Side 1/2

Booting

Device malfunction

Failed to boot up

Booting completed

Waiting for Wi-Fi configuration

WiFi connection process

Device has been configured with WiFi, but it

failed to work normally

WPS pairing

Wi-Fi connection succeeded

Operate normally

Device upgrade

SD card malfunction

Reset/WPS Button

Micro SD Card Slot

Note:

To reset, long press for 10 seconds till the light is off; to enable WPS, just press the button.

Packing List Product Appearance

Device*1 QSG*1 Power Adapter*1

Quick Installation Board*1

Screw Package*1 USB*1

Installation Position Map*1

The following table shows more information about status of indicator light

Spinning red

Spinning green

Flashing yellow

Flashing green

Blue light stably on

Flashing blue

Flashing red

Device StatusIndicator Light Status

Built-in Speaker

LED Indicator

Network Port

Power

Microphone

Lens

Version 1.0.0

Quick Start Guide

Step1 Drill holes on the wall and install the expansion bolts into

the drilled holes.

Step2 Fix the installation board with screws onto the wall.

Step3

Spin the device to get locked onto the installation board.

Note:

Before installation, please make sure the installation environments

can at least support 3x weight of the device.

To install the device, do the following.

Device Installation

Step 1

Power on your camera with power adapter.

Step 2

Connect your smartphone to your Wi-Fi network, scan the

QR on the packing box to download and install Imou App.

Step 3

Run Imou App, and register account for first use.

Step 4

Follow the steps below to add your camera .

Note:

-If you have more cameras, please follow step 4 to add them one by one.

-If you want to change the Wi-Fi signal, please reset the camera to factory default and repeat step 4 to add the camera.

Disclaimer

This quick start guide is for reference only. Minor difference might be

found inuser interface.

All the design and software here are subject to change without prior

writtennotice.

All trademarks and registered trademarks mentioned are the

properties of their respective owners.

Please visit our website or contact your local service engineer for

more information.

If there is any uncertainty or controversy,please refer to our final

explanation.

Operation by Imou App

Add Device

Device

Scan Setup

Add Successfully

Live View

Setup

WiFi Name

Setup

Admin password

Wall

Expansion Bolt

Installation Board

Screw

Device

Produkspesifikasjoner

Merke:	Imou
Kategori:	fotokamera
Modell:	Ranger Pro Z 4MP
Vekt:	250 g
Høyde:	101 mm
Bruksanvisning:	Ja
Bluetooth:	Nei
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Tilkoblingsteknologi:	Ledning & Trådløs
Maksimal oppløsning:	2688 x 1520 piksler
Videokomprimeringsformater:	H.264, H.265
Diameter:	94 mm
Strømkildetype:	DC
Antall kameraer:	1
Innebygde høyttalere:	Ja
Sertifisering:	CE, FCC, UL
Optisk zoom:	3 x
Innebygd mikrofon:	Ja
Progressiv skanning:	Ja
Antall linser:	1
Antall sensorer:	1
Bevegelsessensor:	Ja
Bildefrekvens:	30 fps
Sensortype:	CMOS
Produktfarge:	Black, White
Vippevinkelområde:	0 - 90 °
Monteringssett:	Ja
Minnekortenhet:	MicroSD (TransFlash)
Støttede grafikkoppløsninger:	2688 x 1520
Kabler inkludert:	USB
Zoomfunksjon:	Ja
Strømforbruk (vanlig bruk):	10 W
Driftstemperatur (T-T):	-10 - 45 °C
Innebygd kortleser:	Ja
nattsyn:	Ja
Formfaktor:	Sfærisk
CCD-sensorstørrelse:	1/2.9 "
tilbakestillingsknapp:	Ja
Modell/Type:	IP-sikkerhetskamera
Innebygd harddisk:	Nei
Panoreringsomfang:	0 - 355 °
Objektivets synsvinkel, diagonal:	130.7 °
Minimumsbelysning:	- lx
Ethernet/bredbåndsforbindelse:	Ja
Ethernet-grensesnittype:	Raskt Ethernet
Relativ luftfuktighet under drift (H-H):	0 - 93
Støttede plasseringer/plasseringer som kan benyttes:	Innendørs
Montasjetype:	Bord
Totale megapiksler:	4 MP
Maksimal størrelse på hukommelseskort:	128 GB
Effektiv distanse for nattsyn:	10 m
Panoreringskontroll:	Ja
Vippekontroll:	Ja
Objektivdiameter:	9 mm
WPS-trykknapp:	Ja
