WARNING
FOR YOUR SAFETY - This product must be installed and serviced by a contractor who is licensed and
qualified in pool equipment by the jurisdiction in which the product will be installed where such state or
local requirements exist. The maintainer must be a professional with sufficient experience in pool equipment
installation and maintenance so that all of the instructions in this manual can be followed exactly. Before
installing this product, read and follow all warning notices and instructions that accompany this product.
Failure to follow warning notices and instructions may result in property damage, personal injury, or death.
Improper installation and/or operation may void the warranty. DO NOT MODIFY THIS EQUIPMENT.
Improper installation and/or operation can create unwanted electrical hazard which can
cause serious injury, property damage, or death.
ATTENTION INSTALLER - This manual contains important information about the installation,
operation and safe use of this product. This information should be given to the owner/
operator of this equipment.
INSTALLATION AND
OPERATION MANUAL
VSFHP130DV
VSFHP165DV
VSFHP185DV
Jandy
Variable-Speed Pumps
ENGLISH | FRANÇAIS | ESPAÑOL
H0719301 REVA
VSFHP130DVS
VSFHP165DVS
VSFHP185DVS
Page 2
ENGLISH
Jandy
®
Variable-Speed Pumps, DV/DVS Models
|
Installation & Operation Manual
Table of Contents
EQUIPMENT INFORMATION RECORD
DATE OF INSTALLATION
INSTALLER INFORMATION
INITIAL PRESSURE GAUGE READING (WITH CLEAR FILTER)
PUMP MODEL
HORSEPOWER
NOTES:
Section 1. Important Safety Instructions ....... 3
1.1 Safety Instructions .............................................. 3
1.2 Pool Pump Suction Entrapment Prevention
Guidelines .......................................................... 5
Section 2. General Description ....................... 6
2.1 Introduction ......................................................... 6
2.2 Product Dimensions ........................................... 6
2.3 ProductSpecications ........................................ 7
2.4 Product Contents ................................................ 7
Section 3. Installation Information .................. 9
3.1 Plumbing ............................................................ 9
3.2 Electrical Installation .......................................... 11
3.3 Pump DIP Switch Settings................................ 14
3.4 Conduct Pressure Test ..................................... 15
Section 4. Operation ....................................... 16
4.1 Start-up ............................................................. 16
Section 5. Service & Maintenance ................ 17
5.1 Removing the Pump Lid ................................... 17
5.2 Winterizing the Pump ....................................... 18
Section 6. Troubleshooting and Repair ........ 19
6.1 Service Technician Maintenance ...................... 20
Section 7. Product Specications and
Technical Data .............................. 21
7.1 Exploded Views ................................................ 21
7.2 Performance Curves ........................................ 22
Page 3
ENGLISH
Jandy
®
Variable-Speed Pumps, DV/DVS Models
|
Installation & Operation Manual
WARNING
RISK OF SUCTION ENTRAPMENT HAZARD, WHICH, IF NOT AVOIDED, CAN RESULT IN SERIOUS INJURY
OR DEATH. Do not block pump suction, as this can cause severe injury or death. Do not use this pump for
wading pools, shallow pools, or spas containing bottom drains, unless the pump is connected to at least two
(2) functioning suction outlets. Suction outlet (drain) assemblies and their covers must be certified to the latest
published edition of ANSI
®
/ASME
®
A112.19.8, or its successor standard, ANSI/APSP-16.
WARNING
To reduce the risk of injury, do not permit children to use this product.
WARNING
To reduce the risk of property damage or injury, do not attempt to change the backwash (multiport, slide, or full
flow) valve position with the pump running.
WARNING
Jandy pumps are powered by a high voltage electric motor and must be installed by a licensed or certified
electrician or a qualified swimming pool service technician.
WARNING
Due to the potential risk of fire, electric shock, or injuries to persons, Jandy pumps must be installed in accordance
with the National Electrical Code
®
(NEC
®
), all local electrical and safety codes, and the Occupational Safety
and Health Act (OSHA). Copies of the NEC may be ordered from the National Fire Protection Association, 1
Batterymarch Park, Quincy, MA 02169, or from your local government inspection agency.
WARNING
RISK OF ELECTRIC SHOCK, FIRE, PERSONAL INJURY, OR DEATH. (For all permanently installed units
intended for use on 15 or 20 ampere, 120 through 240 volt, single phase branch circuits). Connect only to a
branch circuit that is protected by a ground-fault circuit-interrupter protection for personnel (GFCI). Contact a
qualified electrician if you cannot verify that the circuit is protected by a GFCI. A GFCI should be provided by the
installer and should be tested on a routine basis. To test the GFCI, push the test button. The GFCI should interrupt
power. Push the reset button. Power should be restored. If the GFCI fails to operate in this manner, the GFCI
is defective. If the GFCI interrupts power to the pump without the test button being pushed, a ground current is
flowing, indicating the possibility of electrical shock. Do not use the device. Disconnect the device and have the
problem corrected by a qualified service representative before using.
WARNING
Incorrectly installed equipment may fail, causing severe injury or property damage.
Section 1. Important Safety Instructions
READ AND FOLLOW ALL INSTRUCTIONS
1.1 Safety Instructions
All electrical work must be performed by a licensed electrician and conform to all national, state, and local codes.
When installing and using this electrical equipment, basic safety precautions should always be followed, including the
following:
