Projector

CP-AW250N

User's Manual (detailed)

Operating Guide

Thank you for purchasing this projector.

►Before using this product, please read all manuals for this

product. Be sure to read “Safety Guide” rst. After reading them, store them in a

safe place for future reference.

WARNING

• The information in this manual is subject to change without notice.

• The manufacturer assumes no responsibility for any errors that may appear in

this manual.

• The reproduction, transfer or copy of all or any part of this document is not

permitted without express written consent.

NOTE

Trademark acknowledgment

Various symbols are used in this manual. The meanings of these symbols are

described below.

About this manual

WARNING

CAUTION

This symbol indicates information that, if ignored, could possibly

result in personal injury or even death due to incorrect handling.

This symbol indicates information that, if ignored, could possibly

result in personal injury or physical damage due to incorrect

handling.

Please refer to the pages written following this symbol.



• Mac

is a registered trademark of Apple Inc.

• Windows

, DirectDraw

and Direct3D

are registered trademarks of Microsoft Corporation

in the U.S. and/or other countries.

• VESA and DDC are trademarks of the Video Electronics Standard Association.

•

HDMI, the HDMI logo, and High-Denition Multimedia Interface are trademarks or registered

trademarks of HDMI Licensing LLC in the United States and other countries.

• Trademark PJLink is a trademark applied for trademark rights

in Japan, the United States of America and other countries and

areas.

• Blu-ray Disc

and Blu-ray

are trademarks of Blu-ray Disc Association.

All other trademarks are the properties of their respective owners.

NOTICE This entry notices of fear of causing trouble.

(Type nos. CP-AW250N, CP-AW250NM)

Contents

Introduction . . . . . . . . . . . . . . . 3

Features . . . . . . . . . . . . . . . . . . . . . . 3

Checking the contents of package

...3

Part names . . . . . . . . . . . . . . . . . . . . 4

Setting up . . . . . . . . . . . . . . . . . 7

Arrangement ...................7

Connecting with your devices

......9

Connecting to a power supply

.....14

Using the security bar and slot . . . . 14

Using the cable cover ...........15

Remote control ............16

Installing the batteries ...........16

About the remote control signal . . . 16

Changing the frequency of remote control signal

. . 17

Using as a simple PC mouse & keyboard

. . 17

Power on/off . . . . . . . . . . . . . . 18

Turning on the power . . . . . . . . . . . 18

Turning off the power . . . . . . . . . . . 19

Operating . . . . . . . . . . . . . . . . 20

Adjusting the volume ............20

Temporarily muting the sound .....20

Selecting an input signal .........20

Searching an input signal . . . . . . . . 22

Selecting an aspect ratio .........22

Adjusting the projector's elevator . . 23

Adjusting the zoom and focus .....23

Using the automatic adjustment feature

...24

Adjusting the position . . . . . . . . . . . 25

Correcting the keystone distortions

. . 25

Using the magnify feature ........26

Temporarily freezing the screen . . . 27

Temporarily blanking the screen . . 27

Using the menu function . . . . . . . . 28

EASY MENU. . . . . . . . . . . . . . . 30

As p e c t ,

D-z o o m ,

Ke y s t o n e , Ke y s t o n e ,

pe r f e c t f i t

pi c t u r e m o D e ,

ec o m o D e ,

i r r o r , re s e t , fi l t e r t i m e , lA n g u A g e ,

D v A n c e D m e n u , ex i t

PICTURE menu . . . . . . . . . . . . 32

Br i g h t n e s s , co n t r A s t , gA m m A , co l o r t e m p ,

co l o r , ti n t , sh A r p n e s s , Ac t i v e i ri s, my m e m o r y

IMAGE menu . . . . . . . . . . . . . . 35

As p e c t , ov e r s c A n , v p o s i t i o n , h p o s i t i o n ,

p h A s e , h s i z e , Au t o A D j u s t e x e c u t e

INPUT menu . . . . . . . . . . . . . . 38

pr o g r e s s i v e , vi D e o n r , co l o r s p A c e ,

i D e o f o r m A t , hD m i f o r m A t , hD m i r A n g e ,

o m p u t e r i n, fr A m e l o c K , re s o l u t i o n



SETUP menu ..............42

D-z o o m , D-s h i f t , pi c t .p o s i t .h,

Ke y s t o n e , Ke y s t o n e , pe r f e c t f i t

u t o e c o m o D e , ec o m o D e ,

mi r r o r ,

t A n D B y m o D e , mo n i t o r o u t

AUDIO menu . . . . . . . . . . . . . . 45

vo l u m e , sp e A K e r , Au D i o s o u r c e ,

D m i A u D i o , mic l e v e l , mi c v o l u m e

SCREEN menu .............47

lA n g u A g e , me n u p o s i t i o n , Bl A n K ,

t A r t u p ,

yScreen

, M

yScreen Lock

e s s A g e , so u r c e n A m e , te m p l A t e , c.c.

OPTION menu . . . . . . . . . . . . . 53

Au t o s e A r c h , Di r e c t p o w e r o n ,

u t o p o w e r o f f , us B t y p e B, lA m p t i m e ,

i l t e r t i m e , my B u t t o n , my s o u r c e ,

e r v i c e

NETWORK menu ...........64

se t u p , pr o j e c t o r n A m e , my i m A g e ,

m x D.D., pr e s e n t A t i o n , in f o r m A t i o n ,

e r v i c e

SECURITY menu ...........71

se c u r i t y p A s s w o r D c h A n g e ,

yScreen

p A s s w o r D , pi n l o c K ,

r A n s i t i o n D e t e c t o r , my t e x t p A s s w o r D ,

y t e x t D i s p l A y , my t e x t w r i t i n g

Presentation tools . . . . . . . . . 77

PC-LESS Presentation

. . . . . . . 77

Thumbnail Mode, Full Screen Mode,

Slideshow mode, Playlist

USB Display

..............

Right-Click menu, Floating menu,

Options window

Maintenance ..............89

Replacing the lamp .............89

Cleaning and replacing the air lter . . 91

Replacing the internal clock battery

. . 93

Caring for the mirror and lens

.......94

Other care ....................95

Troubleshooting . . . . . . . . . . . 96

Related messages . . . . . . . . . . . . . 96

Regarding the indicator lamps . . . . 98

Resetting all settings ...........100

Phenomena that may be easy

to be mistaken for machine defects

. 100

Specications ............104



Introduction

• Keep the original packing materials, for future reshipment. Be sure

to use the original packing materials when moving the projector. Use special

caution for the lens.

NOTE

Introduction

The projector provides you with the broad use by the following features.

Checking the contents of package

ü The unique lens and mirror system realizes ultra short distance

projection,which gives you more various way of use.

ü The motorized lens door offers you very simple use of the projector.

The double layer lter system is expected to function longer and offers you

less maintenance frequency.

ü The HDMI port can support various image equipment which have digital

interface to get clearer pictures on a screen.

ü This projector can be controlled and monitored via LAN connection.

ü This projector's network supports the PJLink

standard.

ü PJLink

is a unied standard for operating and controlling data projectors.

PJLink

enables central control of projectors manufactured by different vendors

and projectors can be operated by a controller. PJLink

compliant equipment

can be managed and controlled at any time and in any place, regardless of

manufacturer.

For the command of PJLink

, see “Technical”.

For specications of PJLink

, see the web site of the Japan Business Machine

and Information System Industries Association.

URL: http://pjlink.jbmia.or.jp (as of Dec. 2009)

Please see the Contents of package section in the User’s Manual (concise)

which is a book. Your projector should come with the items shown there. Require

of your dealer immediately if any items are missing.

Features

Produkspesifikasjoner

Merke:	Hitachi
Kategori:	videoprosjektor
Modell:	CP-AW250N
Vekt:	3800 g
Bredde:	345 mm
Dybde:	303 mm
Høyde:	85 mm
Støynivå:	- dB
Bluetooth:	Nei
Plassering:	Tak
Wi-Fi:	Nei
USB-kontakttype:	USB Type-A, USB Type-B
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Matrisestørrelse:	0.59 "
Antall USB 2.0-porter:	2
Antall HDMI-porter:	1
DVI-port:	Nei
Innebygde høyttalere:	Ja
Sertifisering:	UL/cUL, FCC Part 15 Class A, AS/NZS CISPR22 Class A, CE, RoHS, GOST-R
Full HD:	Nei
3D:	Nei
Lydutgang:	1
Dimensjoner (B x D x H):	345 x 303 x 85 mm
Kontrastforhold:	2000:1
AC-inngangsspenning:	100 - 240 V
Strømforbruk (standby):	- W
Projektorens lysstyrke:	2500 ANSI lumen
Projektoroppløsning:	WXGA (1280x800)
Produktfarge:	Hvit
Støttede grafikkoppløsninger:	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 640 x 480 (VGA), 800 x 600 (SVGA)
Analogt signalformatsystem:	NTSC, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM
Kabler inkludert:	VGA
Visningsteknologi:	LCD
Skjermstørrelsekompabilitet:	11.6 - 70.5 "
Projeksjonsavstand:	0.12 - 0.392 m
Zoomfunksjon:	Ja
Brennviddeområde:	- mm
RS-232-port:	1
Lyskildens tjenestetid:	- timer
Lyskildetype:	Lampe
Støttede videofunksjoner:	1080i, 1080p, 480i, 480p, 576i, 720p
Antall VGA (D-Sub)-porter:	3
Lydinngang (V/H) inn:	1
Mikrofon, linje-inn-støpsel:	Ja
Seriell grensesnittype:	RS-232
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	5 - 35 °C
Innebygd kortleser:	Nei
Fjernkontroll medfølger:	Ja
Lampetype:	UHP
Antall S-Video-innganger:	1
Ethernet/bredbåndsforbindelse:	Ja
Komposittvideo inn/sammensatt video inn:	1
Lydutgang (venstre/høyre):	1
RMS-rangert strøm/utgangseffekt:	10 W
Batterier medfølger:	Ja
Lampens effekt:	210 W
Type CardBus PCMCIA-port:	Nei
Optisk diskettspillertype:	Ikke inkludert
Størrelseforhold:	16:10
Kabellåsport:	Ja
Kabellåstype:	Kensington
Lydkontakter:	2
Zoom-forhold:	1.2:1
3D Ready:	Nei
Matrisetype:	3-panel (p-Si TFT aktiv)
HD-Ready:	Ja
