BP-RA-MBH
Right Angle Baby Plate
with Mini Ball Head
INSTRUCTIONS
Thank you for choosing Impact.
The BP-RA-MBH Right Angle Baby Plate securely mounts a camera or
camcorder onto a wall. Its 8-inch baby pin can support a camera and lens
combination that weigh up to 6 pounds, and the included mini ballhead lets
you precisely adjust the camera’s angle and the distance from the wall. The
metal mounting block and ballhead are removable for camera swapping or
maintenance, and they can be mounted on any tripod, light stand, or C-stand
with a 5/8-inch stud. The plate mounts with four screws or other wall fasteners.
• Securely mount the plate to the
wall before use.
• Make sure that this product is
intact and that there are no missing
parts.
• Do not exceed the maximum load
capacity.
• All images are for illustrative
purposes only.
Plate Dimensions 3.2 × 5.9 in. (8 × 15 cm)
Arm Length 8 in. (20.3 cm)
Load Capacity 6 lb. (2.7 kg)
Weight 1.5 lb. (689 g)
Screw Size 1/4 in.
Pin Diameter 5/8” (16mm)
1. Screw holes
2. Ballhead locking knob
3. 1/4-20 mounting bolt
4. Mini ballhead
5. Baby pin
6. 5/8 in. receiver
7. Mounting block
8. Mounting block locking knob
9. Wall plate
You’ll Also Need
• Wall fasteners (anchors and
screws, molly bolts, or toggle bolts)
• Drill bit (see the fastener’s
packaging for appropriate size)
2
4
3
7 6 58
9
1
