Horizon Fitness Oxford 6 Bruksanvisning
Horizon Fitness
romaskin
Oxford 6
Les nedenfor 📖 manual på norsk for Horizon Fitness Oxford 6 (48 sider) i kategorien romaskin. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/48
OXFORD 3
OXFORD 6
2
3 ENGLISH
18 FRANÇAIS
33 ESPAÑOL
3
ENGLISH
SERIAL NUMBER LOCATION
ASSEMBLY
UNPACKING
Unpack the equipment where you will be using it. Place the carton on a level at surface. It is
recommended that you place a protective covering on your oor. Never open box when it is on its side.
IMPORTANT NOTES
During each assembly step, ensure that ALL nuts and bolts are in place and partially threaded.
Several parts have been pre-lubricated to aid in assembly and usage. Please do not wipe
this off. If you have diculty, a light application of lithium grease is recommended.
TOOLS INCLUDED:
F 6mm L-Wrench
F 5mm L-Wrench
PARTS INCLUDED:
F 1 Main Frame
F 1 Front Stabilizer
F 1 Seat Rail
F 1 Rear Stabilizer
F 1 Foot Pad Assembly
F 1 Main Frame Cover
F 1 Seat Frame Assembly
F 1 Seat Rail End Cap
F 1 Hardware Kit
WARNING!
There are several areas during the assembly process that special
attention must be paid. It is very important to follow the assembly
instructions correctly and to make sure all parts are rmly tightened. If
the assembly instructions are not followed correctly, the equipment could
have parts that are not tightened and will seem loose and may cause
irritating noises. To prevent damage to the equipment, the assembly
instructions must be reviewed and corrective actions should be taken.
NEED HELP?
If you have questions or if there are any missing parts,
contact Horizon Customer Tech Support.
Before proceeding, nd your
equipment’s serial number
located on a barcode sticker
and enter it in the space
provided below.
SERIAL NUMBER
MODEL NAME
F OXFORD 3 F OXFORD 6 HORIZON ROWER
* Use the information above when calling for service.
