Side 1/20
OWNER’S MANUAL
1000W Monoblock Subwoofer Amplier
Thank you for purchasing a JL Audio amplifier for
your automotive sound system.
Your amplifier has been designed and manufactured to exacting
standards in order to ensure years of musical enjoyment in your vehicle.
For maximum performance, we highly recommend that you have
your new amplifier installed by an authorized JL Audio dealer. Your
authorized dealer has the training, expertise and installation equipment
to ensure optimum performance from this product. Should you
decide to install the amplifier yourself, please take the time
to read this manual thoroughly to familiarize yourself
with its installation requirements and setup procedures.
If you have any questions regarding the instructions in this
manual or any aspect of your amplifier’s operation, please contact your
authorized JL Audio dealer for assistance. If you need further assistance,
please call the JL Audio Technical Support Department
at (954) 443–1100 during business hours.
2 | JL Audio - RD1000/1 Owner’s Manual
PROTECT YOUR HEARING!
We value you as a long-term customer. For
that reason, we urge you to practice restraint in
the operation of this product so as not to damage
your hearing and that of others in your vehicle.
Studies have shown that continuous exposure to
high sound pressure levels can lead to permanent
(irreparable) hearing loss. This and all other
high-power amplifiers are capable of producing
such high sound pressure levels when connected
to a speaker system. Please limit your continuous
exposure to high volume levels.
While driving, operate your audio system in
a manner that still allows you to hear necessary
noises to operate your vehicle safely (horns,
sirens, etc.).
SERIAL NUMBER
In the event that your amplifier requires
service or is ever stolen, you will need to have
a record of the product’s serial number. Please
take the time to enter that number in the space
provided below. The serial number can be found
on the bottom panel of the amplifier and on the
amplifier packaging.
Serial Number:
INSTALLATION APPLICATIONS
This amplifier is designed for operation in
vehicles with 12 volt, negative-ground electrical
systems. Use of this product in vehicles with
positive ground and/or voltages other than 12V
may result in damage to the product and will void
the warranty.
This product is not certified or approved for
use in aircraft.
Do not attempt to “bridge” the outputs of this
amplifier with the outputs of a second amplifier,
including an identical one.
WHAT’S INCLUDED
(1) RD1000/1 amplifier
(1) Control panel cover (removable)
(1) Round logo badge
(1) 2.5 mm hex wrench
(1) Owner’s manual
PLANNING YOUR INSTALLATION
It is important that you take the time to
read this manual and that you plan out your
installation carefully. The following are some
considerations that you must take into account
when planning your installation.
Status
LED
(pg. 10)
Bass Boost
(pg. 8)
Input
Voltage
(pg. 7)
Low-Pass Filter
Frequency
Selector
(pg. 8)
Turn-On
Mode
(pg. 6)
Clipping
Indicator
(pg. 7)
Input Sensitivity
Control
(pg. 7)
+12 VDC Ground Remote
Turn On Mode
Rem.
|
Oset
|
Signal
Low
|
High
Clipping
Input Voltage
0
+12
+5
+10
+8
Bass Boost (dB) LP Filter Freq. (Hz)
Input Sensitivity
Monoblock Subwoofer Amplifier
MONO SUBWOOFER OUPUT
(
L
)
(
R
)
CH. 1
(
L
)
CH. 2
(
R
)
INPUT SECTION
PRE-OUTS
Remote
Level
Control
(RBC-1)
Mono Subwoofer Output
INPUT SECTION
(
L
)
(
R
)
(
L
)
(
R
)
PREOUTS
+12 VDC Ground Remote
Remote Turn-On
Connector
(pg. 6)
Chassis Ground
Connector
(pg. 5)
Left & Right
Output Jacks
(pg. 9)
+12 V Power
Connector
(pg. 5)
Speaker Outputs
(pg. 9)
Remote Level
Control
(pg. 8)
Left & Right
Input Jacks
(pg. 7)
