Projector

CP-SX1350

User's Manual - Operating Guide

Thank you for purchasing this projector.

TRADEMARK ACKNOWLEDGMENT :

• VGA and XGA are registered trademarks of International Business Machines Corporation.

• Apple and Mac are registered trademarks of Apple Computer, Inc.

• VESA and SVGA are trademarks of Video Electronics Standard Association.

• Windows is a registered trademark of Microsoft Corporation.

• Internet Explorer is a trademark of Microsoft Corporation.

All other trademarks are the property of their respective owners.

WARNING Before using the product, please read the "User's Manual -

Safety Guide" and related manuals to ensure the proper use of this product.

After reading them, store them in a safe place for future reference.

RGB

BNG

-VIDEO

ANDBY

VIDE

OMPO

KEYST

SEA

RCH

FOCUS

SHIF

• The information in this manual is subject to change without notice.

• The manufacturer assumes no responsibility for any errors that may appear in this manual.

• The reproduction, transfer or copy of all or any part of this document is not permitted without

express written consent.

NOTE

Projector Features

Preparation

●

Ultra High Brightness

Crisp, ultra-bright presentations is achieved by using a UHB (ultra high brightness) lamp and a highly

efficient optical system.

●

Whisper Mode Equipped

Special mode is available for reducing projector noise to achieve quieter operation.

●

User Memory Function

This projector can memorize 4 settings by MY MEMORY function.

●

Partial Magnification Function

Interesting parts of images can be magnified for closer viewing.

●

Keystone Distortion Correction

Quick correction of distorted images electrically.

●

Optical Lens Shift

The lens of this projector can be shifted vertically. When you want to finely adjust the picture position,

use the LENS SHIFT buttons.

This multimedia projector is used to project various computer signals as well as

NTSC/PAL/SECAM video signals onto a screen. Little space is required for

installation and large images can easily be realized.

Please see the “Contents Of Package” of the “User’s Manual – Quick Guide”.

Your projector should come with the items shown there. Contact immediately

your dealer if anything is missing.

• Keep the original packing materials for future reshipment. For moving the projector, be

sure to use the original packing materials. Use special caution for the lens part.

NOTE

3
Content
Content
Projector Features
……………………………………
2
Preparation
……………………………………………………
2
Part Names
……………………………………………………
4
Projector ……………………………4
Control Buttons ……………………5
Remote control ……………………5
Setting Up
…………………………………………………………
6
Arrangement ………………………6
Adjusting The Projector’s
Elevator ……………………………7
Using The Lens shift Buttons ……7
Connecting Your Devices…………8
Connecting The Power Supply …11
Remote Control
…………………………………………
12
About The Laser Pointer ………12
Loading Batteries ………………12
Operating The
Remote Control …………………13
Using The Remote
ID Feature…………………………13
Using The Mouse/Keyboard
Control Function …………………14
Power ON/OFF
…………………………………………
15
Turning On The Power …………15
Turning Off The Power …………15
Operating
……………………………………………………
16
Selecting An Input Signal ………16
Selecting The Aspect Ratio ……17
Using The Automatic
Adjustment Feature………………17
Adjusting The Picture Position …18
Correcting The Keystone
Distortion …………………………18
Adjusting The Volume …………19
Muting The Sound ………………19
Temporarily Blanking
The Screen ………………………19
Freezing The Screen ……………20
Using The Magnify Feature ……20
Displaying The Child Window …21
Selecting An Audio Input ………21
Multifunctional Settings
……………………
22
Using The Menu Functions ……22
MAIN Menu ………………………23
PICTURE-1 Menu ………………24
PICTURE-2 Menu ………………26
INPUT Menu ……………………27
AUTO Menu ………………………29
SCREEN Menu …………………31
OPTION Menu ……………………33
NETWORK Menu ………………35
Network Setting Up
………………………………
36
Lamp
………………………………………………………………
37
Replacing The Lamp ……………38
Air Filter
…………………………………………………………
39
Caring For The Air Filter…………39
Other Care
……………………………………………………
40
Caring For The Inside Of
The Projector ……………………40
Caring For The Lens ……………40
Caring For The Cabinet And
Remote Control …………………40
Troubleshooting
……………………………………
41
Related Messages ………………41
Regarding The Indicator
Lamps ……………………………43
Phenomena That May Easily Be
Mistaken For Machine Defects …45
Warranty And After-Service
…………
47
Specifications
…………………………………………
47
TECHNICAL

Produkspesifikasjoner

Merke:	Hitachi
Kategori:	videoprosjektor
Modell:	CP-SX1350
Vekt:	7700 g
Antall USB 2.0-porter:	1
Antall innebygde høyttalere:	1
Sertifisering:	CE, DEMKO EN60950
Dimensjoner (B x D x H):	420 x 320 x 160 mm
Projektorens lysstyrke:	3500 ANSI lumen
Type strømforsyning:	100 - 120/220 - 240V AC
Analogt signalformatsystem:	NTSC, PAL 60, SECAM
Kabler inkludert:	AC, VGA
Visningsteknologi:	LCD
Skjermstørrelsekompabilitet:	0.99 "
Hjørnesteinsrettelse, vertikal:	10:0~1:1 °
Horisontalt frekvensområde:	15 - 106 kHz
Brennviddeområde:	31 - 46 mm
RS-232-port:	1
Lyskildens tjenestetid:	2000 timer
Lyskildetype:	Lampe
Strømforbruk (vanlig bruk):	470 W
Lydinngang (V/H) inn:	2
Seriell grensesnittype:	RS-232
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Lampetype:	UHB
Antall S-Video-innganger:	1
Nettverksgrensesnitt:	1 x RJ-45
Videoopptaksgrensesnitt:	15-pin mini D-sub
Lydutgang (venstre/høyre):	2
RMS-rangert strøm/utgangseffekt:	2 W
Lampens effekt:	310 W
Display antall farger:	16.78 million farger
Vertikal scanningsratio:	50 - 120 Hz
Plugg inn og spill:	Ja
Fokuseringsområde:	1.7 - 2.4
