Side 1/16

! This symbol reminds you to read this booklet.

Contents

Installation, 2-3-4-5

Unpacking and levelling

Connecting the electricity and water supplies

The first wash cycle

Technical data

Description of the washer-dryer and

starting a wash cycle, 6-7

Control panel

Indicator lights

Starting a wash cycle

Wash cycles, 8

Table of wash cycles

Personalisation, 9

Setting the temperature

Setting the drying cycle

Functions

Detergents and laundry, 10

Detergent dispenser drawer

Preparing the laundry

Garments requiring special care

Load balancing system

Precautions and tips, 11

General safety

Disposal

Opening the porthole door manually

Care and maintenance, 12

Cutting off the water or electricity supply

Cleaning the washer-dryer

Cleaning the detergent dispenser drawer

Caring for the door and drum of your appliance

Cleaning the pump

Checking the water inlet hose

Troubleshooting, 13-14

Assistance, 15-16

WDAL 8640

Instructions for use

WASHER-DRYER

English,1

Installation

Levelling your appliance correctly will provide it with sta-

bility and avoid any vibrations, noise and shifting during

operation. If it is placed on a fitted or loose carpet, adjust

the feet in such a way as to allow enough room for ventila-

tion beneath the washer-dryer.

Electric and water connections

Connecting the water inlet hose

1. Connect the supply pipe

by screwing it to a cold

water tap using a 3/4 gas

threaded connection (see

figure).

Before performing the con-

nection, allow the water to

run freely until it is perfectly

clear.

2. Connect the other end

of the water inlet hose to

the washer-dryer, screwing

it onto the appliance’s cold

water inlet, situated on the

top right-hand side on the

rear of the appliance (see

figure).

3. Make sure there are no kinks or bends in the hose.

! The water pressure at the tap must be within the values

indicated in the Technical details table (on the page 5).

! If the water inlet hose is not long enough, contact a spe-

cialist store or an authorised serviceman.

! Ensure that the supply taps are allowing water through.

Old taps may seize in the closed position and thus pre-

vent water reaching the machine.

! Never use second-hand or old inlet hoses; use the pro-

ducts supplied with the machine.

! Keep this instruction manual in a safe place for future

reference. Should the appliance be sold, transferred or

moved, make sure the instruction manual accompanies the

washer-dryer to inform the new owner as to its operation and

features.

! Read these instructions carefully: they contain vital infor-

mation on installation, use and safety.

Unpacking and levelling

Unpacking

! This is a separate part of

the polystyrene base and

should be removed with

the base.

! IMPORTANT check

when unpacking your

machine.

1. Unpack the washer-dryer.

2. Check whether the washer-dryer has been damaged

during transport. If this is the case, do not install it and

contact your retailer.

3. Remove the 4 protective

screws and the rubber bush

with the respective spacer,

situated on the rear of the

appliance (see also the

installation leaflet).

4. Seal the gaps using the plastic plugs provided.

5. Keep all the parts: you will need them again if the

washer-dryer needs to be moved to another location.

! Packaging materials are not children’s toys.

Levelling

Your machine may make a considerable amount of noise if

the two front feet have not been adjusted correctly.

1. Install the washing ma-

chine on a flat sturdy floor,

without resting it up against

walls, cabinets or anything

else.

2. If the floor is not perfectly level, compensate for any

unevenness by tightening or loosening the adjustable front

feet (see figure); the angle of inclination, measured accor-

ding to the worktop, must not exceed 2°.

Produkspesifikasjoner

Merke:	Hotpoint
Kategori:	Vaskemaskin
Modell:	WDAL 8640G
Innebygd skjerm:	Nei
Bredde:	595 mm
Dybde:	605 mm
Høyde:	850 mm
Barnelås:	Nei
Energieffektivitetsklasse (gammel):	A
Tørkekapasitet:	6 kg
Produktfarge:	Grafitt
Sentrifugeringsklasse:	A
Lastetype:	Frontmatet
Plassering av innretning:	Frittstående
Forsinket start timer:	Ja
Trommelvolum:	62 l
Maksimal sentrifugeringshastighet:	1400 RPM
Justerbar spinnhastighet:	Ja
Belastningsbalansering:	Ja
Energiforbruk ved vask per syklus:	- kWh
Vaskeklasse:	A
LED-programtrinnsindikator:	Ja
Energiforbruk ved vasking og tørking per syklus:	- kWh
Vannforbruk (vasking og tørking):	- l
Nominell kapasitet (vasking):	8 kg
