Side 1/24
N 3804AB3
Model Stapler
DANGER
Improper use of this Stapler can result in death or serious injury!
This Manual contains important information about product safety.
Read and understand this Manual before operating the Stapler.
Keep this Manual available for others before they use the Stapler.
Never allow anyone who has not reviewed this manual.
Instruction and safety manual
01Eng_N3804AB3_Eng 10/4/07, 19:501
IMPORTANT SAFETY INFORMATION ..................... 3
DEFINITIONS OF SIGNAL WORDS .......................... 3
EXPLANATION OF THE NAILING ACTION OF THE
HiKOKI
NAILER ................................................ 3
SAFETY
IMPORTANT SAFETY INSTRUCTIONS
FOR USING STAPLERS ..................................... 4
EMPLOYER’S RESPONSIBILITIES ............................ 6
OPERATION
NAME OF PARTS ...................................................... 7
SPECIFICATIONS ....................................................... 8
STAPLE SELECTION ................................................. 8
ACCESSORIES ........................................................... 8
STANDARD ACCESSORIES .............................. 8
OPTIONAL ACCESSORIES ................................ 9
APPLICATIONS .......................................................... 9
BEFORE OPERATION ................................................ 9
WORKING ENVIRONMENT ............................... 9
AIR SUPPLY ........................................................ 9
LUBRICATION .................................................. 10
COLD WEATHER CARE .................................... 10
TESTING THE STAPLER .................................. 10
ADJUSTING AIR PRESSURE ........................... 12
LOADING STAPLES ......................................... 12
STAPLER OPERATION ............................................ 12
METHODS OF OPERATION ............................. 13
ADJUSTING THE STAPLING DEPTH .............. 15
CHANGING THE EXHAUST DIRECTION ........ 16
USING THE NOSE CAP .................................... 16
MAINTENANCE
MAINTENANCE AND INSPECTION ....................... 16
SERVICE AND REPAIRS .......................................... 17
PARTS LIST .............................................................. 20
Page Page
CONTENTS
01Eng_N3804AB3_Eng 10/4/07, 19:502
3
IMPORTANT SAFETY INFORMATION
Read and understand tool labels and all of the operating instructions, safety precautions
and warnings in this manual before operating or maintaining this stapler.
Failure to follow warnings could result in DEATH or SERIOUS INJURY.
Most accidents that result from the operation and maintenance of Staplers are caused
by the failure to observe basic safety rules or precautions. An accident can often be
avoided by recognizing a potentially hazardous situation before it occurs, and by
observing appropriate safety procedures.
Basic safety precautions are outlined in the “SAFETY” section of this Manual and in the sections which contain
the operation and maintenance instructions.
Hazards that must be avoided to prevent bodily injury or machine damage are identified by DANGERS and
WARNINGS on the Stapler and in this Manual.
NEVER use this Stapler for applications other than those specified in this Manual.
DEFINITIONS OF SIGNAL WORDS
DANGER indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate
injury, or may cause machine damage.
NOTE emphasizes essential information.
EXPLANATION OF THE NAILING ACTION OF THE HiKOKI NAILER
䡬
SINGLE ACTUATION MECHANISM (SINGLE SEQUENTIAL ACTUATION MECHANISM):
First, press the push lever against the wood; next, pull the trigger to drive the fastener.
First, pull the trigger; next, press the push lever against the wood to drive the fastener.
After fastening once, fastening will not be possible again until the trigger is released and pressed again.
䡬
CONTACT ACTUATION MECHANISM:
First, press the push lever against the wood; next, pull the trigger to drive the fastener.
First, pull the trigger; next, press the push lever against the wood to drive the fastener.
If the trigger is held back, a fastener will be driven each time the push lever is pressed against the wood.
䡬
FULL SEQUENTIAL ACTUATION MECHANISM:
First, press the push lever against the wood; next, pull the trigger to drive the fastener.
Follow the same sequence to continue driving fasteners.
01Eng_N3804AB3_Eng 10/4/07, 19:503
