ENGLISH
This Liquid Crystal Projector can display various computer
signals and NTSC/PAL/SECAM video signals.
Outline
(1) High brightness
A highly efficient optical system with a UHP lamp ensures
high brightness.
(2) High resolution
Three separate high-definition liquid crystal panels are
used for the R, G and B signals.
(3) Compact size, light weight for portability
(4) RGB output terminal
(5) RS232C Communication
(6)
Mouse emulation
(7)
Power zoom and power focus functions
(8)
Complies with VESA DDC1/2B specifications
(9) Auto-adjustment function
Contents
Page
Features
Liquid Crystal Projector
Model name
Thank you very much for purchasing this hitachi Liquid Crystal Projector.
Please read this operating guide to use correctly. After reading this manual, keep it carefully for
future reference.
OPERATING GUIDE
CP-X940W/E
Before use ......................................3
Contents of shipping box..................8
Names and functions of each part ..8
Installation ....................................12
Basic operations ............................13
Adjustments and functions ............16
Connection to the video signal
terminals ................................20
Connection to the RGB signal
terminal ..................................20
Connection to the control
signal terminal ........................23
Example of system setup ..............28
Cleaning the air filter ......................29
Lamp ..............................................30
Message table................................31
When you think something wrong ..32
Specifications ................................33
As these colours may not correspond with the coloured makings identifying the terminals in your plug,
proceed as follows:
The wire which is coloured Green and Yellow must be connected to the terminal in the plug which is
marked with the letter E or by the earth symbol or coloured Green or Green and Yellow.
The wire coloured Blue must be connected to the terminal marked with the letter N or coloured BLUE or
BLACK. The wire coloured BROWN must be connected to the terminal marked with the letter L or
coloured BROWN or RED.
FOR THE CUSTOMERS IN U.K
THIS PRODUCT IS SUPPLIED WITH A TWO PIN MAINS PLUG FOR USE IN MAINLAND EUROPE.
FOR THE U.K PLEASE REFER TO THE NOTES ON THIS PAGE.
IMPORTANT FOR UNITED KINGDOM
WORDING FOR CLASS I EQUIPMENT INSTRUCTION BOOKS AND LABELS
The mains lead on this equipment is supplied with a moulded plug incorporating a fuse, the value of which
is indicated on the pin face of the plug. Should the fuse need to be replaced, an ASTA or BSI approved BS
1362 fuse must be used of the same rating. If the fuse cover is detachable never use the plug with the cover
omitted. If a replacement fuse cover is required, ensure it is of the same colour as that visible on the pin
face of the plug. Fuse covers are available from your dealer.
DO NOT cut off the mains plug from this equipment. If the plug fitted is not suitable for the power points
in your home or the cable is too short to reach a power point, then obtain an appropriate safety approved
extension lead or consult your dealer.
Should it be necessary to change the mains plugs, this must be carried out by a competent person,
preferable a qualified electrician.
If there is no alternative to cutting off the mains plug, ensure that you dispose of it immediately, having
first removed the fuse, to avoid a possible shock hazard by inadvertent connection to the mains supply.
2
Green & Yellow to Earth
Fuse
Cord Clamp
Brown to Live
Blue to Neutral
WARNING: THIS EQUIPMENT MUST BE EARTHED
IMPORTANT:
The wires in the mains lead are coloured in accordance with the following code:
Green and Yellow=Earth, Blue=Neutral, Brown=Live.
