Side 1/54

Network

Camera

Operation Manual

DC-D1011 / DC-D1022W / DC-D1022WR /

DC-D1111/ DC-D1122 / DC-D1122R / DC-D1122V /

DC-D1122VR / DC-D1122W / DC-D1122WR / DC-D1123 /

DC-D1123R / DC-D1123V / DC-D1123VR / DC-D1123W /

DC-D1123WR / DC-D1123WHR / DC-D1212R / DC-D1223 /

DC-D1223R / DC-D1223V / DC-D1223VR / DC-D1223W /

DC-D1223WR / DC-D1223WHR / DC-D1323R /

DC-D1323WR / DC-D1323WHR

This is a basic operation manual for use of an IDIS network camera. Users who are using this product for the rst time,

as well as users with experience using comparable products, must read this operation manual carefully before use and

heed to the warnings and precautions contained herein while using the product. Safety warnings and precautions

contained in this operation manual are intended to promote proper use of the product and thereby prevent accidents

and property damage and must be followed at all times. Once you have read this operation manual, keep it at an easily

accessible location for future reference.

• The manufacturer will not be held responsible for any product damage resulting from the use of unauthorized parts and

accessories or from the user's failure to comply with the instructions contained in this operation manual.

• The information in this document is believed to be accurate as of the date of publication. The manufacturer is not

responsible for any problems resulting from the use thereof. The information contained herein is subject to change

without notice. Revisions or new editions to this publication may be issued to incorporate such changes.

• It is recommended that rst-time users of this network camera and individuals who are not familiar with its use seek

technical assistance from their retailer regarding product installation and use.

• If you need to disassemble the product for functionality expansion or repair purposes, you must contact your retailer and

seek professional assistance.

• Both retailers and users should be aware that this product has been certied as being electromagnetically compatible for

commercial use. If you have sold or purchased this product unintentionally, please replace with a consumer version.

Safety Symbols

Symbol Type Description

Warning

An important instruction or set of important instructions that can lead to severe injury or even death

if not followed.

Caution

An instruction or set of instruction that can lead to personal injury and/or property damage if not

followed.

In-Text

Symbol Type Description

Caution

Important information concerning a specic function.

Note

Useful information concerning a specic function.

Classication of products by model

This manual explains two types of models. The

TYPE1

TYPE2

icons in the manual specify the following models. The

TYPE1

models

support features like the Alarm In/Out, Audio Input/Output, and recording videos in the SD card.

Types of models Model

TYPE1

DC-D1123 / DC-D1123R / DC-D1123V / DC-D1123VR / DC-D1123W / DC-D1123WR / DC-D1123WHR /

DC-D1223 / DC-D1223R / DC-D1223V / DC-D1223VR / DC-D1223W / DC-D1223WR / DC-D1223WHR /

DC-D1323R / DC-D1323WR / DC-D1323WHR

TYPE2

DC-D1011 / DC-D1022W / DC-D1022WR / DC-D1111 / DC-D1122 / DC-D1122R / DC-D1122V /

DC-D1122VR / DC-D1122W / DC-D1122WR / DC-D1212R

Before reading this manual

Produkspesifikasjoner

Merke:	IDIS
Kategori:	Overvåkingskamera
Modell:	DC-D1123R
Vekt:	510 g
Høyde:	122 mm
Bluetooth:	Nei
Wi-Fi:	Nei
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	1280 x 720 piksler
Videokomprimeringsformater:	H.264, M-JPEG
Diameter:	160 mm
Strømkildetype:	PoE
Antall kameraer:	1
LED-type:	IR
Sertifisering:	FCC, CE, KC
Støyreduksjon:	Ja
Kablingsteknologi:	10/100Base-T(X)
Nettverksstandard:	IEEE 802.1x
Støttede nettverksprotokoller:	RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/UDP RTSP/TCP, HTTP, HTTPS, FTP, SNTP, SMTP, FEN, mDNS, uPNP
Progressiv skanning:	Ja
Rotasjonsvinkel:	352 °
Minimum blenderåpning:	1.5
Linsetype:	Varifokal
Justering av bildekvalitet:	Skarphet
Linsesynsvinkel, horisontal:	105.5 °
Anti-flimmer:	Ja
Linsesynsvinkel, vertikal:	55.4 °
Iris:	Ja
Terminalblokkport:	Ja
Bildefrekvens:	30 fps
Sensortype:	CMOS
Støttede lydformater:	G.711, G.726
Produktfarge:	Black, White
Vippevinkelområde:	0 - 80 °
Minnekortenhet:	MicroSD (TransFlash), MicroSDHC
Støttede grafikkoppløsninger:	352 x 240,640 x 360,704 x 480,1280 x 720 (HD 720)
Brennviddeområde:	3.3 - 10 mm
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	-10 - 50 °C
Innebygd kortleser:	Ja
Lukkerhastighet:	1 - 1/8000 s
nattsyn:	Ja
Formfaktor:	Kuppel
CCD-sensorstørrelse:	1/2.7 "
IP-adressefiltrering:	Ja
Strømforbruk (Power over Ethernet (PoE)):	5.6 W
Signal-til-støy-forhold (SNR):	45 dB
Modell/Type:	IP-sikkerhetskamera
3D NR (3D-støyreduksjon):	Ja
Panoreringsomfang:	-167 - 167 °
Objektivets synsvinkel, diagonal:	125.3 °
Lydsystem:	2-veis
Flip og speil:	Ja
Bithastighetskontroll:	Constant Bit Rate (CBR), Variable Bit Rate (VBR)
Minimumsbelysning:	0.6 lx
Ethernet/bredbåndsforbindelse:	Ja
Ethernet-grensesnittype:	Raskt Ethernet
Relativ luftfuktighet under drift (H-H):	0 - 90
Maksimal størrelse på hukommelseskort:	32 GB
Strøm over Ethernet (PoE):	Ja
Privacy maske:	Ja
Effektiv distanse for nattsyn:	20 m
Maksimal blenderåpning:	2.5
Videobasert bevegelsesdeteksjon:	Ja
Baklyskompensasjon (BLC):	Ja
Alarminngang/-utgang:	Ja
Aktiv tuklealarm:	Ja
Alert varslingstype:	E-mail, Snapshot alert message
Støyregistrering:	Ja
Kamelukkertype:	Elektronisk
Justering av lukkerhastighet:	Automatisk/Manuell
