Side 1/20

ENGLISH

Projector

CP-A200

User's Manual (concise)

Thank you for purchasing this product.

Please read the manuals for the product beforehand, in order to use the product safely

and more effectively. To read the manuals in the CD, see the “

15. Using the CD

manual

” (



16).

Contents

1. Checking the contents ...................2

2. Arrangement ..................................2

3. Connecting with your devices ........4

4. Connecting with a power supply ....5

5. Using the security bar and slot ......6

6. Using the cable cover ....................6

7. Preparing for the remote control ....7

8. Starting the projector .....................8

9. Adjusting the projection position ....9

10. Operation .....................................9

11. Turning the projector off .............11

12. Replacing the lamp ....................12

13. Maintaining the air-lter .............14

14. Caring for the mirror and lens ....15

15. Using the CD manual ................16

16. Regulatory notices .....................17

17. Warranty and after-service ........18

18. Specications ............................19

 

WARNING

■ Before using this product, be sure to read all the manuals for the product. Heed all the

warnings and cautions in the manuals or on the product. Follow all the instructions in the

manuals or on the product. Retain the manuals in a safe place for future reference.

■ The manufacturer assumes no responsibility for any damage caused by mishandling

that is beyond normal usage defined in these manuals of this projector.

d11_01CP-A200_CO_ENG.indd 1 2009/12/22 9:37:50

(1) (2)

(3) (4)

(5) (6)

(7)

1. Checking the contents

Check that all the following items are included. If any items are missing, tell your dealer

soon.

(1) Projector

(2) Remote control with two batteries

(3) Power cord

(4) Computer cable

(5) Cable cover with a screw

(6) User’s manuals (a booklet, a CD)

(7) Security label

WARNING

■ Keep the original packing materials, and use for transporting this product.

2. Arrangement

Install the projector in a stable, cool, dry and airy place, keeping a space of 30 cm or more

between the sides of the projector and other objects such as walls.

Refer to the following to decide the projection style. For the case of installation in a

special state such as ceiling mount, the specified mounting accessories and service may be

required. Before installing the projector, consult your dealer about your installation.

(2) Ceiling mount

(1) Usual use

NOTE

• When installing the projector, confirm that there is nothing that blocks the projection

light between the projector and the screen.

• When installing the projector, check that the remote sensors are not exposed to any

strong ray (



7).

• Install the projector in the way specified in this manual. Otherwise the projection lamp

may not light.

VIDEO

DOC.CAMERA

KEYSTONE

ASPECT SEARCH

BLANK

MUTE

MY BUTTON

POSITION

1 2

ESC

ENTER

RESET

COMPUTER

MY SOURCE/

AUTO

MAGNIFY

VOLUME

ー

OFF

＋

FREEZE

FOCUS D-ZOOM

- + - +

d11_01CP-A200_CO_ENG.indd 2 2009/12/22 9:37:51

Produkspesifikasjoner

Merke:	Hitachi
Kategori:	videoprosjektor
Modell:	CP-A200
Produkttype:	Ultrakort stråleprojektor
Vekt:	5900 g
Støynivå:	35 dB
Wi-Fi:	Nei
Antall farger:	16.78 million farger
Matrisestørrelse:	0.63 "
DVI-port:	Nei
Innebygde høyttalere:	Ja
Antall innebygde høyttalere:	1
Hodetelefonutganger:	1
Full HD:	Nei
Digital zoom:	1.2 x
3D:	Nei
Dimensjoner (B x D x H):	397 x 131 x 356 mm
Kontrastforhold:	500:1
AC-inngangsspenning:	220 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Strømforbruk (standby):	5 W
Projektorens lysstyrke:	3000 ANSI lumen
Projektoroppløsning:	XGA (1024x768)
Produktfarge:	Hvit
Støttede grafikkoppløsninger:	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 768 (WXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Analogt signalformatsystem:	NTSC, NTSC 4.43, PAL, SECAM
Visningsteknologi:	LCD
Skjermstørrelsekompabilitet:	60 - 100 "
Projeksjonsavstand:	- m
Hjørnesteinsrettelse, horisontal:	-5 - 5 °
Hjørnesteinsrettelse, vertikal:	-20 - 20 °
Horisontalt frekvensområde:	50 - 120 kHz
Støynivå (økonomisk funksjon):	29 dB
Brennviddeområde:	- mm
RS-232-port:	1
Lyskildens tjenestetid:	2000 timer
Lyskildetype:	Lampe
Strømforbruk (vanlig bruk):	230 W
Støttede videofunksjoner:	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Antall VGA (D-Sub)-porter:	3
Lydinngang (V/H) inn:	1
Komponentvideo (YPbPr/YCbCr) inn:	1
Seriell grensesnittype:	RS-232
Driftstemperatur (T-T):	5 - 35 °C
Fjernkontroll medfølger:	Ja
Lampetype:	UHB
Antall S-Video-innganger:	1
Ethernet/bredbåndsforbindelse:	Nei
Komposittvideo inn/sammensatt video inn:	1
RMS-rangert strøm/utgangseffekt:	7 W
Lampens effekt:	230 W
Lyskildens tjenestetid (økonomisk modus):	3000 timer
Størrelseforhold:	4:3, 16:9
Kabellåsport:	Ja
Vertikal scanningsratio:	15 - 106 Hz
Kabellåstype:	Kensington
Lydkontakter:	2
Matrisetype:	3-panel (p-Si TFT aktiv)
