Side 1/4

CP-WX3015WN LCD Projector

Classroom and

Conference Room

Series

High performance LCD projector

captures attention in classrooms or

conference rooms with dynamic images

and 3,000 ANSI lumens.

Key Features



WXGA 1280 x 800 resolution



3,000 ANSI lumens white/color output



16 watt audio output



3000:1 contrast ratio



HDMI 1 input



5,000 hours lamp life (Standard mode)

and 6,000 hours lamp life (Eco mode)**



Power saving standby mode less

than .5W

1800 HITACHI

dps@hitachi.com.au

www.hitachi.com.au/dps

CP-WX3015WN

From the classroom to the conference room, Hitachi’s CP-WX3015WN LCD

projector combines superior image clarity, high quality value, and long-life

reliability. Bright, vivid colors with razor-sharp text and bold graphics will

truly enhance any lesson or meeting and make it more memorable.

For greater installation convenience, the CP-WX3015WN has a cloning

function which enables you to copy setting data from one projector to others

of the same model via USB memory. Plus, Hitachi’s Intelligent Eco

and Saver Modes with ImageCare combines optimal picture performance

with maximum energy savings for a lower total cost of ownership. For added

peace of mind, Hitachi’s CP-WX3015WN is also backed by a generous

warranty and our world-class service and support programs.

STANDARD FEATURES

CP-WX3015WN LCD Projector

Classroom and

Conference Room

Series

UNIQUE FEATURES

Display via USB

Simply plug and play using the USB port instead of the

15-pin D-sub VGA cable.

Network Control, Maintenance and Security

Embedded networking gives you the ability to manage and

control multiple projectors over your LAN. Features include

scheduling of events, centralized reporting, image transfer and

e-mail alerts for reactive and routine maintenance.

PC-Less Presentation

By using a USB memory stick or other stor-

age device, you can use the projector without

a computer. Menus are easy to see with a

thumbnail display. Additionally there is also a

slideshow function.

PIN Lock / MyScreen / MyText

PIN lock protection can limit projector users. MyScreen PIN

lock keeps captured images on the startup screen. Users can

set any name logo to MyScreen, clearly identifying ownership.

MyText provides the ability to write text on the startup screen

such as model name, serial number or location.

PJMessenger

PJMessenger function allows you to send and display text

messages and audio alerts on your networked projectors. It

is an easy and efﬁcient way to send announcements out to

multiple units.

Present Content via LAN

Hitachi’s suite of networking software allows you to easily

send content directly from your PC to the projector via your

LAN connection.

Serial Number and Media Access Control Label

A label is afﬁxed to side of projector to more easily access

and read the model name, serial number and MAC address

while mounted in ceiling use. This is a convenience for

installers, end users and auditors for instant accessibility.

Serial #

Wireless Presentation Ready

You can use a wireless network by connecting the projector

to a computer using the optional USB wireless adapter part

number USBWL11N. The adapter supports IEEE802.11b/g

and the latest 11n.

Cloning Function

Copy setting data from one projector to others of the same

model via USB memory. Cloning can save almost all PJ

settings such as gamma and keystone via USB memory.

Intelligent Eco and Saver Modes

Automatically changes the brightness of the lamp according to

the brightness level of the screen. Also, automatically changes

the brightness of the lamp if there is no change in the screen

image. Using ImageCare technology, these features give

optimal picture performance with maximum energy savings.

Input Source Naming

Users can name input sources in simple language instead of

factory default name. Exclusive to Hitachi.

Hitachi Australia Pty Ltd

123 Epping Road, Macquarie Park, North Ryde 2113

Toll Free: 1800 HITACHI

Email: dps@hitachi.com.au

Web: www.hitachi.com.au/dps

HI0139-11/12 WEB

All speciﬁcations subject to change without notice.

3LCD and the 3LCD logo are registered trademarks of the Seiko Epson Corporation.

* Actual ﬁlter life will vary by individual ﬁlter and based on environmental conditions, selected operating mode, user settings

and usage. Hours of average ﬁlter life speciﬁed are not guaranteed and do not constitute part of the product warranty.

** Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user

settings and usage. Hours of average lamp life speciﬁed are not guaranteed and do not constitute part of the product or

lamp warranty. Lamp brightness decreases over time.

Microphone Input

A microphone can be used via the jack located on the

input panel. Allows for more dynamic presentations even in

standby mode.

ImageCare Technology

ImageCare is a lamp power control function that combines

optimal picture performance with maximum energy savings

by decreasing energy usage, improving contrast ratio and

lengthening lamp life. The result is a lower total cost of

ownership and decreased maintenance cost.

CP-WX3015WN LCD Projector

Long-life reliability with a lower

total cost of ownership.

From classrooms to conference rooms, Hitachi’s

CP-WX3015WN can make a big impact on your

audience. With 3,000 ANSI lumens brightness and

WXGA 1280 x 800 resolution, the CP-WX3015WN

is designed to make any message more memorable

with colorful images, crisp text, and powerfully

clear audio. Incorporating Hitachi’s leading-edge

technology, the CP-WX3015WN features high

contrast ratio, long lamp life, cloning function enabling

you to copy settings data from one projector to others

of the same model, and is wireless presentation ready.

Plus, embedded networking gives you the ability to

manage and control multiple projectors over your LAN

(scheduling of events, centralized reporting, image

transfer, and e-mail alerts). Even with the the array

of advanced features, Hitachi’s CP-WX3015WN is

designed for user-friendly operation and installation

convenience.

Input/Outputs

CP-WX3015WN

Left Proﬁle

Right Proﬁle

Top View

1314 12 9101115

2 3 54

1. USB Type A x 2

2. USB Type B

3. HDMI

4. Computer in 1

5. Computer in 2

6. Audio In 3

7. Audio in 1

8. Audio in 2

9. Composite Video

10. S-Video

11. Audio Out

12. Monitor Out

13. Microphone Input

14. Control (RS-232C)

15. Kensington Lock

16. Security Bar

17. LAN

HDMI

AMX Device

Discovery

Crestron

Integrated Partner

3 Year Warranty

3LCD Technology

Classroom and

Conference Room

Series

Front View

Hitachi Australia Pty Ltd

123 Epping Road, Macquarie Park, North Ryde 2113

Toll Free: 1800 HITACHI

Email: dps@hitachi.com.au

Web: www.hitachi.com.au/dps

HI0139-11/12 WEB

All speciﬁcations subject to change without notice.

3LCD and the 3LCD logo are registered trademarks of the Seiko Epson Corporation.

Produkspesifikasjoner

Merke:	Hitachi
Kategori:	videoprosjektor
Modell:	CP-WX3015WN
Vekt:	3600 g
Bredde:	317 mm
Dybde:	288 mm
Høyde:	98 mm
Støynivå:	29 dB
Strømkilde:	AC
Bruksanvisning:	Ja
Antall farger:	16.78 million farger
Antall USB 2.0-porter:	3
Antall HDMI-porter:	1
DVI-port:	Nei
Innebygde høyttalere:	Ja
Antall innebygde høyttalere:	2
Sertifisering:	UL60950-1/cUL, FCC, CE, EN61000-3-2, EN61000-3-3, EN55022, EN55024, EN60950, WEEE, ErP, DEMKO-GS, GOST-R
Full HD:	Nei
HDCP:	Ja
3D:	Nei
Luftfilter:	Ja
Støyreduksjon:	Ja
On Screen Display (OSD):	Ja
Forhåndsinnstilte moduser:	Cinema, Dynamic
Kontrastforhold:	3000:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Strømforbruk (standby):	0.5 W
Projektorens lysstyrke:	3000 ANSI lumen
Projektoroppløsning:	WXGA (1280x720)
Produktfarge:	Hvit
Naturlig sideforhold:	16:9
Analogt signalformatsystem:	NTSC, PAL, PAL M, PAL N, SECAM
Visningsteknologi:	3LCD
Skjermstørrelsekompabilitet:	30 - 300 "
Projeksjonsavstand:	- m
Hjørnesteinsrettelse, vertikal:	-30 - 30 °
Støynivå (økonomisk funksjon):	36 dB
Brennviddeområde:	- mm
Lyskildens tjenestetid:	5000 timer
Lyskildetype:	Lampe
Strømforbruk (vanlig bruk):	300 W
Støttede videofunksjoner:	1080i, 1080p, 480i, 480p, 576i
Antall VGA (D-Sub)-porter:	3
Lydinngang (V/H) inn:	1
Mikrofon, linje-inn-støpsel:	Ja
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Bærekraftsertifikater:	RoHS
Fjernkontroll medfølger:	Ja
Lampetype:	UHP
Antall S-Video-innganger:	1
Ethernet/bredbåndsforbindelse:	Ja
RMS-rangert strøm/utgangseffekt:	16 W
Batterier medfølger:	Ja
Lampens effekt:	215 W
Lyskildens tjenestetid (økonomisk modus):	6000 timer
Kabellåsport:	Ja
Kabellåstype:	Kensington
Zoom-forhold:	1.2:1
Støttede forhold:	16:9
Plugg inn og spill:	Ja
Progressiv skanningsoutput:	Ja
