Side 1/2
2A8388-010
Commercial Undercounter, Worktop, and Prep Table Overshelf Kit
HS-5163, HS-5164, HS-5165, HS-5166, HS-5172, HS-5173, HS-5174, HS-5175, HS-5236, HS-5237
For Use with Hoshizaki Commercial Series Undercounter/Worktop/Prep Table Models
Check to ensure that all parts are included:
Index
No. Description Part Number
Single Shelf
HS Kit Qty
Double Shelf
HS Kit Qty
1 Overshelf 2A7365-01 HS-5172 (27)
1
HS-5163 (27)
2
2A7365-07 HS-5237 (36) HS-5236 (36)
2A7365-02 HS-5173 (48) HS-5164 (48)
2A7365-03 HS-5174 (60) HS-5165 (60)
2A7365-04 HS-5175 (72) HS-5166 (72)
1a Hex Head Bolt - (6x50 mm) 7B02-0650
All
4
All
8
1b Lock Washer 7L22-0600 4 8
1c Hex Nut 7N12-0600 4 8
1d Flat Washer 7W22-0600 4 8
2 Square Tube 4A5733-01 2 2
2a Hex Head Bolt - (6x60 mm) 7B02-0660 6 6
2b Lock Washer 7L22-0600 6 6
2c Flat Washer 4A0198-03 18 18
3 Square Tube Cap 4A5862-01 2 2
2
1a
1
2a
2b
2c
3
WARNING
• This appliance should be repaired only by qualied service personnel to reduce the risk of death, electric shock, serious
injury, or re.
• No installation or service should be undertaken until the technician has thoroughly read these instructions. Failure to
install this kit in accordance with these instructions will adversely affect safety, performance, component life, and warranty
coverage.
• To reduce the risk of electric shock, do not touch the plug with damp hands. Unplug the appliance before servicing.
• Maximum load per shelf:
Total Maximum Weight Per Shelf
27 36 48 60 72
75 lb. (34 kg) 97 lb (44 kg) 130 lb. (58 kg) 165 lb. (74 kg) 200 lb. (90 kg)
• Use care when stacking product on the shelves to prevent items from falling.
• Do not climb, stand, or hang on the appliance, drawers, or shelves. Death or serious injury could occur or the appliance
could be damaged.
1b
1c
1d
