SPECIFICATION
MODEL NO. : IB-645GS
RATED VOLTAGE : 230Va.c. 60Hz
POWER CONSUMPTION : 500W
CAPACITY : 1500cc
BOX DIMENSION : 350*210*278mm
UNIT DIMENSION : 168*190*392mm
GROSS WEIGHT : 3.3kg
RPM : 23000RPM/Min (±15%)
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed,
including the following:
1. Read all instructions thoroughly.
2. Before using the unit, check if the voltage indicated corresponds with the convenience
outlet (230Va.c.).
3. Do not use the two-way socket with another appliance.
4. Do not use any appliance with a damaged cord or plug. If the cord is damaged it should
be replaced with the same type and size or bring the unit to the nearest Imarflex
Authorized Service Center.
5. Do not place the unit near a gas stove, an electric burner or in a heated oven.
6. Place the unit on stable surface; keep it away from the edge of counter to avoid accident.
7. Children should be supervised to ensure that they do not play with the appliance.
8. This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliances by a
person responsible for their safety.
9. The maximum continuous operating time of the blender is one minute only. Do not
exceed with the maximum operating time. It may cause damage to the unit.
10. To protect against electric shock, do not immerse the base in water or any other liquid.
11. Extreme caution must be exercised when using an appliance containing hot liquid in the
blender when blending as it can be ejected out of the appliance due to sudden steaming.
12. Use of accessories or equipment not supplied by the manufacturer may cause damage
or malfunctioning of your appliance or result in injuries.
13. Use on a hard, flat level surface only, to avoid interruption of air flow underneath the
appliance.
14. Carry or move the blender’s tumbler only by its handle.
15. Switch off the appliance and unplug the unit before replacing tumbler or accessories.
16. Blade is sharp, handle it carefully.
17. Do not put the blade assembly on the base without the tumbler.
18. Do not use the blender if the tumbler has a crack.
19. This appliance is not intended for outdoor use.
20. Never place the blender near hot surfaces.
21. In case of malfunctions, please bring the blender to the nearest Authorized Imarflex
Service Center.
22. Avoid water spillage into the socket, connector, cord and alike.
23. Switch off the appliance before removing the glass jar into the motor base.
24. Do not use this unit other than its intended use.
25. For household use only; not intended for any business purposes
26. Save this instruction manual for future reference.
27. CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal cutout,
this appliance must not be supplied through an external switching device, such as a
timer, or connected to a circuit that is regularly switched on and off by the utility.
DESCRIPTION OF PARTS:
HOW TO ASSEMBLE:
IMPORTANT: The blender jar and blades are subject to wear during regular use. Always inspect
the jar for nicks, chips or cracks. Always inspect blades for broken, bent or loose blades. Avoid
using the jar or blades if damaged. Contact the Imarflex Authorized Service Center to obtain
evaluation and repair.
Make sure that the blender is unplugged. Place blender base on clean, dry surface to keep foreign
particles from being pulled up into motor during operation.
1. Place the rubber packing into the blade assembly and put the assembly into the jar support.
(See pic.1 & 2).
2. Assemble the jar support
assembly into the glass jar.
3. Put the measuring cup into the lid.
(See pic.3)
4. Secure the lid into the glass jar
and press down. (See pic.3)
5. Put the glass jar on the motor
base, press down and turn
clockwise until securely engaged.
(See pic. 4) Note: The blender will not work if the glass jar is not properly attached to
the unit base.
HOW TO USE:
1. For initial use, wash glass jar with blade assembly thoroughly. “Please refer to cleaning and
maintenance method #2”. Wipe it dry.
2. Put the glass jar with blade assembly on the motor base.
3. Plug the unit into the convenience outlet.
4. Be sure to remove the seeds of the fruits/vegetables if needed.
5. Put the desired mixture.
6. Put the lid on the glass jar and close securely. Place the center lid into the hole of the lid and
push down to lock.
7. Plug the unit into the convenience outlet.
8. Press the pulse button first to crack the ice.
9. Select the desired speed and function.
a. Speed 1 – Function is for blending soft vegetables, soft fruits or any light mixture
b. Speed 2 – Function is for blending hard vegetables and hard fruits or if you desire to blend
smoothie or any alike.
c. Pulse – It is the function to crush the ice.
10. Additional ingredients can be added through opening in the lid.
11. Turn OFF and unplug the unit after every use.
NOTE:
(1) Some electric smell may be observed on first use.
(2) Maximum continuous operating time is 1 minute only.
CAUTION: Always put water or liquid in the jar to avoid damage to the unit. Use pulse function
first, if you are blending with ice.
USEFUL TIPS:
- To achieve the best results when pureeing solid ingredients, place small portions
through the opening in the lid one by one.
- When mixing solid ingredients, start with a small amount of liquid. Gradually add more
liquid through the opening in the lid.
- For stirring solid or very thick liquid ingredients, we recommend that you use the
blender in pulse mode to prevent the blades from being stuck.
CLEANING AND MAINTENANCE:
Motor Base
1. Unplug the unit from the convenience outlet.
2. Wipe or clean the outside surface with a damp or soft cloth.
NEVER IMMERSE MOTOR BASE IN WATER OR OTHER LIQUID.
3. Thoroughly clean speed selector knob so that it works freely. It will become sticky when in
use. Use a damp cloth or sponge to flush and clean the groove around the water shielded
switch. You may also lightly spray the surface around the switch with an all-purpose cleaner
and work the switch back and forth a few times to loosen any dried residue under switch.
4. Polish with a soft cloth.
5. Always be sure to wring excess water out of cloth or sponge when cleaning around the
controls or any electrical part.
Lid/Center Lid
Wash in warm soapy water. Rinse by a running water and dry. Reassemble before use.
Container and Blade Assembly:
Method #1
- After use, add warm water and a splash of vinegar to blender jar. Turn ON and let the
blender work the liquid for about a minute. Pour out, rinse the blender jar well.
Method #2
- Fill the blender jar half way with warm water, add a small amount of liquid dish detergent and
turn the unit ON for about 30 seconds. Repeat if needed. Rinse well.
Method #3
- If blender was left sitting until there is dried, crusty food bits inside: fill with warm, soapy
water (or vinegar water) and let sit for about 30 to 60 seconds. Empty water to about half
and then blends for 30 second intervals until clean.
1. Turn OFF the unit and wait for the blade and motor to stop.
2. Always unplug the unit after every use.
3. Remove the blade assembly by turning it clockwise.
4. Wash the rubber packing, blade and jar support with soap and water.
5. Turn the plastic jar upside down to remove excess water.
6. Wipe the plastic jar and blade with soft cloth to dry. Make sure to reassemble the unit
properly before storing it.
7. Never leave food inside the blender jar for a long period of time.
8. Store the blender on a dry cool place.
NOTE: NEVER ALLOW THE BOTTOM OF THE BLADE TO GET WET.
TROUBLE SHOOTING:
REMINDER: Please do not forget to fill up and send the warranty card with receipt to our
email addressimarflexfb@evergoodinc.com
Distributed By: Evergood Unlimited Corp.
901 G.Masangkay St., Manila
Made in China
PROBLEM
CAUSE
SOLUTION
Motor not
working
1. Convenience
outlet is not
working.
2. Damage on the
unit
1. Check the outlet where the
unit is plug in if it is working.
2. Check for any damage.
3. Bring the unit to the nearest
Authorized Imarflex Service
Center
Motor stop
during
operation
1. Overload
protection
activated
1. Unplug and let the unit rest
for at least 1 minute
Smoke and
burnt smell
occurred
1. Unit is use for the
first time
1. Its normal for the first use
Leak on
the bottom
of the jar
1. Rubber packing is
not properly
installed
2. Rubber was
damaged
1. Turn OFF the unit. Remove
the jar and check the rubber.
Reassemble the unit.
2. Replace the rubber with the
new one.
3. Bring the unit to the nearest
Authorized Imarflex Service
Center.
Attachment
not
functioning
1. Not properly install
1. Turn off the unit and
check the assembly
