
10. Base body
11. Parquet nozzle
12. Crevice tool
13. Round brush
14. Small brush
15. Suction hose
16. Metal tube
17. Floor nozzle
18. Remote control
www.heinner.com
3
5. CLEANING AND MAINTENANCE
1. Changing the dust bag: when the Dust full indicator turns red, it is time to clean the dust or replace it with
a new bag (Fig 1).
2. Open the front cover by clipping (Fig 2, 3).
3. Take out the bag holder then remove the full dust bag (Fig 4).
4. The motor protection filter should be removed and rinsed once a year. Return it to the unit when dry. If
the filter is damaged, it should be replaced with a new one (Fig 5).
5. Washing or exchanging the outlet filter (HEPA): clip down and remove the outlet cover to wash or exchange
the filter (Fig 6, 7).
6. TROUBLESHOOTING
Less vacuum power of the cleaner:
1. The cleaner can be used to tip the rubbish out of the full dust cup or the dust bag.
2. If blockage is found in ground brush, hose or tubes, the machine can be re-operated only after the blockage
is cleared away.
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following data available: Model
and Serial Number.
The information can be found on the rating plate. Subject to change without notice.
TECHNICAL DATA
Voltage
220-240V~50/60 Hz
Power
700W
Thank you for purchasing this product. If you need support with your product, visit our website using the
links below.
Get User manuals: https://www.heinner.ro
Get Service information: https://www.heinner.ro
www.heinner.com
4
Environment friendly disposal
You can help protect the environment!
Please remember to respect the local regulations: hand in the non-working electrical equipment’s to
an appropriate waste disposal center.
HEINNER is a registered trademark of Network One Distribution SRL. Other brands and product
names are trademarks or registered trademarks of their respective holders.
No part of the specifications may be reproduced in any form or by any means or used to make any
derivative such as translation, transformation, or adaptation without permission from NETWORK
ONE DISTRIBUTION.
Copyright © 2013 Network One Distribution. All rights reserved.
www.heinner.com, http://www.nod.ro
This product is in conformity with norms and standards of European Community.
Importer: Network One Distribution
Marcel Iancu Street, 3-5, Bucharest, Romania
Tel: +40 21 211 18 56, www.heinner.com

Produkspesifikasjoner

Merke: Heinner
Kategori: Støvsuger
Modell: HVC-MLED700BL
