Side 1/168

Handling instructions

Bedienungsanleitung

Mode d’emploi

Istruzioni per l’uso

Gebruiksaanwijzing

Instrucciones de manejo

Instruções de uso

Bruksanvisning

Brugsanvisning

Bruksanvisning

Käyttöohjeet

Οδηγίες χειρισμού

Instrukcja obsługi

Kezelési utasítás

Návod k obsluze

Kullanım talimatları

Instrucţiuni de utilizare

Navodila za rokovanje

Pokyny na manipuláciu

Инструкция за експлоатация

Uputstvo za rukovanje

Upute za rukovanje

Iнструкції щодо поводження з

пристроєм

Инструкция по эксплуатации

DH 25DL • DH 25DAL

DH 36DL • DH 36DAL

ﬁ

DH36DAL

ﬁ

0000BookDH25DL.indb10000BookDH25DL.indb1 2017/12/0116:42:482017/12/0116:42:48

English

power source and/or battery pack, picking up or

carrying the tool.

Carrying power tools with your ﬁ nger on the switch

or energising power tools that have the switch on

invites accidents.

d) Remove any adjusting key or wrench before

turning the power tool on.

A wrench or a key left attached to a rotating part of

the power tool may result in personal injury.

e) Do not overreach. Keep proper footing and

balance at all times.

This enables better control of the power tool in

unexpected situations.

f) Dress properly. Do not wear loose clothing or

jewellery. Keep your hair, clothing and gloves

away from moving parts.

Loose clothes, jewellery or long hair can be caught in

moving parts.

g) If devices are provided for the connection of

dust extraction and collection facilities, ensure

these are connected and properly used.

Use of dust collection can reduce dust-related

hazards.

4) Power tool use and care

a) Do not force the power tool. Use the correct

power tool for your application.

The correct power tool will do the job better and safer

at the rate for which it was designed.

b) Do not use the power tool if the switch does not

turn it on and oﬀ .

Any power tool that cannot be controlled with the

switch is dangerous and must be repaired.

c) Disconnect the plug from the power source and/

or the battery pack from the power tool before

making any adjustments, changing accessories,

or storing power tools.

Such preventive safety measures reduce the risk of

starting the power tool accidentally.

d) Store idle power tools out of the reach of

children and do not allow persons unfamiliar

with the power tool or these instructions to

operate the power tool.

Power tools are dangerous in the hands of untrained

users.

e) Maintain power tools. Check for misalignment

or binding of moving parts, breakage of parts

and any other condition that may aﬀ ect the

power toolʼs operation.

If damaged, have the power tool repaired before

use.

Many accidents are caused by poorly maintained

power tools.

f) Keep cutting tools sharp and clean.

Properly maintained cutting tools with sharp cutting

edges are less likely to bind and are easier to control.

g) Use the power tool, accessories and tool bits

etc. in accordance with these instructions,

taking into account the working conditions and

the work to be performed.

Use of the power tool for operations diﬀ erent from

those intended could result in a hazardous situation.

5) Battery tool use and care

a) Recharge only with the charger speciﬁ ed by the

manufacturer.

A charger that is suitable for one type of battery pack

may create a risk of ﬁ re when used with another

battery pack.

b) Use power tools only with speciﬁ cally

designated battery packs.

Use of any other battery packs may create a risk of

injury and ﬁ re.

GENERAL POWER TOOL SAFETY

WARNINGS

WARNING

Read all safety warnings and all instructions.

Failure to follow the warnings and instructions may result in

electric shock, ﬁ re and/or serious injury.

Save all warnings and instructions for future reference.

The term “power tool” in the warnings refers to your mains-

operated (corded) power tool or battery-operated (cordless)

power tool.

1) Work area safety

a) Keep work area clean and well lit.

Cluttered or dark areas invite accidents.

b) Do not operate power tools in explosive

atmospheres, such as in the presence of

ﬂ ammable liquids, gases or dust.

Power tools create sparks which may ignite the dust

or fumes.

c) Keep children and bystanders away while

operating a power tool.

Distractions can cause you to lose control.

2) Electrical safety

a) Power tool plugs must match the outlet.

Never modify the plug in any way.

Do not use any adapter plugs with earthed

(grounded) power tools.

Unmodiﬁ ed plugs and matching outlets will reduce

risk of electric shock.

b) Avoid body contact with earthed or grounded

surfaces, such as pipes, radiators, ranges and

refrigerators.

There is an increased risk of electric shock if your

body is earthed or grounded.

c) Do not expose power tools to rain or wet

conditions.

Water entering a power tool will increase the risk of

electric shock.

d) Do not abuse the cord. Never use the cord for

carrying, pulling or unplugging the power tool.

Keep cord away from heat, oil, sharp edges or

moving parts.

Damaged or entangled cords increase the risk of

electric shock.

e) When operating a power tool outdoors, use an

extension cord suitable for outdoor use.

Use of a cord suitable for outdoor use reduces the

risk of electric shock.

f) If operating a power tool in a damp location

is unavoidable, use a residual current device

(RCD) protected supply.

Use of an RCD reduces the risk of electric shock.

3) Personal safety

a) Stay alert, watch what you are doing and use

common sense when operating a power tool.

Do not use a power tool while you are tired

or under the inﬂ uence of drugs, alcohol or

medication.

A moment of inattention while operating power tools

may result in serious personal injury.

b) Use personal protective equipment. Always

wear eye protection.

Protective equipment such as dust mask, non-skid

safety shoes, hard hat, or hearing protection used for

appropriate conditions will reduce personal injuries.

c) Prevent unintentional starting. Ensure the

switch is in the oﬀ position before connecting to

(Original instructions)

0000BookDH25DL.indb20000BookDH25DL.indb2 2017/12/0116:42:492017/12/0116:42:49

English

c) When battery pack is not in use, keep it away

from other metal objects, like paper clips, coins,

keys, nails, screws or other small metal objects,

that can make a connection from one terminal to

another.

Shorting the battery terminals together may cause

burns or a ﬁ re.

d) Under abusive conditions, liquid may be ejected

from the battery; avoid contact. If contact

accidentally occurs, ﬂ ush with water. If liquid

contacts eyes, additionally seek medical help.

Liquid ejected from the battery may cause irritation or

burns.

6) Service

a) Have your power tool serviced by a qualiﬁ ed

repair person using only identical replacement

parts.

This will ensure that the safety of the power tool is

maintained.

PRECAUTION

Keep children and inﬁ rm persons away.

When not in use, tools should be stored out of reach of

children and inﬁ rm persons.

CORDLESS ROTARY HAMMER

SAFETY WARNINGS

1. Wear ear protectors

Exposure to noise can cause hearing loss.

2. Use auxiliary handle(s), if supplied with the tool.

Loss of control can cause personal injury.

3. Hold power tool by insulated gripping surfaces,

when performing an operation where the cutting

accessory may contact hidden wiring.

Cutting accessory contacting a "live" wire may make

exposed metal parts of the power tool "live" and could

give the operator an electric shock.

ADDITIONAL SAFETY WARNINGS

1. Do not allow foreign matter to enter the hole for

connecting the rechargeable battery.

2. Never disassemble the rechargeable battery and

charger.

3. Never short-circuit the rechargeable battery.

Shortcircuiting the battery will cause a great electric

current and overheat. It results in burn or damage to the

battery.

4. Do not dispose of the battery in ﬁ re. If the battery is burnt,

it may explode.

5. When using this unit continuously, the unit may overheat,

leading to damage in the motor and switch. Please leave

it without using it for approximately 15 minutes.

6. Do not insert object into the air ventilation slots of the

charger. Inserting metal objects or inﬂ ammables into the

charger air ventilation slots will result in electrical shock

hazard or damaged charger.

7. Bring the battery to the shop from which it was purchased

as soon as the post-charging battery life becomes too

short for practical use. Do not dispose of the exhausted

battery.

8. Before starting to break, chip or drill into a wall, ﬂ oor or

ceiling, thoroughly conﬁ rm that such items as electric

cables or conduits are not buried inside.

9. Ensure that the power switch is in the OFF position. If the

battery is installed while the power switch is in the ON

position, the power tool will start operating immediately,

which could cause a serious accident.

10. Do not touch the bit during or immediately after

operation. The bit becomes very hot during operation

and could cause serious burns.

11. Always hold the body handle and side handle of the

power tool ﬁ rmly. Otherwise the counterforce produced

may result in inaccurate and even dangerous operation.

12. Wear a dust mask

Do not inhale the harmful dusts generated in drilling or

chiseling operation. The dust can endanger the health of

yourself and bystanders.

13. Make sure that the battery is installed ﬁ rmly. If it is at all

loose it could come oﬀ and cause an accident.

14. To prevent accidents, make sure to turn the switch oﬀ

and pull out the battery before changing accessories,

storing, carrying or when not using the tools.

15. Mounting the drill bit

○ To prevent accidents, make sure to turn the switch oﬀ

and pull out the battery.

○ When using tools such as bull points, drill bits, etc.,

make sure to use the genuine parts designated by our

company.

○ Clean the shank portion of the drill bit.

○ Check the latching by pulling on the drill bit.

16. Operate the change lever only when the motor is at a

full stop. Operating the change lever while the motor is

running may cause the tip tool to unexpectedly rotate

and result in an accident. (Fig. 7)

17. Rotation + hammering

When the drill bit touches construction iron bar, the bit

will stop immediately and the rotary hammer will react

to revolve. Therefore ﬁ rmly tighten the side handle, hold

the body handle and side handles.

18. Rotation only

○ To drill wood or metal material using the drill chuck and

chuck adapter (optional accessories).

○ Application of force more than necessary will not only

expedite the work, but will deteriorate the tip edge of the

drill bit and reduce the service life of the rotary hammer

in addition.

○ Drill bits may snap oﬀ while withdrawing the rotary

hammer from the drilled hole. For withdrawing, it is

important to use a pushing motion.

○ Do not attempt to drill anchor holes or holes in concrete

with the machine set in the rotation only function.

○ Do not attempt to use the rotary hammer in the rotation

and striking mode with the drill chuck and chuck adapter

attached. This would seriously shorten the service life of

every component of the machine.

19. Selecting the Power / Save mode

○ The hammering force of the hammer can be increased or

decreased to conform with intended usage, by operating

the shift knob as per Fig. 11. Adjust the force to match

the usage intended.

○ Do not drill holes in wood with the “SAVE“ mode. There

is a likelihood that the motor will burn out because it can

easily lock up due to the low power.

CAUTION ON LITHIUM-ION BATTERY

To extend the lifetime, the lithium-ion battery equips with the

protection function to stop the output.

In the cases of 1 to 3 described below, when using this

product, even if you are pulling the switch, the motor may

stop. This is not the trouble but the result of protection

function.

1. When the battery power remaining runs out, the motor

stops.

In such a case, charge it up immediately.

2. If the tool is overloaded, the motor may stop. In this

case, release the switch of tool and eliminate causes of

overloading. After that, you can use it again.

0000BookDH25DL.indb30000BookDH25DL.indb3 2017/12/0116:42:492017/12/0116:42:49

Produkspesifikasjoner

Merke:	Hitachi
Kategori:	drill
Modell:	DH 25DAL
Vekt:	3600 g
Dybde:	322 mm
Strømkilde:	Batteri
Produktfarge:	Grønn
Batterispenning:	25.2 V
Borediameter i stål (maks.):	13 mm
Bæretaske:	Ja
Slaghastighet:	2250 bpm
