Side 1/12

GBGB

FRIDGE

HUT161IT

HUT1622

Operating Instructions

English

Contents

Installation, 2-3

Positioning and connection

Description of the appliance, 4

Overall view

Start-up and use, 5

Starting the appliance

Using the refrigerator to its full potential

Using the freezer to its full potential

Maintenance and care, 6

Switching the appliance off

Cleaning the appliance

Avoiding mould and unpleasant odours

Defrosting the appliance

Replacing the light bulb

Precautions and tips, 7

General safety

Disposal

Respecting and conserving the environment

Troubleshooting, 8

Hotpoint Guarantee, 11

Key Contacts, 12

Installation

! Before placing your new appliance into operation please

read these operating instructions carefully. They contain

important information for safe use, for installation and for

care of the appliance.

! Please keep these operating instructions for future

reference. Pass them on to possible new owners of the

appliance.

Positioning and connection

Positioning

1. Place the appliance in a well-ventilated humidity-free

room.

2. Do not obstruct the rear fan grills. The compressor and

condenser give off heat and require good ventilation to

operate correctly and save energy.

3. Ensure the appliance is away from any sources of heat

(direct sunlight, electric stove, etc.).

Electrical connections

After the appliance has been transported, carefully place it

vertically and wait at least 3 hours before connecting it to

the electricity mains. Before inserting the plug into the

electrical socket ensure the following:

 The appliance is earthed and the plug is compliant with

the law.

 The socket can withstand the maximum power of the

appliance, which is indicated on the data plate located on

the bottom left side of the fridge (e.g. 150 W).

 The voltage must be in the range between the values

indicated on the data plate located on the bottom left

side (e.g. 220-240V).

 The socket is compatible with the plug of the appliance.

If the socket is incompatible with the plug, ask an

authorised technician to replace it (see Assistance). Do

not use extension cords or multiple sockets.

! Once the appliance has been installed, the power supply

cable and the electrical socket must be easily accessible.

! The cable must not be bent or compressed.

! The cable must be checked regularly and replaced by

authorised technicians only (see Assistance).

The manufacturer declines any liability should these

safety measures not be observed.

Your appliance is supplied with a 13amp fused plug that

can be plugged into a 13amp socket for immediate use.

Before using the appliance please read the instructions

below.

WARNING:

THIS APPLIANCE MUST BE EARTHED.

Replacing fuse covers:

When replacing a faulty fuse, a 13amp ASTA approved

fuse to BS 1362 should always be used and the fuse

cover re-fitted.

If the fuse cover is lost, the plug must not be used until a

replacement is obtained.

Replacement fuse covers:

If a replacement fuse cover is fitted, it must be of the

correct colour as indicated by the coloured marking or the

colour that is embossed in words on the base of the plug.

Changing the plug:

Removing the plug

If your appliance has a non-rewireable moulded plug and

you should wish to remove it to add a longer cable or to

re-route the mains cable through partitions, units etc.

please ensure that either:

- The plug is replaced by a fused 13amp re-

wireable plug bearing the BSI mark of

approval.

- The mains cable is wired directly into a

13amp cable outlet, controlled by a

switch (in compliance with BS 5733)

which is accessible without moving the

appliance.

Disposing of the plug

Cut off and dispose of the supplied plug if it does not fit

your socket. The cable should be cut as close as possible

to the moulded plug.

Remove the fuse.

WARNING:

To avoid a shock hazard do not insert the discarded

plug into a socket anywhere else.

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR 5 YEAR PARTS GUARANTEE ON 08448 24 24 24

Fitting a new plug

IMPORTANT:

WIRES IN THE MAINS LEAD ARE COLOURED IN

ACCORDANCE WITH THE FOLLOWING CODE...

Green and Yellow - Earth

Blue - Neutral

Brown - Live

As the colours of the wires in the mains lead may not

correspond with the coloured markings identifying the

terminals in your plug, proceed as follows:

- Connect Green and Yellow wire to terminal marked

'E' or

or coloured Green and Yellow.

- Connect Brown wire to terminal marked 'L' or coloured

red or brown.

- Connect Blue wire to terminal marked 'N' or coloured

Black or Blue.

If a 13amp plug (BS 1363) is used it must be

fitted with a 13amp fuse. A 15amp plug must be protected

by a 15amp fuse, either in the plug or adaptor or at the

distribution board.

If you are in any doubt about the electrical

supply to your machine, consult a qualified

electrician before use.

CE Marking certifies that this appliance conforms to

the following EEC directives :

Low Voltage Equipment - 73/23/EEC & 93/68 EEC

Electromagnetic Compatibility 89/336/EEC, 92/31/EEC

& 93/68/EEC

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR 5 YEAR PARTS GUARANTEE ON 08448 24 24 24

Produkspesifikasjoner

Merke:	Hotpoint
Kategori:	Kjøleskap
Modell:	HUT1622
Innebygd skjerm:	Nei
Bredde:	580 mm
Dybde:	540 mm
Høyde:	815 mm
Dørhengsel:	Riktig/Høyre
Årlig energiforbruk:	178 kWh
Klimaklasse:	N-ST
Støynivå:	40 dB
Energieffektivitetsklasse (gammel):	A+
Frysekapasitet:	2 kg/24t
Antall stjerner:	4*
Total bruttokapasitet:	- l
Hyllemateriale:	Herdet glass
Produktfarge:	Hvit
Pakkedybde:	590 mm
Pakkehøyde:	860 mm
Pakkebredde:	610 mm
Kjøleskap brutto kapasitet:	83 l
Number of vegetable drawers:	1
Lagringstid ved strømbrudd:	11 timer
Plassering av innretning:	Innebygget
Tilkoblet nettbelastning:	- W
Fryser netto kapasitet:	19 l
Klar for spesialtilpassede paneler:	Ja
Antall hyller/bokser i kjøleskap:	2
Kjøleskap netto kapasitet:	79 l
Innvendig lys kjøleskap:	Ja
Total netto kapasitet:	98 l
Fryserposisjon:	Topp-plasserte
Fryser brutto kapasitet:	- l
Egg balcony:	Ja
Dørhyller kjøleskap:	2
Dørpanel inkludert:	Nei
