HP Sprocket Plus Bruksanvisning

HP Printer Sprocket Plus

Les nedenfor 📖 manual på norsk for HP Sprocket Plus (15 sider) i kategorien Printer. Denne guiden var nyttig for 4 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/15

Parts and Controls

Supplied Items

Product Overview

LED Indicator Lights

Caring for your HP Sprocket Plus

Getting Started

Installing Mobile App

Loading Paper

Charging Battery and Powering On/O

Pairing a Mobile Device and the HP Sprocket Plus

Navigating the App

Menu Navigation

Browse Photo Galleries

Take or Select a Photo

Set up Social Media Sources

Enable Sprocket Printing

Image Preview

Edit a Photo

Create Custom Stickers

Print a Photo

Share a Photo

Sprocket App Features

Safety Information

Specications

Troubleshooting

Enjoy larger prints with the HP Sprocket Plus!

The information contained herein is subject to change without notice.

HP Sprocket Plus

Supplied Items

HP Sprocket Plus

Setup Instructions

HP Sprocket Plus Photo Paper (10 sheets)

USB Charging Cable

Regulatory and Warranty Information

Product Overview

1. Power Button

2. Micro-USB Charging Port

3. Status Indicator LED Light

4. Charging Indicator LED Light

5. Paper Cover

6. Paper Output Slot

7. Lanyard Notch

Parts and Controls

What if my HP Sprocket Plus isn’t responding or won’t connect to my

mobile device?

If you have trouble connecting or other issues, reset

the device. Remove the Paper Cover and locate the

pin-hole near the Paper Tray. Insert a straight pin into

the hole to press the Reset Button until the printer

turns o. Restart the device.

Reset Button

LED Indicator Lights: Status LED and Charge LED

LED Color/Status HP Sprocket Plus Condition Description

Charge LED Red Charging Connected to power. LED will turn

green upon full charge. Printer can

be used while charging.

Green Fully charged Device is fully charged.

Status LED White, Blinking Powering on/Receiving

print job

LED ashes white when powering

on and when receiving a print job.

Red, Blinking Printer error When a print error occurs, the LED

will ash red. Wait for the light to

turn white to send a print job.

White Idle/On Powered on and waiting for print

job. Device defaults to power down

after 5 minutes without use. This

can be changed in the sprocket

menu.

Caring for your HP Sprocket Plus

• Remove ngerprints, dust, and dirt from the printer using a dry microber cloth.

• Keep the Paper Cover on to prevent dust and debris from entering the paper path.

• Update the printer rmware. Make sure your mobile device is connected to the Internet and then open the HP

Sprocket app. If there is a rmware update available, a rmware update screen displays. Follow the on-screen

prompts to complete the update. Your printer must be charged to 50% or higher before a rmware update.

• Keep your sprocket app updated. If you don’t have your mobile app set to automatically update, go to the

appropriate app store and make sure the latest version is installed.

Produkspesifikasjoner

Merke:	HP
Kategori:	Printer
Modell:	Sprocket Plus
Innebygd skjerm:	Nei
Vekt:	204 g
Bredde:	142 mm
Dybde:	86 mm
Høyde:	18 mm
Strømkilde:	Batteri
Batterikapasitet:	900 mAh
Bluetooth:	Ja
Wi-Fi:	Nei
USB-port:	Ja
Maksimal oppløsning:	313 x 400 DPI
Garantikort:	Ja
Pakkevekt:	310 g
Internminne:	512 MB
HP-segment:	Home, Home office
Utskriftsteknologi:	ZINK (Zero ink)
PictBridge:	Nei
Batteriteknologi:	Lithium-Ion (Li-Ion)
Strømforbruk (standby):	0.75 W
Produktfarge:	Rød
Pakkedybde:	115 mm
Pakkehøyde:	36 mm
Pakkebredde:	175 mm
Batterispenning:	7.4 V
Driftstemperatur (T-T):	5 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-30 - 70 °C
Lagringsrelativ fuktighet:	5 - 90
Innebygd kortleser:	Nei
Andre støttede operativsystemer:	Android, iOS
Ethernet/bredbåndsforbindelse:	Nei
Relativ luftfuktighet under drift (H-H):	5 - 70
Markedsplassering:	Hjem og kontor
Total matingskapasitet:	10 ark
Direkte utskrift:	Ja
Maksimalt utskriftsområde:	2.3" x 3.4" (5.8x8.6 cm)
Gjennomsnittlig strømforbruk ved utskrift:	17.6 W
Utskrift uten kanter:	Ja
HP Auto-On/Auto-Off:	Ja
