Side 1/38

Subwoofer Kullanım Kılavuzu

Betjeningsvejledning til subwoofer

重低音喇叭擁有者手冊

低音炮用户手册

サブウーファーの取扱説明書

Buku Panduan Pemilik Subwoofer

Subwoofer Gebruikershandleiding

Instrukcja obsługi subwoofera

Alibassokaiuttimen ohjekirja

Bruksanvisning för subwoofer

Руководство пользователя сабвуфера

Subwoofer Bedienungsanleitung

Manual do proprietário do subwoofer

Manuale utente del Subwoofer

Manual del propietario del subwoofer

Mode d'emploi du caisson de graves

Subwoofer Owner's Manual

서브우퍼 사용 설명서

STAGE 1220B

CHS

TR04321_B

Торговая марка : JBL

Назначение товара : Автомобильная акустическая система

Изготовитель : Харман Интернешнл Индастриз Инкорпорейтед, США, 06901 Коннектикут, г.Стэмфорд, Атлантик Стрит 400, офис 1500

Страна происхождения : Китай

Импортер в Россию : OOO “ХАРМАН РУС СиАйЭс“, Россия, 127018, г.Москва, ул. Двинцев, д.12, к 1

Гарантийный период : 1 год

Информация о сервисных центрах : www.harman.com/ru тел. +7-800-700-0467

Срок службы : 3 года

Товар не подлежит обязательной сертификации

Дата производства : Дата изготовления устройства определяется по двум буквенным обозначениям из второй группы символов серийного

номера изделия, следующих после разделительного знака «-». Кодировка соответствует порядку букв латинского

алфавита, начиная с января 2010 года: 000000-MY0000000, где «M» - месяц производства

(А - январь, B - февраль, C - март и т.д.) и «Y» - год производства (A - 2010, B - 2011, C - 2012 и т.д.).

THANK YOU FOR CHOOSING THIS JBL PRODUCT

This product has been designed to deliver great bass performance from a compact, easily installed enclosure. To get the best performance

from your enclosure, we strongly recommend that you entrust installation to a qualified professional. Although these instructions explain how

to install your enclosure in a general sense, they do not show specific installation methods that may be required for your particular vehicle.

If you do not have the necessary tools or experience, do not attempt the installation yourself. Instead, please ask your authorized JBL car

audio dealer about professional installation. To help us serve you better if your enclosure ever requires warranty service, please retain your

original sales receipt and serial number.

INSTALLATION WARNINGS AND TIPS

INSTALLATION TIPS

• Always wear protective eyewear when using tools.

•

Turn off all audio components and other electrical devices before you start. Disconnect the negative (–) lead from your vehicle’s battery.

•

Check clearances on both sides of a planned mounting surface. Be sure that screws or wires will not puncture brake lines, fuel lines or

wiring harnesses, and that wire routing will not interfere with the safe operation of the vehicle.

• When making electrical connections, make sure they are secure and properly insulated.

• Before drilling or cutting holes, use a utility knife to remove unwanted fabric or vinyl, to keep material from snagging in a drill bit or saw.

• Do not mount speakers where they will get wet.

CHOOSING A MOUNTING LOCATION FOR THE ENCLOSURE

Choose a mounting location that doesn’t interfere with cargo, the fold-down rear seat or the trunk lid. The best location is usually a corner

of the trunk or cargo area. Securely mount the enclosure to the mounting surface.

WARNING: Playing loud music in an automobile can permanently damage your hearing as well as hinder your ability to hear traffic.

Listening at low levels while driving is recommended. HARMAN International accepts no liability for hearing loss, bodily injury or property

damage resulting from use or misuse of this product.

STAGE 1220B

Produkspesifikasjoner

Merke:	JBL
Kategori:	Subwoofer
Modell:	Stage 1220B
Produkttype:	Subwoofer-driver
Bredde:	764.5 mm
Dybde:	347.5 mm
Høyde:	380 mm
Produktfarge:	Sort
Kroppsmateriale:	MDF
Antall drivere:	2
Subwoofer RMS-styrke:	500 W
Subwoofer-driverdiameter (imperisk):	12 "
Subwoofer-type:	Aktiv subwoofer
Frekvensomgang subwoofer:	34 - 200 Hz
Diameter på subwoofer-driver:	300 mm
Subwoofer-sensitivitet:	94 dB
Subwooferens toppeffekt:	1000 W
Svingspolediameter:	50.8 mm
Subwoofer-impedans:	2 Ω
