Thank you for choosing a JL Audio Marine Subwoofer.
With proper installation, your new speaker will deliver
years of listening pleasure.
We strongly recommend that you have your subwoofer
installed by your authorized JL Audio dealer.
The installation professionals employed by your dealer have
the necessary tools and experience to properly install this product.
If you prefer to perform your own installation,
please read this instruction manual completely before
beginning the process.
OWNER’S MANUAL
Marine Subwoofer with
Built-In RGB LED Lighting (optional)
2 JL AUDIO M 3 -10 I B
M3
-
10
10.0-IN CH MARINE SUBWO OFER DRIVER
Built in USA wit h global compone nts.
Patents pending.
A
B
E
D
C
All specifications are subject to change without notice.
PHYSICAL SPECIFICATIONS
Subwoofer Parameters M3-10IB
Free Air Resonance (Fs): 41.84 Hz
Electrical “Q” (Qes): 0.806
Mechanical “Q” (Qms): 11.751
Total Speaker “Q” (Qts): 0.754
Equivalent Compliance (Vas): 1.29 ft
3
/ 36.53 litres
One-way, Linear Excursion (Xmax)*: 0.42 in / 10.7 mm
Efficiency (1W/1m)**: 87.23 dB SPL
Effective Piston Area (Sd): 50.68 in / 0.0327 m
DC Resistance (Re): 3.957 ohm
Nominal Impedance: 4 ohm
Infinite Baffle Use: Yes (Preferred)
Enclosure Use: Yes (Sealed Only)
Power Handling (continuous): 175W
* Xmax specifications are derived via one-way voice coil overhang method with no
correction factors applied.
** Efficiency (1W/1m) is not an accurate indicator of a subwoofer’s output capability
and should not be used as a comparison to other subwoofers to determine which
one is “louder” !
Subwoofer Physical Specifications
Nominal Diameter 10 in / 250 mm
Outer Diameter (A) 10.75 in / 273 mm
Bolt Hole Circle (B) 9.71 in / 247 mm
Frontal Grille Protrusion-Classic* (C) 1.50 in / 38 mm
Frontal Grille Protrusion-Sport* (C) 1.58 in / 40 mm
Mounting Hole Diameter (D) 8.875 in / 225 mm
Mounting Depth (E) 5.00 in / 127 mm
Net Weight 12.60 lbs / 5.70 kg
Driver Displacement 0.52 ft / 1.47 litres
* Frontal grille protrusion measured from mounting surface (Sport Grille Pictured)
INCLUDED PARTS
• One Polymer Subwoofer Grille
• Six #8 x 1 1/2-inch (38 mm) Phillips pan-head stainless-steel screws
• Six #8 stainless-steel washers
• Logo Badges
One Pair Black (Gunmetal Sport Models Only)
One Pair White (White Sport Models Only)
LED Equipped Models
Built-in, RGB LED lighting delivers beautiful accent illumination. LED functionality
requires separate wiring at each speaker location. Adjustable control of RGB
lighting requires the use of an RGB lighting controller (sold separately). For optimal
performance, we recommend using the JL Audio marine lighting controller (MLC-RW).
We recommend the use of this speaker in a bi-amplified system using high-quality satellite
speakers and amplifiers. We do not recommend the use of this subwoofer with a passive
crossover (coil), as this type of device will adversely affect performance.
