User’s Operating Manual

Interactive Intelligent Panel

Contents

Safety Warning & Statements

Connection and Setting

Menu Operation

Maintenance

Prepare to Install

Simple Troubleshooting

Safety Warning

Placement

Do not place the unit on an unstable cart, stand, tripod, bracket, table, or shelf.

Do not expose the unit to direct sunlight and other sources of heat.

Do not put the unit near appliances that generate magnetic ﬁelds.

Do not put any liquid near or on the unit, make sure do not spill any liquid inside the unit.

Do not put heavy objects on top of the unit.

Power Supply

Check that the unit’s operating voltage is identical with your local power supply.

Please unplug power supply and antenna plug when the weather is thunder-storm or lightning.

Please unplug power supply, when there is nobody home or the unit will be in idle for a long time.

Please keep power cable from physical or mechanical damage.

Please use the original power cable from the accessory bag, don't modify or lengthen it.

Please check and ensure AC source is connected with the ground.

This power cable comes with the device exclusively for this device only.

LED Screen

Never use any other hard or sharp object to replace the touch pen.

Unplug the power cable before cleaning.

Clean the screen with a soft, dustless and dry cloth.

Never use water or the spray type detergent to clean the unit.

For deep clean, please contact an authorized service center.

Better for the panel lifetime and the display performance, do not display high brightness image for long time.

Temperature

Do not place the unit near or over a radiator or a heater.

If your unit is suddenly moved from a cold to a warm place, please unplug the power cable and do not turn it on at least 2 hours,

making sure the moisture inside the unit is all evaporated.

Normal operating temperature is 0 ~ 40℃.

Humidity

Do not expose the unit in rain, or place in high humidity area.

Please make sure indoor environment is dry and cool.Normal operating humidity is 10%~90%RH.

Ventilation

Please put the unit in a well ventilated place, so the heating can be released easily.

Ensure that the unit has enough space for ventilation. Space requirement: left, right and back >10cm, top> 20cm.

Earphone

Using the earphone to listen loud sound for a long time might effect the hearing.

Before using earphone, please turn down the volume in advance.

Standby

It will enter standby mode but not turn off the unit after press the standby key.

Battery

Please make sure the battery get proper disposal or recycle after using.

Please keep the battery away from kids and don't throw the battery into fire.

Notes for Cleaning

There are vents on back cover, please do not use any liquid or spray directly during cleaning.

Power Switch Status Signs

“I” means power on, “O” means power off.

Notes for Maintenance

This machine can only be maintained by certiﬁed engineer.

Statements

not be reproduced, copied, or used in other ways without permission. Otherwise Guangzhou Shirui Electronics

Co., Ltd. will have the right to pursue legal responsibilities.

The image shown in this manual is indicative only. If there is inconsistency between the image and the actual

product, the actual product shall govern.

Produkspesifikasjoner

Merke:	HELGI
Kategori:	skjerm
Modell:	TDP86
Type baklys:	Direkte LED
Berøringsskjerm:	Ja
Synsvinkel, horisontal:	178 °
Skjermform:	Flat
Antall HDMI-porter:	3
Innebygde høyttalere:	Ja
Antall høyttalere:	2
Sertifisering:	CE
Full HD:	Ja
Maksimal oppdateringshastighet:	60 Hz
Innebygd mikrofon:	Nei
Internminne:	2048 MB
Prosessorarkitektur:	ARM Cortex-A53
Lydutgang:	1
HDMI:	Ja
HDMI-versjon:	1.4/2.0
Skjermteknologi:	LED
Innebygd kamera:	Nei
Antall DisplayPorts:	1
AMD FreeSync:	Nei
NVIDIA G-SYNC:	Nei
Antall USB Type-A nedstrømsporter:	6
Tilkobling til PC:	Ja
Antall samtidige berøringspunkter:	20
Berøringsskjermteknologi:	Infrarød
OPS-modulspor:	Ja
USB Touch-port:	Ja
Kontrastforhold:	1200:1
Skjermoppløsning:	3840 x 2160 piksler
Strømforbruk (standby):	0.5 W
Antall USB Touch-porter:	2
Skjermoverflate:	Gloss
Produktfarge:	Sort
Type strømforsyning:	AC
HD-type:	4K Ultra HD
Bredde (uten stativ):	1990 mm
Høyde (uten stativ):	1180 mm
Vekt (uten stativ):	78000 g
Skjermdiagonal:	86 "
LED-baklys:	Ja
Berøringsteknologi:	Multi-touch
Berøringsskjermtype:	Flere-bruker
Operativsystemprogramvare 04:	Android
RS-232-port:	1
Strømforbruk (vanlig bruk):	500 W
Antall VGA (D-Sub)-porter:	2
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Bærekraftsertifikater:	RoHS
Fjernkontroll medfølger:	Ja
Hurtigstartsguide:	Ja
VESA-montering:	Ja
Dybde (uten stativ):	100 mm
Synsvinkel, vertikal:	178 °
Innebygd prosessor:	Ja
Oppgraderbar fastvare:	Ja
Kan monteres på vegg:	Ja
Diagonal skjermstørrelse:	218.44 cm
Overflatehardhet:	Mhos 7
Ethernet/bredbåndsforbindelse:	Ja
Lysstyrke for skjerm:	330 cd/m²
Oppdateringsresponstid:	8 ms
Panelmonterbart grensesnitt:	800 x 600 mm
RMS-rangert strøm/utgangseffekt:	32 W
Display antall farger:	1.073 milliarder farger
Størrelseforhold:	16:9
Bildestørrelse, horisontal:	1895 mm
Bildestørrelse, vertikal:	1065 mm
Gjennomsnittstid mellom feil (MTBF):	30000 timer
Lydkontakter:	1
Synlig skjermområde (HxB):	1895 x 1065 mm
Digital koaksialutgang for lyd:	1
Operativsystem, versjon:	5.1
Skjermglasstype:	Herdet glass
Glasstykkelse:	4 mm
Pekepenn medfølger:	Ja
Kontrollerbar via nettverk:	RS232
Koordinatoppløsning:	32767 x 32767 piksler
Antall samtidige berøringspunkter (skriving):	10
