IRoad X10 Pro Bruksanvisning
Les nedenfor 📖 manual på norsk for IRoad X10 Pro (36 sider) i kategorien Dashcam. Denne guiden var nyttig for 25 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/36
IROAD X10 PRO
Quick Start
Ver 1.2 (NOV. 2024)
FAQ
English
简体中文
繁體中文
日本語
Polski
Русский
tiếng Việt
Türkçe
español
italiano
CONTENTS
ת י ִר ְ ב ִע
رع
3
10
12
14
16
18
20
22
24
26
28
30
Scan for User Guide
Videos
PRECAUTIONS
3
※
※
※
※
※
※
※
※
※
Do not arbitrarily disassemble and modify the product.
It will be considered user’s fault and it will void the warranty.
Do not handle the product while driving, it can cause serious accidents.
(Please operate the product in a safe place after parking.)
Turn recorder off when exposed to direct sunlight or used for too long.
Otherwise, malfunction or breakdown will occur.
Do not remove SD card or turn off the power during the firmware update.
It may cause malfunction or loss of data.
Use of genuine IROAD memory card is recommended.
Failure to use genuine SD card may cause error or malfunction.
Real-time recording and playback via Wi-Fi could be delayed depending on the
specifications of your smart device.
Motion detection is initiated by an image sensor software.
Errors may occur depending on the surrounding environment and the voltage of the car.
If the GPS signal is good, ADAS will activate when the speed of the car is above the set
speed. The surrounding environment may cause errors.
Incorrect installation of the uninterrupted power cable may cause malfunctions.
Installations must be different depending on the power type of the vehicle.
(Please contact a professional engineer if you need help to install it)
4
WARRANTY
IROAD Global guarantees the quality of the item.
Only signed members can use this card.
Transferring and lending the card to others is strictly not allowed.
No after-sale-service will be provided in case the card is lost.
Warranty period of each part is as follow.
Product(Front/Rear Camera) : 1 Year
Interior IR Camera, External Waterproof Camera : 1 Year
Memory Card : 6 Months
Fuse Cable, Rear Cable, Wi-Fi Dongle : Does Not Cover
●
●
●
●
PRODUCT NAME
SERIAL NUMBER
DATE OF PURCHASE
SUPPLIER SHOP NAME
CONTACT NUMBER
SPECIFICATIONS
Model
Image sensor
Resolution/Frame
Options Cam (3CH)
Viewing angle
Wi-Fi (5GHz)
Wi-Fi button
Audio input
Video/Audio
Vibration Sensor
Voice guidance
Built-in GPS
Speed Cam Alert
Storage medium
Night Vision & HDR
Recording mode
Uninterrupted
power
Backup Battery
Power supply
Operating temperature
Humidity
Dedicated PC viewer
Application
IROAD X10 PRO
Front : Sony STARVIS2(IMX678) Image Sensor
Rear : 2.0 Mega Pixel CMOS Image Sensor
Front : UHD 3840x2160p@30fps / Rear : FHD 1920x1080p@30fps
Interior Cam : FHD 1920x1080p@30fps
External Waterproof Cam : FHD 1920x1080p@30fps
(Front camera switches to QHD in 3CH)
Front : 160° / Rear : 140°
Smartphone Playback/Settings, Firmware Update
Activate "Stand-by Mode for Registration"
Embedded MIC
H.264/ ADPCM
3-axis Acceleration Sensor
Effect sound/buzz alert to inform the condition of the device
Voice guidance supported
Synched with Google Maps
Records location and speed of the vehicle
Voice alerts for speed and red-light camera
(You can Update via ‘iroad.kr’ → Support → FAQ → Updates)
Micro SD 32GB ~ 256GB (Class10)
Supported (Front & Rear HDR)
Driving, Event(Impact), Parking(Timelapse, Motion Detection, Energy Saving
Mode), Manual Recording
Uninterrupted Power
(Low voltage cut-off, overheating prevention is embedded)
Built-in Supercapacitor
DC 12V/24V
-10 ~ 60° C (Storage temperature : -20 ~ 70° C)
10 ~ 95%
Win10 (64Bit), Mac (OS X 10.13 or higher)
Android 10.0, IOS 14.0 or higher : Firmware update supported
5
PACKAGE
Basic Components
Front Camera
/ Cradle
Rear Camera
/ Cradle
Uninterrupted
Fuse Cable
IROAD Genuine
MicroSD
Wi-Fi
USB Dongle
User Manual
Rear Camera
Cable
Protective
Film
Optional Items
The Basic components may change without prior notice.
●
Interior
Infrared (IR) Camera
External Waterproof
Camera
Cigar Jack
Power Cable
OBD-Ⅱ Power Cable
USB MicroSD
Reader
6
BUTTON SCENARIO GUIDE
7
MODE
DESCRIPTION
MANUAL
RECORDING
Start manual recording.
OPERATION
FORMATTING
THE MICRO SD
CARD
“SD card is formatting, please wait,
system restart.” will be signaled,
format the microSD card and restart.
Press the button ( )
shortly.
Press the button ( )
for 7sec.
MODE
DESCRIPTION
OPERATION
VOICE
RECORDING
ON/OFF
"Voice recording is OFF"
OR "Voice recording is ON"
Press the button ( )
shortly.
9
USING THE MOBILE APP
ANDROID DEVICE
On your Android device, open the “Google Play Store” and download and install
“IROAD DASH CAM”
1
After running the application, register your device.
- Activate the registration stand-by mode by pressing the Wi-Fi registration button
“Stand-by mode for the registration” (Voice guidance)
2
Tap Connection
- The SSID and model will be shown.
- Once the user selects the device, it will be registered & connected.
3
iOS DEVICE
On your iOS device, open the “App Store” and download and install
“IROAD DASH CAM”
1
After running the application, register your device.
- Activate the registration stand-by mode by pressing the Wi-Fi registration button
“Stand-by mode for the registration” (Voice guidance)
2
Tap Connection
- follow the on-screen instructions to connect the product to your smartphone.
3
Select the Wi-Fi Network
- From the Wi-Fi setting menu on your smartphone, select the Wi-Fi network starting
with “IROAD”
4
Enter Password
- Enter “qwertyuiop” in the password field
Now the product is connected to your iOS device via Wi-Fi
5
The password is the first row of the alphabet on the keyboard
●
注意事项
10
※
※
※
※
※
※
※
※
※
请勿随便拆卸或维修产品。
此为用户过失，无法保修。
驾驶途中请勿操作设备，可能引发事故。
(请将车辆停稳,再进行操作。)
在暴露于阳光直射或长时间使用的情况下请关闭行车记录仪。
否则，容易发生故障。
更新固件的过程中，请勿拔掉SD卡或电源线。
可能导致发生故障或者信息缺失。
请使用原装正品IROAD记忆卡。
如不使用原装正品，可能导致故障发生。
根据智能设备的参数，实时记录和监控记录录像回放可能会有所延迟。
移动侦测由图像传感器软件启动。
车辆电压和周边环境会导致故障发生。
如GPS信号良好，ADAS功能会由设置的速度值运行。
周边环境有可能导致故障发生。
随便连接不间断电源可能引发故障，请勿随便连接不间断电源。
电源连接根据车辆电源而定。
(如需安装，请咨询专业技术人员。
