Side 1/46

Manual IB-TH100-DK

Swivel stand for tablet and smartphone with

USB Type-C

DockingStation

Handbuch IB-TH100-DK

Drehbarer Ständer für Tablet und Smartphone

mit USB Type-C

DockingStation

Manual IB-TH100-DK

Please read carefully the following information to prevent injuries, da-

mage to material and device as well as data loss:

Warning levels

Signal words and safety codes indicate the warning level and provide immediate

information in terms of the probability of occurrence as well as the type and severity

of the consequences if the measures to prevent hazards are not complied with.

Warns of a directly hazardous situation causing

death or serious injury.

Warns of a potentially hazardous situation that may

cause death or serious injury.

Warns of a potentially hazardous situation that may

cause minor injury.

Warns of a potential situation that may cause ma-

terial or environmental damage and disrupt operative

processes.

1. Risk of electrical shock

Contact with parts conducting electricity

Risk of death by electrical shock

• Read the operating instructions prior to use

• Make sure the device has been de-energised prior to working on it

• Do not remove contact protection panels

• Avoid contact with conducting parts

• Do not bring plug contacts in contact with pointed and metal objects

• Use in intended environments only

• Operate the device using a power unit meeting the speciﬁcations of the type plate

only!

• Keep the device/power unit away from humidity, liquid, vapour and dust

• Do not modify the device

• Do not connect the device during thunderstorms

• Approach specialist retailers if you require repairs

2. Hazards during assembly (if intended)

Sharp components

Potential injuries to ﬁngers or hands during assembly (if

intended)

• Read the operating instructions prior to assembly

• Avoid coming into contact with sharp edges or pointed components

• Do not force components together

• Use suitable tools

• Use potentially enclosed accessories and tools only

3. Hazards caused by a development of heat

Insufﬁcient device/power unit ventilation

Overheating and failure of the device/power unit

• Prevent externally heating up components and ensure an exchange of air

• Do not cover the fan outlet and passive cooling elements

DANGER

WARNING

CAUTION

IMPORTANT

WARNING

CAUTION

IMPORTANT

Produkspesifikasjoner

Merke:	Icy Box
Kategori:	hub & dokkstasjon
Modell:	IB-TH100-DK
Vekt:	315 g
Bredde:	120 mm
Dybde:	120 mm
Høyde:	185 mm
Bruksanvisning:	Ja
Bluetooth:	Nei
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	3840 x 2160 piksler
Strømkildetype:	USB
Pakkevekt:	420 g
Antall HDMI-porter:	1
Maksimal oppdateringshastighet:	60 Hz
Lydutgang:	3,5 mm
Materiale:	Aluminium, Plastic
HDMI:	Ja
HDMI-versjon:	2.0
Merkekompatibilitet:	Universell
USB-hub:	Ja
Kombinert hodetelefon/mikrofonport:	Ja
Antall USB Type-C-porter:	2
Dataoverføringshastighet:	5 Gbit/s
Produktfarge:	Anthracite, Black
HD-type:	4K Ultra HD
Pakkedybde:	165 mm
Pakkehøyde:	64 mm
Pakkebredde:	125 mm
Minnekortenhet:	MicroSD (TransFlash), MicroSDHC, MicroSDXC, SD, SDHC, SDXC
HDMI-kontakttype:	Full-size
Innebygd kortleser:	Ja
Modell/Type:	Aktiv holder
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	2
Plugg inn og spill:	Ja
Korrekt bruk:	Innendørs
Masterkassens (ytterkassens) bruttovekt:	9020 g
Masterkassens (ytterkassens) lengde:	350 mm
Produkter per masterkasse (ytterkasse):	20 stykker
Masterkassens (ytterkassens) bredde:	340 mm
Masterkassens (ytterkassens) høyde:	290 mm
Antall:	1
Mobilenhetstype:	Mobile phone/smartphone, Tablet/UMPC
USB Power Delivery:	Ja
USB Power Delivery opp til:	100 W
Enhetsmonteringstype:	Nei
USB Power Delivery-revisjon:	3.0
Dokkingtilkoblingstype:	USB Type-C
Enhetsgrunntype:	Nettbrett/smarttelefon
